Kenmore Elite 79579022310 refrigerator Parts

Kenmore Elite refrigerator model 79579022310 is a bottom-mount style in the Kenmore Elite 795.7902 model family; its exact exterior dimensions are listed in the 79579022310 owner's manual. Most 33-inch-wide bottom-mount units in this series are roughly 33 inches wide, 30 to 34 inches deep, and 67 to 70 inches tall.

How to confirm the exact dimensions for 79579022310

Use the dimensions and clearance guidance in the 79579022310 owner's manual, then measure your opening:

• Measure the cabinet opening width at the front and back.
• Measure height to the lowest overhead cabinet or soffit.
• Measure depth from the back wall to the front edge of the countertop.
• Include door swing and handle clearance in front.
• Confirm you have a nearby water supply if you use the ice maker.

Space and clearance guidelines (from the manual)

The manual calls out installation clearances that affect the “real-world” space you need:

• Allow at least 33 3/4 inches in front to open the doors.
• Allow at least 2 inches between the back of the refrigerator and the wall.
• Install where ambient temperature stays roughly 55°F to 110°F.
• Water pressure should be 20 to 120 psi (no filter) or 40 to 120 psi (with filter).

What you are sizing for	What to include	Why it matters
Width	Cabinet opening plus wiggle room	Prevents rubbing and vibration noise
Depth	Case depth plus door swing	Ensures drawers and doors open fully
Height	Case height plus leveling	Keeps doors aligned and seals tight

Why it matters

Getting the size right prevents door interference, poor airflow, and higher energy use. It also helps avoid water line kinks and makes it easier to remove doors/handles if you need to move the refrigerator through a tight opening.

Last updated: January 2026

On Kenmore Elite refrigerator model 79579022310, DH typically indicates a defrost heater (defrost heating) problem. In most cases, it means the refrigerator is not heating properly during the defrost cycle, so frost can build up and restrict airflow, leading to warm temperatures.

What you’ll usually notice when DH shows up

• Refrigerator section warming up even though the freezer seems cold
• Frost or ice buildup on the rear freezer panel
• Fan noise changing (fan hitting ice) or reduced airflow from vents
• Longer run times and inconsistent temperatures
• Ice maker performance issues due to poor cooling

Quick checks we recommend first

Before testing parts, do these simple steps to rule out common causes:

• Power reset: unplug for 2 minutes, then restore power and monitor for 24 hours
• Door seal and door closing: confirm doors fully close and gaskets seal all the way around
• Airflow: make sure vents are not blocked by food packages
• Condenser cleaning: vacuum dust from the condenser area to improve cooling efficiency
• Temperature settings: return to normal setpoints if they were changed recently

What usually causes a DH (defrost heat) issue

A DH code is most often tied to the defrost circuit. Common culprits include:

• Defrost heater not heating
• Defrost thermostat or temperature sensor reading incorrectly
• Wiring connection issue in the defrost circuit
• Control board not sending power to the heater

Common parts involved (examples for this model)

Symptom	Likely area	Example part on this model
Frost buildup, weak airflow	Evaporator area	Lg refrigerator evaporator fan motor 4681JB1027C
Temps fluctuate, defrost timing seems off	Sensor feedback	Refrigerator temperature sensor 6500JB2002X
Unit not cooling well overall	Sealed system control	Refrigerator electronic control board CSP30020817

Why it matters

When the defrost heater system is not working, frost can blanket the evaporator coil and block airflow. That forces the compressor and fans to run longer, raises food temperatures, and can lead to repeated cooling complaints.

Where to confirm the exact code meaning and diagnostics

We recommend using the troubleshooting and diagnostics section in the 79579022310 owner's manual. For display codes specific to Kenmore 795 bottom-freezer models, use Kenmore 795 model bottom freezer refrigerator error codes.

Last updated: January 2026

Water leaking from the bottom of your Kenmore Elite refrigerator model 79579022310 is usually caused by a clogged defrost drain (water backs up and spills), a leak in the dispenser or water supply tubing, or a problem in the sealed-system area that creates excess moisture. Use the steps below to pinpoint the source, then correct it.

Quick checks to find the leak source

• Look at the water location: front center, under the freezer drawer, or back by the wall.
• Check the ice maker and dispenser use: leaks that appear after dispensing often point to the water line or valve.
• Inspect the freezer floor: a sheet of ice under the bottom basket often indicates a defrost drain issue.
• Check the door gaskets: warm air leaks can create heavy frost that later melts and overflows.
• Confirm the unit is level: a nose-down tilt can encourage water to run out the front.

Most common causes (and what to do)

Likely cause	Typical clue	What we recommend
Clogged defrost drain	Water under crisper drawers or ice under freezer basket	Clear the drain path and flush with hot water (after unplugging).
Cracked/loose water tubing	Drips near left front or under hinge area	Inspect tubing connections; reseat or replace damaged line sections.
Water inlet valve leaking	Puddle appears even when not dispensing	Test for seepage; replace the valve if it weeps.
Evaporator/fan area icing then melting	Frost buildup, warm temps, water later	Check airflow and fan operation; address icing cause.

Model-specific notes that matter

Your 79579022310 uses a plumbed water supply; the 79579022310 owner’s manual includes water line connection guidance and cautions about plumbing issues like water hammer that can contribute to leaks. Keeping the supply line stable and connections tight helps prevent recurring puddles.

Parts that commonly fix bottom leaks

If your checks point to the water supply side, these model-matched parts are common solutions:

• Lg refrigerator water inlet valve AJU73753101 (leaking or not closing fully)
• Refrigerator filter dryer ADH73150208 (sealed-system service item; technician-level repair)

Why it matters

Water leaks can damage flooring and also lead to ice buildup that blocks airflow, causing warm refrigerator temperatures and poor ice production. Fixing the leak source early protects the evaporator area, fan airflow, and food temperatures.

Last updated: January 2026

Common problems on the Kenmore Elite 79579022310 bottom-mount refrigerator include weak or no cooling, frost buildup, water leaks, ice maker issues, and unusual noises. Most fixes start with airflow and temperature checks, then move to components like the evaporator fan, water inlet valve, or compressor.

Most common symptoms and what usually causes them

• Not cooling or warm temperatures: dirty condenser area, failed evaporator fan motor, temperature sensor issue, or sealed system/compressor problem
• Frost or ice buildup (freezer or back wall): door not sealing, frequent door openings, or a defrost system problem
• Water leaking or puddles: clogged defrost drain, loose water line connection, or valve seepage
• Ice maker not making ice: low water pressure, frozen fill tube, bad inlet valve, or ice maker assembly failure
• Buzzing, clicking, or humming: condenser fan area obstruction, compressor start/overload issue, or compressor wear

Quick checks we recommend before replacing parts

1. Confirm settings: freezer near 0°F and fresh food near 37°F (allow 24 hours after changes).
2. Check door sealing: look for gaps, torn gasket areas, or doors not closing fully.
3. Listen for fans: evaporator fan should run during cooling; condenser fan should run when the compressor runs.
4. Inspect for frost patterns: heavy frost on the evaporator cover often points to airflow or defrost trouble.
5. Check water supply (for ice/water issues): verify the shutoff valve is fully open and the line is not kinked.

Parts that commonly solve these problems on model 79579022310

Symptom	Likely part area	Example part for this model
Warm fridge/freezer	Air circulation	Lg refrigerator evaporator fan motor 4681JB1027C
No ice or slow fill	Water supply control	Lg refrigerator water inlet valve AJU73753101
Clicking at compressor	Start/overload protection	Refrigerator compressor overload protector 6750CL0001D
Loud running, no cooling	Sealed system	Refrigerator compressor TCA38091801

Why it matters

Catching airflow, frost, and water-supply problems early helps protect food, reduces strain on the sealed system, and can prevent repeat failures (especially when a fan or drain issue forces the compressor to run nonstop).

Model-specific help from the manual

Your refrigerator includes Kenmore Connect diagnostics and a troubleshooting guide; we recommend following the steps in the 79579022310 owner’s manual to narrow the failure to a fan, sensor, ice maker, or sealed system issue before ordering parts.
