Kenmore 79575002401 refrigerator Parts

Kenmore refrigerator model 79575002401 is a bottom-mount (bottom freezer) design, but the exact cubic-foot capacity is not listed in the manual excerpts we have for this model family. Most Kenmore 795 bottom-mount refrigerators are commonly in the 20 to 22 cu. ft. range; confirm the exact number on the model’s rating label or in the 79575002401 owner's manual.

Where to find the exact cubic feet (fastest options)

Use these checks in order; they are the most reliable for your specific refrigerator.

• Rating label inside the fresh food compartment (often on a side wall or near the crisper area); it may list capacity in cu. ft.
• First pages/specifications section of the 79575002401 owner's manual
• Product ID plate (sometimes behind a crisper drawer or along the cabinet frame)
• If you have the original paperwork, look for “capacity” or “total volume”

Typical capacity range for Kenmore 795 bottom-mount models

Many Kenmore models that start with 795 (commonly LG-built) fall into a fairly consistent size class.

Refrigerator type	Typical capacity range	What that means for you
Bottom-mount (bottom freezer)	20 to 22 cu. ft.	Standard kitchen fit, good for most households
Larger bottom-mount variants	22 to 25 cu. ft.	More storage, sometimes deeper/wider cabinet

Why it matters

Knowing the cubic feet helps us match the right shelves, drawers, door bins, and gaskets, and it also helps when comparing airflow needs and food storage expectations for a bottom-freezer refrigerator.

Related tip for this model family

If you are checking capacity because cooling seems weak or temperatures fluctuate, review the control and airflow guidance in the 79575002401 owner's manual. For display or diagnostic issues on Kenmore 795 bottom-freezer units, the Kenmore 795 model bottom freezer refrigerator error codes guide is a good next step.

Last updated: February 2026

On Kenmore refrigerator model 79575002401, the drip pan (defrost drain pan) is designed to collect water during defrost; a small amount of water in it is normal and usually evaporates. Clean it when you notice odors, overflow, or heavy buildup; follow the steps in the 79575002401 owner's manual.

Quick steps to clean the drip pan

• Unplug the refrigerator (or switch off power at the breaker).
• Pull the refrigerator straight out to access the lower rear area.
• Remove the rear lower access cover if needed.
• Slide the drip pan out carefully; keep it level to avoid spills.
• Wash with warm water and mild detergent; rinse and dry completely.
• Reinstall the pan and cover, then restore power.

What to use (and what to avoid)

The goal is to remove slime and odor without damaging plastic.

Use	Avoid
Warm water + mild dish soap	Abrasive pads or harsh cleaners
Soft sponge or soft cloth	Cleaners containing petroleum
Baking soda and water for odors	Bleach on plastic parts

If the pan keeps filling with water

Water in the defrost drain pan is normal during defrost cycles and in humid weather; it can take longer to evaporate when it is hot or humid.

Check these common causes if you see puddles or repeated overflow:

• Refrigerator not level (water may not flow correctly to the pan)
• Dirty condenser area causing excess run time and moisture
• Clogged defrost drain tube (water backs up and can leak)
• Door gasket not sealing, letting humid air in (see refrigerator gasket assembly ADX73350922)

Why it matters

A clean drip pan helps prevent odors and reduces the chance of water leaking onto the floor. It also makes it easier to spot a defrost drain problem early, before it causes recurring puddles.

Last updated: February 2026

For Kenmore model 79575002401, the most accurate way to get cubic feet is to read the capacity listed on the refrigerator’s identification label (rating plate) inside the fresh food compartment; the model number alone does not reliably encode the exact capacity.

Fast ways to find the cubic feet (best to least effort)

• Check the rating plate inside the refrigerator compartment (commonly on the right-hand side wall); it lists model and serial information and typically includes capacity. See the 79575002401 owner's manual.
• Look up the spec section in the manual for your exact model family; capacity is usually listed with other key specs.
• Measure and estimate if the label is missing (useful for planning, not for exact specs).
• Compare by model family (Kenmore 795 bottom-freezer models often share similar sizes, but capacity still varies by revision and configuration).

Where to find the rating plate on this model

The identification label is located inside the refrigerator compartment, commonly on the right-hand side. Use that label for the most dependable capacity information. See the 79575002401 owner's manual.

If you need an estimate (quick math)

If you measure the inside dimensions of the refrigerator section and freezer section, you can estimate cubic feet:

What to measure	How	Notes
Interior width, depth, height	Measure in inches	Measure usable space, not door bins
Convert to cubic feet	(W x D x H) / 1728	Do fridge and freezer separately
Adjust for shelves/ducts	Subtract 10% to 20%	Air channels and liners reduce usable volume

Why it matters

Cubic feet affects how much food you can store and helps you choose compatible accessories (like shelves and drawers) and plan kitchen fit. For parts selection, we always recommend matching by model number 79575002401 first, then confirming the exact configuration in the manual.

Last updated: February 2026

Common Kenmore Elite refrigerator problems include warm temperatures (cooling failure), slow or no ice production, water leaks, and doors that do not seal or open correctly. On Kenmore model 79575002401, these issues are often tied to airflow restrictions, dirty condenser coils, door gasket condition, or ice maker water supply and temperature settings (see the 79575002401 owner's manual).

Most common symptoms and what usually causes them

• Refrigerator or freezer too warm: blocked air vents, frequent door openings, controls set too warm, dirty condenser coils
• Ice maker slow or not making ice: freezer not cold enough, heavy ice usage, door left open, water supply restriction
• Water leaking or puddles: clogged/iced drain path, loose water line connections, cracked tubing
• Door hard to open or not sealing: dirty or sticky gaskets, door reopened too quickly (air pressure), misalignment
• No interior light or light issues: door switch not closing properly

Quick checks we recommend first (in order)

1. Confirm control settings and make only one change at a time; wait 24 hours between temperature adjustments.
2. Check airflow: keep packages from blocking vents and allow space for proper circulation.
3. Clean condenser coils (dust buildup is a top cause of poor cooling and long run times).
4. Inspect door gaskets: clean sticky residue; if the seal is torn or warped, replacement is the fix.
5. For ice maker issues: verify the freezer is cold enough and the water shutoff valve is fully open.

Parts that commonly solve these problems

Symptom	Common part involved	What it affects
Light does not turn on or door alarm behavior seems wrong	Refrigerator door push-button switch 6600JB1010A	Detects door open/closed
Frost buildup, warming, or defrost-related temperature swings	Refrigerator defrost sensor assembly 6615JB2005C	Defrost monitoring and control
Poor cooling with fan noise or weak airflow	Refrigerator condenser fan 4680JK1001B	Moves air across condenser coils
Leaks at the back or dispenser/ice maker supply issues	Refrigerator water tubing 5210JA3005W	Water supply routing

Why it matters

Cooling, ice production, and leak complaints usually share the same root causes: temperature control, air circulation, and water supply integrity. Fixing the basic maintenance items first prevents unnecessary part replacement and helps the refrigerator stabilize faster.

For model-specific troubleshooting steps (including temperature adjustment guidance and door gasket care), follow the 79575002401 owner's manual.

Last updated: February 2026

On Kenmore refrigerator model 79575002401, the ER 1F (often shown as ER IF) code points to a problem with the ice fan circuit (the fan that moves cold air around the ice maker area). Running the refrigerator with this fault can lead to poor ice production and temperature issues; follow the troubleshooting steps in the 79575002401 owner's manual.

What you should do first

• Power reset: unplug the refrigerator (or switch off the breaker) for 5 minutes, then restore power.
• Check for ice buildup around the ice maker area; heavy frost can block airflow and trigger the code.
• Make sure air vents are not blocked by food packages; restricted airflow can cause cooling problems.
• Confirm the freezer is set correctly; most units stabilize best near 0°F after 24 hours.
• If the code returns quickly, plan on inspecting the ice fan wiring, fan motor, or control.

Quick checks vs. likely repairs

What you notice	Most common cause	What it affects
Little or no ice, code appears	Ice fan not running or obstructed	Ice maker cooling and ice production
Frost buildup near ice room	Defrost or airflow issue	Air circulation, temperature stability
Code comes back after reset	Electrical fault (fan circuit or control)	Ongoing error, inconsistent temps

Parts that are commonly involved

If you confirm the issue is related to sensing or control (not just ice blockage), these model-matched parts are often checked during diagnosis:

• Refrigerator thermistor 6500JB2002T (temperature sensing)
• Refrigerator main pcb 6871JB1215J (controls fan operation and error reporting)
• Refrigerator defrost sensor assembly 6615JB2005C (helps manage frost conditions that can impact airflow)

Why it matters

The ice fan helps keep the ice maker area cold and stable. When airflow is reduced or the fan circuit fails, the refrigerator can struggle to maintain proper temperatures, which can lead to weak ice production and wider cooling complaints.

For code interpretation and model-family guidance, we also use the Kenmore 795 model bottom freezer refrigerator error codes reference.

Last updated: February 2026

Most Kenmore refrigerators average 10 to 15 years of service life; your Kenmore bottom-mount refrigerator model 79575002401 can reach the high end of that range when it is installed correctly, kept clean, and maintained using the care steps in the 79575002401 owner's manual.

Typical lifespan (what to expect)

Kenmore refrigerators generally fall into these real-world ranges:

Usage and maintenance	Typical lifespan	What usually ends the life
Light use, good maintenance	15 years	Sealed system or control failures
Average household use	10 to 15 years	Cooling performance decline, wear items add up
Heavy use, poor airflow/dirty coils	8 to 12 years	Compressor strain, overheating, icing issues

What extends the life the most

The manual for this model calls out routine care areas such as condenser coils, door gaskets, and air circulation. We recommend focusing on these high-impact habits:

• Clean dust from the condenser coil area regularly (better cooling efficiency, less compressor stress).
• Keep door gaskets clean and sealing tightly; warm air leaks force longer run times.
• Confirm the refrigerator has proper clearance for airflow around the cabinet.
• Set temperatures to normal targets (about 37°F fresh food, 0°F freezer) and avoid extreme settings.
• Address small issues early (unusual noises, frost buildup, temperature swings) before they become major repairs.

Quick “repair or replace” checkpoint

Use this simple guide when deciding whether to invest in a repair:

• Under 8 years: Repairs usually make sense unless it is a major sealed-system issue.
• 10 to 15 years: Compare repair cost to replacement; prioritize fixing airflow, fan, and defrost problems.
• 15+ years: Replace if you have repeated cooling failures or multiple expensive parts needed.

Why it matters

A refrigerator that runs hot (dirty coils, poor airflow, leaking gasket) cycles longer and stresses the sealed refrigeration system. That shortens lifespan and increases energy use, even if temperatures still seem “okay.”

Last updated: February 2026

If you have a Kenmore bottom-mount refrigerator, the fastest way to identify your exact model is to read the model/serial label inside the fresh food (refrigerator) compartment or on the door frame. Once you match that label to 79575002401, you can confidently order parts and follow the correct care and use instructions in the 79575002401 owner's manual.

Where to find the model number label

We see the model/serial tag in these common locations on Kenmore refrigerators like model 79575002401:

• Inside the refrigerator section on a side wall (often near the crisper area)
• On the door frame (open the refrigerator door and check the vertical frame)
• Behind or near the base grille (kick plate) area
• Occasionally near the ceiling of the fresh food compartment

How to read the label correctly

Use these tips so you capture the right identifier the first time:

• Copy the full model number exactly as printed (letters and numbers)
• Record the serial number too; it helps confirm production details
• Take a clear photo of the tag before ordering parts
• Do not use numbers from the control panel display; those are settings, not the model

Model number vs. serial number (quick guide)

Item on the label	What it’s used for	Example format
Model number	Picking the correct parts list and manual	79575002401
Serial number	Identifying the unit’s production run	Mix of letters and numbers

Why it matters

Kenmore model families can look similar, but parts like door switches, thermistors, and gaskets can vary by model. Using the exact model number prevents ordering the wrong refrigerator door parts or cooling system components.

Last updated: February 2026

For Kenmore bottom-mount refrigerator model 79575002401, the correct water filter is the cartridge that matches the filter number printed on your current filter or on the filter housing label; then confirm that number against the 79575002401 replacement information in the 79575002401 owner's manual.

How to identify the exact filter that fits 79575002401

Use these quick checks; they give you the exact cartridge without guessing between common Kenmore numbers.

• Read the part or model number printed on the existing water filter cartridge.
• If the old filter is missing, check the filter head or housing label inside the refrigerator.
• Confirm the refrigerator model tag shows 79575002401 (inside the fresh food compartment).
• Match the filter number you found to the replacement filter listing in the 79575002401 owner's manual.
• After installing the new filter, flush several gallons of water to clear air and carbon fines.

Common Kenmore filter numbers vs. the right way to match

Kenmore filter numbers like 9081, 9083, 9690, and 9890 are retail identifiers used across different manufacturers and refrigerator families. For model 79575002401, the correct match is the number on your filter or housing label, verified in the manual.

What you can check	Where to look	What to write down
Existing filter	Printed on the cartridge	Filter model/part number
Filter housing label	Near the filter head	Filter model/part number
Refrigerator ID tag	Inside fresh food section	79575002401

Water pressure and why it matters for filter fit and performance

A correct filter keeps water flowing properly to the dispenser and ice maker and helps protect the water valve screen from sediment. This model’s water system is designed for typical household cold-water pressure; the manual notes 40 to 120 psi on models with a water filter (and 20 to 120 psi on models without a water filter).

Last updated: February 2026

Water leaking from the bottom of your Kenmore 79575002401 bottom-mount refrigerator is usually caused by defrost water not reaching the drain pan (most often a clogged or frozen defrost drain) or a water supply leak to the icemaker/dispenser. We focus first on the defrost drain because it can overflow during defrost.

Quick checks we recommend (in order)

• Look for ice or standing water on the freezer floor or under the crisper drawers; this points to a defrost drain issue.
• Check the drain pan area underneath; during defrost you can hear water running into the pan, but it should not spill over.
• Inspect the water line connection if the unit has an icemaker; the manual notes water line installation details and leak risks.
• Check the door seal for gaps that can cause excess frost, which later melts and overwhelms the drain.
• Confirm the refrigerator is level; poor leveling can change how water flows to the drain.

Defrost drain clog or freeze-up (most common)

When the defrost cycle melts frost off the evaporator, water should flow down the drain to the pan. If the drain hole or drain tube is blocked by ice or debris, water backs up and can leak out at the bottom.

What to do

• Unplug the refrigerator.
• Remove the freezer drawer/bins as needed to access the drain area.
• Melt ice with warm water (turkey baster works well) and clear debris.
• Flush until water runs freely to the drain pan.

What you see	Most likely cause	What usually fixes it
Water under crisper drawers	Defrost drain restricted	Thaw and flush drain
Ice sheet on freezer floor	Drain frozen over	Thaw, then clear tube
Water near back/bottom with icemaker	Water line/tubing leak	Tighten/replace tubing

Water line or tubing leak (icemaker/dispenser models)

A slow drip from the supply connection, tubing, or fittings can pool and show up as a bottom leak. The water line section in the 79575002401 owner's manual also highlights installation precautions that help prevent water damage.

If you suspect tubing, inspect and replace damaged sections such as refrigerator water tubing 5210JA3005W when it is kinked, cracked, or leaking at a connection.

Why it matters

Bottom leaks can lead to floor damage and can also signal airflow or defrost problems that create heavy frost buildup. Fixing the drain or water line early helps the refrigerator cool consistently and prevents repeat leaks.

Last updated: February 2026
