Samsung RSG307AARS/XAA-01 refrigerator Parts

For the Samsung RSG307AARS side-by-side refrigerator, the most common issues are ice maker and dispenser problems, warm temperatures from airflow or fan failures, water leaks from drain or tubing issues, and door closing or sealing problems. We use the troubleshooting steps in the owner's manual to pinpoint the cause.

• Not making ice or slow ice production: ice maker fault, frozen fill path, low water flow, or dispenser door not sealing
• Warm fridge or freezer: evaporator fan not running, condenser fan problem, dirty condenser area, or temperature sensor issue
• Water leaking or puddles: clogged/iced defrost drain, cracked drain tray, or loose water tube fitting
• Noisy operation: condenser fan blade hitting, failing fan motor, or compressor start components
• Door not closing well: worn closer/cam, hinge alignment, or door switch/door magnet issues

If your symptom matches, these model-compatible parts are often involved:

• Confirm temperature settings; allow 24 hours after changes
• Make sure vents inside the fridge/freezer are not blocked by food packages
• Listen for the evaporator fan with the door closed (door switch held in)
• Inspect the ice chute area for frost buildup that prevents sealing
• Check for water line kinks and verify strong water flow at the dispenser

These issues affect food safety, ice and water performance, and energy use. Catching a weak fan, a leaking drain path, or a door that does not seal early helps prevent bigger cooling and moisture problems.

Last updated: March 2026

A Samsung side-by-side refrigerator like model RSG307AARS typically lasts 13 years with normal household use. Lifespan depends most on condenser airflow, door seal condition, and how hard the ice maker and compressor have to work.

Most refrigerators reach their full service life when they can cool efficiently and run without overheating.

• Keep the condenser area clean so heat can dissipate properly
• Make sure doors close and seal tightly to prevent long run times
• Replace clogged water filtration components on schedule (if equipped)
• Avoid overpacking; it blocks air circulation in the fresh food and freezer sections
• Address unusual noises early (fan, auger, or compressor strain)

Use these routine steps and the maintenance guidance in the owner's manual.

If cooling is inconsistent, ice production stops, or you hear repeated clicking at the back, a targeted repair often restores performance.

Common parts involved on this model include:

• Samsung refrigerator compressor MKV190CL2BASH (sealed system cooling)
• Refrigerator condenser fan DA31-00146B (moves heat off the condenser)
• Refrigerator electronic control board DA92-00175B (manages cooling and defrost)

A refrigerator near end-of-life often runs longer and warmer, which can spoil food and increase energy use. Basic airflow and sealing maintenance reduces stress on the compressor and fans, which are the highest-impact components.

Last updated: March 2026

The Samsung RSG307AARS side-by-side refrigerator has a total capacity of about 28.5 cu. ft., with about 8.8 cu. ft. in the freezer. For the exact breakdown for your unit and configuration, confirm the specs in the RSG307AARS owner's manual.

Capacity is the usable interior volume; it helps you compare storage space across refrigerators.

• Total capacity includes both fresh food and freezer sections.
• Freezer capacity is the freezer compartment volume.
• Fresh food capacity is typically the remainder (total minus freezer).
• Shelves, bins, and the ice maker can slightly reduce usable space.

Capacity affects day-to-day fit for groceries, frozen foods, and ice storage. It also helps when you are comparing replacement parts (like an ice maker) or planning kitchen layout and food storage.

If ice storage or ice production is a concern (which can affect perceived freezer space), use our troubleshooting steps in why your Samsung fridge stopped making ice and how to fix it.

Last updated: January 2026
