Kenmore Elite 66513763K602 dishwasher Parts

The exact decibel (dBA) rating depends on the specific Kenmore Elite model; for 66513763K602, the published sound rating is listed in the specifications section of the 66513763K602 owner's manual. That spec is the correct number to use when comparing noise levels across dishwashers.

Look for “Sound level,” “Noise level,” or “dBA” in the model specifications.

• Open the 66513763K602 owner's manual
• Check the “Specifications” or “Features” pages
• Confirm the model tag on the tub frame matches 66513763K602
• Use the published dBA value (not a phone app reading) for accurate comparisons

Lower dBA is quieter; a small change can be noticeable in an open kitchen.

If your 66513763K602 suddenly sounds louder, the issue is usually mechanical or related to installation fit.

• Make sure no utensil or tall item is hitting a spray arm
• Clean the filter area and remove debris from the sump
• Verify the toe panel is installed and secured
• If noise comes with poor draining, check the dishwasher drain pump WPW10348269

Using the published dBA rating helps you compare models accurately and gives you a baseline; if your dishwasher’s sound changes significantly, it points to a correctable problem such as a blockage, loose component, or pump issue.

Last updated: January 2026

For the Kenmore Elite dishwasher model 66513763K602, a hard reset is typically done by canceling the current cycle and restoring power to clear the control. This resets the electronic control and often clears a stuck cycle, keypad glitch, or non-start condition.

• Press Cancel/Drain (or Cancel) once; close the door and let the dishwasher run the drain for about 1 to 2 minutes.
• Turn OFF power to the dishwasher at the breaker (or unplug it if accessible).
• Wait 3 minutes.
• Restore power.
• Select a normal cycle and press Start/Resume, then close the door.

Some Kenmore 665-series dishwashers support a keypad reset sequence (often involving Heated Dry and High Temp). The exact sequence and indicator behavior varies by console style, so we recommend following the model-specific steps in the 66513763K602 owner's manual.

• Door not latching: Make sure the door closes firmly and the latch engages.
• Water supply: Confirm the shutoff valve is open and the fill hose is not kinked.
• Drain issue: If water remains in the tub, inspect the drain path; a failing dishwasher drain pump WPW10348269 can prevent proper draining.
• No power symptoms: If the dishwasher is completely dead, a blown fuse W10258275 is a common cause.
• Control problems: If lights behave erratically or cycles will not start, the dishwasher electronic control WPW10084141 may be involved.

A proper hard reset clears temporary control faults without replacing parts, and it helps you confirm whether the issue is a one-time glitch or a repeatable failure tied to draining, filling, or the electronic control.

Last updated: January 2026

On Kenmore Elite model 66513763K602, the F4E1 service code points to a wash (circulation) motor or pump problem, meaning the dishwasher is not moving water through the spray arms correctly. After correcting the cause (often a failed motor/pump), clear the code using the reset steps in the 66513763K602 owner's manual.

• Dishes come out dirty because spray arms are not getting strong water flow
• Little to no wash sound during the wash portion of the cycle
• Cycle may stop and display the code again
• Standing water can remain if the unit never washes properly

1. Power reset: Turn off the breaker for 1 minute, then restore power.
2. Confirm water supply: Make sure the shutoff valve is fully open and the fill is normal.
3. Check for wash blockage: Verify spray arms spin freely and are not clogged.
4. Look for sump debris: Food or broken glass in the sump area can restrict circulation.

If the checks above do not restore normal washing, these model-matched parts are the most common fixes:

Many Kenmore 665-series dishwashers clear stored service codes by pressing any 3 keys in a repeating 1-2-3 pattern three times (1-2-3, 1-2-3, 1-2-3). Use the exact key sequence and timing shown in the 66513763K602 owner's manual.

F4E1 is a wash-performance fault; if the circulation system is not moving water, detergent cannot dissolve and spray coverage drops fast. Fixing the underlying pump or motor issue prevents repeat errors and restores cleaning.

Last updated: January 2026
