Kenmore 66513543N410 dishwasher Parts

To tell what model Kenmore dishwasher you have, look for the model and serial number label on the tub opening area when you open the door. For your dishwasher, the model number format will match 66513543N410 (often shown as 665.1354* with a color code). See the label location diagram in the 66513543N410 use & care manual.

Where to find the model number label

On Kenmore dishwashers like model 66513543N410, the label is typically in one of these spots:

• Along the inner door frame (left or right side)
• On the tub rim near the latch area
• On the tub wall just inside the door opening
• Occasionally on the side of the tub opening near the hinges

What the model number should look like

Kenmore dishwasher model numbers are usually a mix of numbers and sometimes a dot.

What you see on the label	What it means	Example for this model
3-digit prefix	Manufacturer platform identifier	665
Middle digits	Series/design family	1354
Suffix	Version and color code	N410 (varies by unit)

If your label shows 665.1354*, the characters after that (often a color code) help identify the exact version.

Tips to avoid ordering the wrong part

Use the full model number exactly as printed on the label before choosing parts.

• Copy every character, including letters and numbers
• Include any suffix (such as N410) if it appears
• Use the model number (not the serial number) for parts lookup
• If the label is worn, take a clear photo with the door open and good lighting

Why it matters

Kenmore dishwashers can look identical across multiple model variations, but internal parts like the door seal, drain pump, or spray arm can differ by model and suffix. Using the exact model number helps ensure the replacement part fits and functions correctly.

Last updated: January 2026

On Kenmore dishwasher model 66513543N410, you can force a drain by canceling the current cycle: open the door slightly to stop the wash action, then press and hold START/RESUME for 3 seconds to start the Cancel/Drain sequence. Close the door to begin draining. See the steps in the 66513543N410 use & care manual.

Steps to force a drain (Cancel/Drain)

• Open the door slightly to pause the cycle; wait for spraying to stop.
• Press and hold START/RESUME for 3 seconds.
• Close the door within 3 seconds; the drain will not start until the door is closed.
• Let the dishwasher run the drain; the Cancel/Drain light typically turns off after about 2 minutes.
• If water remains after draining, check for a drain restriction (next section).

If it still will not drain

These checks apply to 66513543N410 and most Kenmore 665-series dishwashers:

• Verify the cycle is actually complete; if not, press START/RESUME and close the door.
• If connected to a garbage disposer, confirm the disposer inlet knockout plug was removed.
• Check the drain hose for kinks or a sag that traps water.
• Check for food blockage in the disposer or sink drain connection.
• Remove and clean the Ultra Wash filters in the bottom center of the tub.

Quick troubleshooting guide

What you see	Most likely cause	What to do next
Cancel/Drain runs but tub stays full	Drain path blocked	Check hose, disposer inlet, sink connection
Humming during drain	Pump trying but restricted	Clean filters and check for blockage
No drain sound at all	Drain pump not running	Inspect wiring and consider replacing the dishwasher drain pump WPW10348269

Why it matters

Forcing a drain clears standing water so odors do not build up, prevents re-depositing soil on dishes, and helps you confirm whether the issue is a simple blockage (filters or hose) versus a drain pump problem.

Last updated: January 2026

To hard reset your Kenmore dishwasher model 66513543N410, we recommend doing a full power reset first (turn power off at the breaker for 5 minutes, then restore power). If the control is still glitchy, cancel and drain the current cycle per the 66513543N410 user manual.

Hard reset steps for model 66513543N410

1. Turn off power at the circuit breaker (preferred over unplugging).
2. Wait 5 minutes to fully discharge the control.
3. Restore power.
4. Clear the current cycle: press and hold START/RESUME for 3 seconds to activate CANCEL/DRAIN.
5. Close the door so the drain can run; let it finish.

If it still will not start after the reset

These checks are specific to how this Kenmore design behaves:

• Make sure the door is fully latched; if the Start/Resume light is blinking, press START/RESUME and close the door within 3 seconds.
• Confirm Control Lock is off; on this control style, press and hold SANI RINSE for 3 seconds to toggle Lock.
• Verify the dishwasher has power (breaker not tripped).
• If the unit is full of water, let CANCEL/DRAIN complete before trying a new cycle.
• If the dishwasher drains poorly even after a reset, inspect the drain path; a failing drain pump can also cause “stuck” behavior (see dishwasher drain pump WPW10348269 if you’re diagnosing a drain issue).

What each “reset” does (quick comparison)

Reset type	What you do	What it helps
Power reset (hard reset)	Breaker off 5 minutes	Control glitches, frozen keypad, odd lights
Cancel/Drain	Hold START/RESUME 3 seconds	Stops a cycle, drains standing water
Control Lock toggle	Hold SANI RINSE 3 seconds	Buttons not responding because controls are locked

Why it matters

A true hard reset clears temporary control-board faults and gets the dishwasher back to a known starting state. Following it with Cancel/Drain prevents a half-finished cycle or leftover water from causing more error symptoms.

Last updated: January 2026

For Kenmore dishwasher model 66513543N410, replacement parts are typically manufactured by the original equipment manufacturer (OEM) that built the dishwasher for Kenmore. In practice, many 665-prefix Kenmore dishwashers are Whirlpool-built, so you will often see Whirlpool-branded components listed as compatible.

How to confirm the correct manufacturer for your exact part

The most reliable way is to match by model number and then verify the part number/part ID for the component you need.

• Use the model number 66513543N410 to filter compatible parts
• Match the part by part name and part ID (not just a description)
• Compare any “replaces” numbers shown for cross-references
• Use diagrams and instructions in the 66513543N410 use & care manual
• For installation-related questions (wiring, drain hose routing, leveling), use the 66513543N410 installation instructions

Examples of OEM-style parts you may see for this model

Because this model’s compatible parts list includes many Whirlpool-labeled components, it is common to see Whirlpool as the manufacturer on individual replacement parts.

What you’re replacing	Example compatible part for this model	What it does
Door sealing surface	Dishwasher door seal W11177741	Helps prevent leaks around the door opening
Filling system component	Dishwasher water inlet valve W11175771	Controls water flow into the dishwasher
Draining component	Dishwasher drain pump WPW10348269	Pumps water out during drain portions of the cycle

Why it matters

Kenmore is a brand name used across multiple manufacturers. Knowing the OEM behind a specific part helps you avoid ordering a look-alike that does not fit, seal, or connect correctly on 66513543N410.

Last updated: January 2026

Kenmore dishwasher issues we see most often on model 66513543N410 are poor cleaning, water not draining, leaks, and “won’t start” symptoms. Many of these trace back to loading, filter maintenance, or a few serviceable components like the spray arms, door seals, or inlet valve (see the 66513543N410 use & care manual).

Most common symptoms (and what usually causes them)

• Not cleaning well (grit, spots, residue): clogged filters, blocked spray arm holes, low water temperature, or detergent/rinse aid issues.
• Water left in the tub: drain hose kink/plug, disposer knockout plug not removed, or a weak drain pump.
• Leaks at the door or corners: worn door seals, lower door seal, or a tub gasket not sealing.
• Won’t start or stops mid-cycle: door not latched, control lock enabled, or a control problem.
• Not drying: rinse aid empty, Heated Dry not selected, or plastic items holding water.

Quick checks we recommend first (no parts needed)

1. Confirm the door latches fully and the Control Lock is off.
2. Run hot water at the sink until it’s hot before starting; this model is designed around hot incoming water.
3. Clean the ULTRA WASH filters monthly (more often with hard water or heavy soil).
4. Inspect spray arms for clogs and make sure tall items are not blocking rotation.
5. Use rinse aid and consider Heated Dry for better drying.

When a part is the likely fix

Symptom	Common part to inspect on 66513543N410	Why it matters
Leaking from the door	Dishwasher door seal W11177741	A flattened or torn seal lets water escape during wash.
Not draining	Dishwasher drain pump WPW10348269	A weak pump may leave water in the sump after drain.
Poor cleaning	Dishwasher spray arm, lower W10849471	Clogged or damaged spray arms reduce wash pressure.
Not filling well	Dishwasher water inlet valve W11175771	Low fill can cause weak spray and poor results.

Why it matters

Catching these problems early helps prevent repeat wash cycles, water damage from leaks, and premature wear on the pump and motor system.

Last updated: January 2026
