Whirlpool ED5PHEXRL02 side-by-side refrigerator Parts

The Whirlpool side-by-side refrigerator model ED5PHEXRL02 has a total capacity of 25.4 cubic feet. This is the overall storage space for both the fresh food (refrigerator) and freezer compartments combined.

We recommend checking the product data section in the documentation for ED5PHEXRL02.

• Look for a “product data” or “specifications” section
• Check for “total capacity” (sometimes listed as “total volume”)
• If separate capacities are listed, add refrigerator + freezer
• Use the model and serial label inside the fresh food compartment to confirm you are matching the correct model

Reference: ED5PHEXRL02 owner’s manual

Capacity is a measurement of interior volume, not usable shelf space. Shelves, bins, the ice maker, and air channels reduce how much you can practically load.

Knowing the cubic feet helps when comparing side-by-side refrigerators, planning kitchen fit, and estimating storage for groceries. It also helps when choosing accessories like bins and when deciding whether to keep or replace the unit.

Last updated: January 2026

The most common issues we see with the Whirlpool ED5PHEXRL02 side-by-side refrigerator involve cooling performance, ice maker and water dispenser problems, and frost buildup from defrost system trouble. Many of these symptoms trace back to airflow, water supply, or a failed control or defrost component; the owner's manual helps confirm settings and basic checks.

• Not cooling or warm refrigerator/freezer: dirty condenser coils, blocked vents, evaporator fan issues, or a control/thermostat problem.
• Ice maker not making ice: water supply shutoff, frozen fill tube, failed inlet valve, or ice maker failure.
• Water dispenser slow or not dispensing: clogged filter, low house water pressure, kinked water line, or inlet valve issue.
• Frost buildup on freezer back wall: defrost heater, defrost bi-metal, or control problem.
• Door not closing well or moisture around door: door alignment or gasket sealing issues.

1. Verify temperature settings and allow 24 hours after changes.
2. Make sure air vents inside both compartments are not blocked by food packages.
3. Clean condenser coils and confirm the condenser fan is running (if equipped).
4. Confirm the shutoff valve is fully open and the water line is not kinked.
5. If frost is heavy, unplug and fully defrost the freezer; then watch for frost returning within a few days.

These are model-matched parts that often resolve the symptoms above when testing confirms failure:

A side-by-side like the ED5PHEXRL02 depends on steady airflow and a working defrost system to keep temperatures stable. Water and ice issues are usually supply related (filter, valve, tubing) and are often faster to diagnose than sealed-system cooling problems.

Last updated: March 2026

Your Whirlpool side-by-side refrigerator’s model number is printed on the appliance ID label, usually inside the fresh food (refrigerator) compartment along the cabinet wall near the crisper drawers or on a side wall. Match that label exactly to ensure you get the right ED5PHEXRL02 parts.

Check these common label locations first:

• Inside the refrigerator section on the left or right side wall
• On the ceiling of the fresh food compartment near the light housing
• Along the frame behind the crisper pans (you may need to slide the pans out)
• On the hinge-side door frame area (open the door and look along the cabinet edge)
• Behind the toe grille at the bottom front (less common, but worth a quick look)

If the label is hard to read, wipe it gently with a damp cloth and take a clear photo so you can zoom in.

Write down the full model number and any additional identifiers exactly as shown:

• Model number (for example: ED5PHEXRL02)
• Serial number (helps confirm production run and compatible revisions)
• Manufacturing date (sometimes shown; useful for matching updated parts)

Whirlpool often uses similar-looking model numbers across multiple side-by-side refrigerators; one character difference can change which water filter, ice maker, or electronic control fits.

Use this as a simple reference when you are shopping or troubleshooting.

Once you confirm the model number, use it to select parts that fit your refrigerator, such as the refrigerator water filter EDR3RXD1. For diagrams and label-location details specific to this model, use the ED5PHEXRL02 owner's manual.
