Kenmore 11062932100 dryer Parts

To hard reset your Kenmore dryer model 11062932100, we unplug the dryer (or switch the breaker off) for 1 to 5 minutes, then restore power and try starting a cycle again. This clears many temporary control glitches and restores normal operation.

Hard reset steps (safe and effective)

• Turn the Cycle Selector (timer) to OFF.
• Unplug the dryer from the wall outlet (or turn the dryer circuit breaker OFF).
• Wait 1 to 5 minutes.
• Plug the dryer back in (or turn the breaker ON).
• Close the door firmly.
• Select a timed cycle and press PUSH TO START.

For model-specific control locations and cycle details, use the owner's manual.

If the dryer still will not start after a reset

A “reset” will not fix an open safety circuit or a failed start component. Check these common causes next:

• Power supply issue: confirm the cord is firmly plugged in and the breaker is fully reset.
• Door not fully closed: opening the door stops the dryer; it will not restart until the door is closed and you press start again.
• Start switch problem: if the button feels loose or does nothing, the start switch can fail.
• Overheat protection tripped: restricted venting can overheat the dryer and open a safety fuse.
• Timer/control not set to a cycle: make sure the timer is on a drying cycle or air setting.

Quick part-to-symptom guide

Symptom	What it often points to	Example part for this model
No start, no motor sound	Start circuit issue	Dryer push-to-start switch WP3977456
Runs but no heat	Heating circuit issue	Dryer heating element WP3387747
No run after overheating/blocked vent	Safety fuse opened	Dryer thermal fuse WP3390719

Why it matters

A hard reset only clears a temporary interruption. If the dryer is overheating or a safety device has opened, the dryer can stop to prevent damage. Restoring airflow (lint screen and vent path) helps prevent repeat shutdowns.

You can order replacement parts for Kenmore 11062932100 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

Kenmore model numbers identify the exact design and parts list for your appliance; for Kenmore dryer model 11062932100, the full model number on the model and serial number plate is what we use to match the correct replacement parts and documentation. Use the complete number exactly as shown on the plate.

Where to find the model number on a Kenmore dryer

On Kenmore electric dryers like 11062932100, the model and serial number plate is the official source. Our owner's manual explains that you should record the complete model and serial numbers from this plate for future reference.

Common places to check on a dryer:

• Inside the door opening on the front panel
• On the door frame or cabinet opening
• On the back panel of the cabinet
• Near the lower front access area (behind the toe panel on some designs)

How Kenmore model numbers are structured (what the digits mean)

Kenmore model numbers typically include a prefix that points to the manufacturing source, followed by digits that identify the platform and feature set.

Key points that help when ordering parts:

• Use the full model number (all digits and any suffixes) to avoid mismatches
• A 3-digit prefix is common on many Kenmore appliances (often shown with a dot on some products)
• The remaining digits narrow down the exact configuration and production variation

Quick example table

What you see	What it tells us	Why it matters
Model number (full)	Exact product identity	Ensures the parts diagram matches your dryer
Prefix (first 3 digits)	Manufacturing source family	Helps separate similar-looking Kenmore designs
Remaining digits	Series and variation	Prevents ordering the wrong switch, heater, or timer

Why it matters for parts and troubleshooting

Dryers can look identical but use different heating circuits, controls, and drum support hardware. Using the correct model number helps us match parts like a heating element, thermal fuse, or idler pulley to your exact build.

If you are ordering parts for 11062932100, you can start with the parts list for this model, or search by model number on Sears PartsDirect.

Parts that commonly depend on the exact model match

These are examples of parts where the correct model number is critical:

• Dryer heating element WP3387747 (heating performance and wiring style)
• Dryer thermal fuse WP3390719 (safety cutoff temperature and mounting)
• Dryer idler pulley 279640 (belt routing and bracket alignment)

Last updated: February 2026

Most Kenmore dryers have a life expectancy of 10 to 13 years with normal household use. Your Kenmore 11062932100 can often reach the high end of that range when airflow is kept clear, lint is removed consistently, and worn drum support and heating parts are replaced as needed.

Typical lifespan and what changes it

A dryer’s service life is driven more by heat and airflow stress than by age alone.

• Longer life: clean venting, correct load sizes, stable power supply
• Shorter life: restricted exhaust, frequent overheating, heavy daily use
• Most common wear items: drum support rollers, idler pulley, thermal fuse, heating element
• Best reference for care: follow the maintenance and safety guidance in the 11062932100 owner's manual

Maintenance checklist that extends dryer life

We recommend these habits for Kenmore electric dryers like model 11062932100:

• Clean the lint screen after every load (replace if the mesh is damaged)
• Inspect and clean the vent duct regularly; keep the run short and unobstructed
• Avoid overloading; it strains the drive motor and drum support system
• If drying times increase, address airflow first before replacing heating parts
• Fix squealing or thumping early to prevent drum and bulkhead wear

Parts that commonly affect longevity (and symptoms)

Symptom	Likely wear area	Example part for this model
Loud thumping or rumbling	Drum support rollers	Support kit WPW10314173
Squealing, drum not turning smoothly	Belt tension system	Dryer idler pulley 279640
No heat or heat cuts out	Heating and safety circuit	Dryer heating element WP3387747, dryer thermal fuse WP3390719

Why it matters

A dryer that runs hot because of poor airflow can trip safety devices and shorten the life of the heating element, motor, and wiring. Keeping venting clear and replacing small wear parts early usually costs less than major repairs later.

If you’re planning a repair, you can order replacement parts for Kenmore 11062932100 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

For Kenmore dryer model 11062932100, replacing the heating element typically costs $70 to $120 for the part plus any supplies; with professional labor, the total commonly lands around $200 to $400 depending on local rates and whether additional heat-related parts are replaced at the same time. See the owner's manual for safety and operating guidance.

Typical cost breakdown (11062932100)

• Heating element part: $72.99 for the dryer heating element WP3387747
• Optional wiring/terminals (recommended if connections look heat-damaged): $10.42 for the dryer heating element wire kit 279457
• Service call and labor (if you hire it): commonly $120 to $300
• Extra parts sometimes needed (only if testing shows a failure): thermal fuse, thermistor, or thermal cut-off kit

Cost item	Typical range	Notes
Heating element (part)	$70 to $120	Model-specific pricing varies; this model’s element is listed above.
DIY supplies	$0 to $25	Screws, connectors, vacuuming lint while open.
Professional labor	$120 to $300	Depends on access, diagnosis time, and local rates.
Total (DIY)	$70 to $145	Part plus supplies.
Total (pro repair)	$200 to $400	Part plus labor; more if multiple parts are replaced.

When the heating element is not the only cost

If the dryer is not heating, we check airflow and heat-safety parts first because restricted venting can overheat the heater circuit and blow safety devices.

Common add-on parts for “no heat” symptoms:

• Dryer thermal fuse WP3390719 (dryer runs but won’t heat on many builds)
• Dryer thermistor WP8577274 (temperature sensing issues)
• Cut-off kit 279769 (heat safety cut-off components)

Why it matters

A new heating element can fail early if the vent is clogged or the blower area is packed with lint. Restoring proper airflow helps the heater, thermostats, and wiring run cooler and last longer.

Ordering the correct part

We recommend ordering by model number 11062932100 to match the correct heater style and terminals. You can order the parts listed for this model, or search by model on Sears PartsDirect.

Last updated: February 2026
