On Whirlpool side-by-side refrigerators like model ED20TKXDW03, the defrost timer is typically mounted in the control housing (fresh food section) or behind the lower front toe grille near the condenser area. Once you locate it, it’s usually held by a small bracket and two mounting screws.

• Fresh food control console: up in the ceiling area where the temperature controls are.
• Behind the toe grille: at the bottom front of the refrigerator.
• Rear service area: near the compressor compartment on some builds.
• Near the thermostat/control area: if your unit uses a mechanical control layout.

A defrost timer is usually a small rectangular module with a dial or a recessed shaft you can turn with a flat screwdriver.

• Unplug the refrigerator before removing panels.
• If you remove the toe grille, look for a small component mounted to a metal plate.
• If you remove the control console cover, support it so wiring is not strained.
• Take a quick photo of wire positions before disconnecting anything.

For ED20TKXDW03, the defrost timer shown in the parts list is the refrigerator defrost timer W10822278.

If the timer sticks, the refrigerator can stop defrosting (leading to frost buildup and warm temperatures) or get stuck in defrost (leading to no cooling). Finding the timer location quickly helps you confirm whether the issue is in the defrost system versus the evaporator fan or thermostat.
