Kenmore Elite 66513122K703 dishwasher Parts

Yes. We still support parts for many Kenmore dishwashers, including Kenmore Elite model 66513122K703. The key is matching parts by the full model number so you get the correct fit for items like spray arms, filters, drain hoses, and control components; confirm details in the 66513122K703 owner's manual.

How to make sure you order the right part

Use the model number 66513122K703 (from the rating label on the tub frame) and match the part by name and part ID.

• Search by the full model number, not just “Kenmore Elite” or “665 series”
• Match the part ID and part name (not only the part number)
• Compare your original part’s shape, ports, and mounting points
• If your symptom is performance-related, check maintenance items first (filter, spray arm)
• For electrical issues, shut off power at the breaker before inspecting anything

Common Kenmore Elite 66513122K703 parts customers replace

These are examples of parts available for this model that cover frequent dishwasher problems.

Symptom	Likely area	Example part for 66513122K703
Won’t drain or leaves water	Drain system	Dishwasher drain pump WPW10348269
Poor cleaning or no spray	Wash system	Dishwasher spray arm WPW10491331
Odor, debris, redeposit	Filtration	Dishwasher filter W10872845
Leaks at drain connection	Drain line	Dishwasher drain hose 8269144A

Why it matters

Kenmore dishwashers are built across multiple manufacturing platforms, so “Kenmore dishwasher parts” is not specific enough. Using 66513122K703 ensures the drain hose routing, pump connections, and rack components match your exact tub and wash system.

Helpful DIY reference

If you are troubleshooting a flashing light or a fault code, use our Kenmore 665 model dishwasher error codes guide to narrow the problem to the wash motor, drain circuit, heater, or control.

Last updated: February 2026

On Kenmore Elite dishwasher model 66513122K703, Control Lock turns off by pressing and holding HEATED DRY for 3 seconds until the LOCK ON light goes out. Once unlocked, the keypad works normally and you can start a cycle.

Quick unlock steps

• Make sure the dishwasher door is fully closed.
• Press and hold HEATED DRY for 3 seconds.
• Confirm the LOCK ON indicator light turns off.
• If you press a button while locked, the light typically flashes 3 times (that is normal).
• Start a cycle normally after unlocking.

If it still seems locked

These checks fix most “stuck in lock mode” complaints on this Kenmore control panel.

• Press and hold HEATED DRY again for a full 3 seconds (a short tap will not unlock).
• If the control is unresponsive, press CANCEL/DRAIN and let the 2-minute drain finish (door must be closed).
• Restore power by turning the breaker off for 1 minute, then back on.
• Try the unlock step again.
• If the panel remains dead, a blown thermal fuse is a common cause on many dishwashers; see fuse W10258275.

What “Control Lock” does (and does not do)

Feature	What you will see	What it means
Control Lock ON	LOCK ON light lit; buttons disabled	Prevents unintended button presses between cycles
Door operation	Door still opens/closes	Lock is for the controls, not the latch
Starting a cycle	Dishwasher will not run	You must unlock before START/RESUME works

Why it matters

Control Lock prevents accidental cycle changes and helps avoid a “dishwasher won’t start” situation caused by a locked keypad. For the exact button locations and indicator behavior on your model, use the 66513122K703 owner’s manual.

Last updated: February 2026

For a Kenmore Elite dishwasher, including model 66513122K703, we typically find the model number on the rating label around the door area. Open the door and check the inner door edge or the tub frame; the label is usually easy to spot once you know where to look. See the 66513122K703 owner’s manual for the exact label location and what the tag looks like.

Where to look on a Kenmore Elite dishwasher

Check these common spots in this order:

• Along the top or side edge of the inner door (visible when the door is open)
• On the tub frame near the door opening (left or right side)
• Behind the toe panel or kick plate area (lower front access area)
• On the side of the door itself (hinge side or latch side)
• On the right or left interior wall just inside the opening

What you are looking for on the label

The rating label usually includes several identifiers. Use the model number for parts lookup and the serial number for age and service history.

Label item	What it is used for	Example format
Model number	Ordering correct parts and diagrams	665.13122K703 (may appear with or without dots)
Serial number	Manufacturing date tracking, service	Letters and numbers
Electrical ratings	Installation and troubleshooting	Volts/amps/Hz

Why it matters

Kenmore Elite dishwashers often share similar styling across multiple 665-series models, but parts like the control panel, pump and motor assembly, and racks can vary by model. Using the exact model number helps us match the correct replacement parts the first time.

Last updated: February 2026

Kenmore model numbers are read in sections: the first 3 digits identify the manufacturer source, the middle digits identify the product platform and feature set, and the final characters identify version, color, or engineering changes. For your Kenmore Elite dishwasher model 66513122K703, matching the full model number ensures you get the correct parts and instructions.

Where to find the model number on a dishwasher

Most Kenmore dishwashers list the model and serial on a label located:

• Along the inner edge of the door (left or right side)
• On the tub frame opening (visible when the door is open)
• Near the top or side of the door liner
• Occasionally behind the toe panel area

For diagrams and model identification details tied to your unit, use the 66513122K703 owner’s manual.

How Kenmore model numbers are structured

Kenmore model numbers commonly follow this pattern:

• Prefix (first 3 digits): manufacturer source code
• Core model digits: series/platform and key design family
• Suffix (ending digits/letters): revision, finish, or configuration

Quick example (generic)

Section	What it tells you	Why you care
First 3 digits	Who built it for Kenmore	Helps match compatible parts families
Middle digits	Design platform/series	Narrows down assemblies (pump, sump, racks)
Last digits/letters	Version/config changes	Prevents ordering the wrong revision

Why it matters when ordering parts

Even small suffix differences can change fitment for common dishwasher parts such as:

• Drain components (pump, drain hose)
• Wash system parts (spray arm, filter)
• Door hardware (hinges, balance links)
• Controls (control panel, electronic control board)

If you are troubleshooting a drain issue on this model, the dishwasher drain pump WPW10348269 is one of the common repair parts tied to the drain system.

Why it matters

Using the complete model number (including the suffix) keeps you aligned with the correct Kenmore Elite 665 platform design, which reduces returns and speeds up repairs.

Last updated: February 2026

Yes, repairing a Kenmore Elite dishwasher like model 66513122K703 is usually worth it when the problem is a wear item or a single failed component and the total repair cost stays well below the price of a comparable new dishwasher. It is especially cost-effective when the unit is still within typical dishwasher life expectancy (about 10 years).

Quick way we decide: repair vs replace

Use these checkpoints before buying parts or scheduling service:

• Age: under ~10 years usually favors repair; over ~10 years depends on condition and repair cost
• Repair cost: if parts plus labor approach 50% of replacement cost, replacement often makes more sense
• Failure type: leaks, drain issues, and rack problems are often straightforward; multiple electronic failures are usually not
• Warranty coverage: this model’s manual describes extended coverage on certain systems (electronic control/power supply board and Ultra Wash wash system) and rack rust coverage; confirm your purchase date and coverage details in the 66513122K703 owner’s manual
• DIY comfort level: many dishwasher fixes are moderate DIY if you can safely shut off power and water

Common repairs that are often worth it on 66513122K703

These are frequent, fixable issues where replacing a specific part can restore normal operation:

• Not draining or standing water: check the drain path, then consider the dishwasher drain pump WPW10348269 or a drain hose
• Poor cleaning or weak spray: inspect and clean the filter and spray arm; consider the dishwasher spray arm WPW10491331
• Door won’t stay up or slams: the dishwasher door balance link 8194001 is a common wear item
• Intermittent power or dead unit: a blown fuse W10258275 can be the root cause

Cost and complexity snapshot

Repair type	Typical difficulty	Typical “worth it” scenario
Drain or hose issue	Low to medium	Unit otherwise runs normally
Spray/filtration issue	Low	Dishes come out dirty but cycles complete
Door balance/hinge issue	Medium	Door safety and usability problem
Control or motor system issue	Medium to high	Worth it mainly if newer or covered by warranty

Why it matters

A targeted repair can extend the life of your Kenmore Elite dishwasher, reduce downtime, and avoid the higher cost of replacement. Using the correct model-specific parts also prevents repeat failures and fit issues.

Last updated: February 2026

For Kenmore Elite dishwasher model 66513122K703, the installation guide lists the cabinet opening as 23-7/8 in. minimum width and 34 in. minimum height (measured from the lowest point under the countertop). The dishwasher depth is typically about 24-1/2 in.; confirm your exact fit using the 66513122K703 installation guide.

Model 66513122K703 size details (from the install guide)

Use these measurements when planning a replacement, checking a tight fit, or verifying a new countertop.

• Minimum cutout width: 23-7/8 in. (60.6 cm)
• Minimum cutout height: 34 in. (86.4 cm)
• Depth shown in product dimensions: 24-1/2 in. (62.2 cm)
• Height can be reduced: to 33-7/8 in. by removing rear wheels (tighter fit, harder to slide in)
• Measure height correctly: from the lowest point on the underside of the countertop

Quick reference table

Measurement	What it applies to	Value
Width	Cabinet opening (minimum)	23-7/8 in.
Height	Cabinet opening (minimum)	34 in.
Height (reduced)	With rear wheels removed	33-7/8 in.
Depth	Product dimension shown	24-1/2 in.

How we recommend measuring before you buy parts or install

• Measure the opening width at the narrowest point (front and back)
• Measure height from the underside of the countertop to the floor at the lowest spot
• Check for tile or built-up flooring that changes the height inside the opening
• Confirm there are no intrusions (pipes, wiring, brackets) in the cutout area
• Plan clearance so the motor and legs do not contact the floor

Why it matters

Dishwashers are designed to fit a standard 24-inch class opening, but small differences in cutout height, flooring, and wheel or leg position can prevent the unit from sliding in squarely or leveling correctly. Using the install guide dimensions helps avoid leaks, vibration, and door alignment issues.

Last updated: February 2026

Most Kenmore Elite dishwashers, including model 66513122K703, last about 10 years with normal household use. Consistent cleaning, correct loading, and fixing small issues early (like draining or drying problems) are what most often determine whether you reach or beat that typical lifespan.

What affects dishwasher lifespan the most

• Water quality (hard water speeds up mineral buildup in the sump, spray arms, and filter)
• Filter and sump cleanliness (clogs strain the pump and reduce wash performance)
• Drain performance (standing water can lead to odors and extra wear)
• Door sealing and venting (leaks and poor drying can create ongoing moisture issues)
• How often you run it (heavy daily use wears moving parts faster)

Maintenance that helps you get the full 10 years

Use these habits to reduce wear on the wash system (motor, pump, spray arms) and help prevent service calls:

• Clean the filter and check the sump area regularly; follow the steps in the 66513122K703 owner's manual.
• Rinse off labels, bones, toothpicks, and glass bits so they do not jam the pump.
• Keep the spray arms clear; remove debris from the holes so water pressure stays strong.
• Use the right detergent amount and run hot water at the sink before starting a cycle.
• If you see water left in the tub, inspect the drain path and consider the dishwasher drain pump WPW10348269 if draining is weak or noisy.

Common “end-of-life” symptoms vs. fixable issues

Symptom	Most common cause	Typical fix
Not draining	Clog, drain hose routing, failing drain pump	Clear blockage; check hose; replace pump if needed
Poor cleaning	Clogged filter, blocked spray arm, low water temp	Clean filter/spray arm; improve hot water supply
Won’t start	Door latch issue, power problem, blown fuse	Check latch and power; test/replace fuse
Leaking	Door seal/vent gasket wear, installation issues	Inspect seals; correct leveling and mounting

Why it matters

A dishwasher that is maintained and draining correctly runs with less strain on the pump and motor assembly, which is the most expensive system to repair. Following the care and troubleshooting guidance in the 66513122K703 owner's manual helps you avoid the failures that shorten lifespan.

Last updated: February 2026

Your Kenmore Elite dishwasher model number is printed on the rating label inside the door. Open the door and look along the inner edge of the tub opening (commonly on the left side); the label lists both the model number and serial number.

Where to look for the rating label

• Open the dishwasher door fully.
• Check the inner frame of the tub opening, not the outer decorative door.
• Look along the left side first; then check the right side if needed.
• Wipe the area with a damp cloth; soap film can hide the print.
• Use a flashlight and read the full model number exactly as shown.

What the model number looks like

For this Kenmore Elite series, the model number is a mix of numbers and letters. Here is a quick example of what you might see:

Item on label	What it’s used for	Example
Model number	Matching parts and diagrams	66513122K703
Serial number	Date/production tracking	Varies

Why it matters

We use the exact model number to match the correct parts (such as a drain pump, spray arm, or control board) and to pull the right procedures and specs from the documentation. One missing character can point to a different parts list.

Tips to avoid common mix-ups

• Copy the model number character-for-character (including any suffix).
• Do not use the number from the control panel styling or the “Elite” name; those are not the model.
• If the label is worn, take a close-up photo and zoom in.

For diagrams and model-specific details, use the 66513122K703 owner’s manual.

Last updated: February 2026

Kenmore Elite is a premium Kenmore product line that has been sold across multiple appliance generations rather than being “made” in a single year. For your Kenmore Elite dishwasher model 66513122K703, the most reliable way to place its timeframe is by using the model and serial information and the documentation in the 66513122K703 owner's manual.

How to identify the age of your 66513122K703 dishwasher

We use the model and serial number tag on the dishwasher to determine the production date range.

• Open the door and look along the inner door edge or tub frame for the model/serial label
• Write down the full serial number (not just the model)
• Compare the serial format to Kenmore 665-series dating charts (the prefix often indicates the manufacturer)
• Match features and control style to the diagrams and specs in the manual
• If you are ordering parts, always confirm using the full model number 66513122K703

What “Kenmore Elite” means (and why the year varies)

Kenmore Elite is a line name used on higher-feature Kenmore appliances (including dishwashers). That means the “Kenmore Elite” label spans many years, while your dishwasher’s exact build date is tied to its serial number.

Quick comparison

Term	What it tells you	Best use
Kenmore Elite	Product line tier	Feature expectations, styling
66513122K703	Exact dishwasher model	Correct parts and manuals
Serial number	Build date code	Determining manufacturing timeframe

Why it matters

Knowing the build timeframe helps us match the correct configuration for parts and service procedures, especially for items that can vary by revision such as the control panel, racks, and wash system components.

If you are troubleshooting performance or drainage issues while you are identifying the unit, common service parts for this model include the dishwasher drain pump WPW10348269 and the dishwasher filter W10872845.

Last updated: February 2026
