Kenmore 10689593102 freestanding ice maker Parts

For Kenmore model 10689593102 (freestanding ice maker), the model number is the exact identifier we use to match the correct parts list and manual. On most Kenmore appliances, the first 3 digits are a manufacturer prefix, and the remaining digits identify the specific design and version.

Check these common locations first:

• On the cabinet side wall behind the front kickplate or lower access panel
• On the back of the cabinet near the power cord
• Inside the bin area on a rating label (near the door opening)
• On the side wall near the condenser area (varies by design)

For label location diagrams and exact wording, use the 10689593102 owner's manual.

Kenmore model numbers are typically structured like this:

• Prefix (first 3 digits): identifies the original manufacturer (who built it for Kenmore)
• Core model digits: identify the platform or series
• Suffix/version digits: identify revisions, finishes, or production changes

Using the full model number prevents ordering a part that looks similar but will not fit or function correctly. This is especially important for ice maker components that vary by revision, such as:

• Water filtration components like the water filter F2WC9I1
• Water circulation components like the ice maker recirculation pump W11542867
• Electrical components like the ice maker electronic control board W11034363

• Copy the model number exactly as printed (include all digits)
• If a serial number is nearby, record it too (helps confirm production range)
• Match the model number on the label to the one used for your parts list: 10689593102

Last updated: February 2026

To replace the ice maker in your Kenmore freestanding ice maker model 10689593102, we remove power, access the ice maker assembly, disconnect the wiring and water connections, then transfer any reusable brackets or sensors to the replacement. Use the 10689593102 owner’s manual for the exact access and fastener locations.

• Unplug the ice maker (or switch off the dedicated breaker).
• Turn off the water supply valve feeding the unit.
• Empty the ice bin and dry up any standing water.
• Protect the floor; keep towels handy.
• Take a quick photo of wire connectors and hose routing before disconnecting.

1. Pull the unit forward enough to access the rear and side panels.
2. Remove the panel(s) needed to reach the ice maker assembly (keep screws organized).
3. Disconnect the ice maker wiring harness plug(s).
4. Disconnect the water line or recirculation hose feeding the ice maker section.
5. Remove the mounting screws and slide the ice maker assembly out.
6. Move any brackets, grommets, or insulation pieces from the old assembly to the new one.
7. Reinstall the new assembly, reconnect hoses and wiring, then reinstall panels.
8. Turn water back on, restore power, and run a test cycle.

If you are replacing the “ice maker” because it stopped producing ice, these model-specific parts are frequent culprits:

Correctly routing hoses and fully seating wire connectors prevents leaks, short cycling, and weak ice production. Using the manual’s panel removal and connector locations also reduces the chance of damaging insulation or harness clips.

Last updated: February 2026

For Kenmore model 10689593102 (a freestanding ice maker), the most reliable reset is a power reset: turn the unit off and unplug it for about 5 minutes, then restore power and allow one full ice-making cycle. If ice still does not produce, focus next on water supply and filtration.

• Turn the ice maker OFF.
• Unplug the unit (or switch off the breaker) for 5 minutes.
• Plug back in and turn the unit ON.
• Wait for the unit to refill and start circulating water.
• Allow 60 to 120 minutes for the first batch, depending on room and water temperature.

For model-specific control locations and cycle details, follow the 10689593102 owner's manual.

Most “needs a reset” complaints are actually a water flow or circulation issue. Check these common causes:

• Water supply valve is not fully open.
• Kinked or pinched inlet line behind the unit.
• Clogged or overdue water filter F2WC9I1 (restricted flow can stop or slow production).
• Low water pressure to the appliance.
• Poor water circulation inside the unit (possible pump issue).

A reset clears a stalled control state, but it will not fix a blocked water path. Restoring proper water flow (filter, line, pressure) prevents repeat shutdowns and helps the Kenmore ice maker maintain normal cube size and harvest timing.

Last updated: February 2026

Yes, replacing the ice maker is usually worth it when the refrigerator is in good overall condition and the problem is isolated to the ice-making system; for Kenmore model 10689593102 (a freestanding ice maker), it is often even more cost-effective to replace a failed component like a pump, control board, or water filter instead of replacing the entire unit. Use the 10689593102 owner's manual to confirm the correct diagnostics and access steps.

• The unit cools normally and only ice production is affected.
• The repair is limited to a common wear part (filter, pump, cutter grid).
• No repeated water leaks or ongoing drain issues.
• The cabinet and door seal are in good shape.
• You can complete basic troubleshooting safely (power off, water off).

Before you commit to a major repair, we recommend checking these items first because they commonly stop ice production:

• Replace the water filter F2WC9I1 if flow is slow or the filter is overdue.
• Verify the water supply valve is fully open and the inlet line is not kinked.
• Clean dust from the condenser area to improve cooling performance.
• Check for scale buildup in the water path (hard water can reduce circulation).
• Confirm the bin is seated correctly and the unit is level.

On model 10689593102, these parts are typical “fix it” items when symptoms match:

• Ice maker recirculation pump W11542867: weak or no water circulation over the evaporator.
• Ice maker drain pump W11542868: standing water in the reservoir or poor draining.
• Ice maker electronic control board W11034363: dead unit, erratic cycles, or no response.
• Grid-assy, 2 W10919199: slab ice not cutting cleanly.

A targeted repair restores ice production without the cost and hassle of replacing the entire appliance; it also prevents secondary problems like pump damage from restricted water flow or poor draining.

Last updated: February 2026

Your Kenmore model 10689593102 is a freestanding ice maker, not a refrigerator, so “fridge size” and “storage capacity” do not apply the same way. To get the correct cabinet dimensions and clearances for your unit, use the specs listed in the 10689593102 owner’s manual.

For a freestanding ice maker, size usually means outside dimensions plus the space it needs to breathe.

• Measure width, height, and depth of the cabinet (front to back)
• Include door/handle swing space in front
• Allow airflow clearance around the unit (especially near the condenser area)
• Confirm water line and drain routing space (if used)
• Verify the unit is level so the door seals and ice production stay consistent

Use a tape measure and record in inches.

The common “multiply dimensions then divide by 1728” approach is used to estimate interior volume for box-shaped spaces, but an ice maker’s usable space is mainly the ice bin capacity and internal components, not refrigerator-style storage.

If you are checking size because the unit is not making enough ice, these items often matter more than cabinet volume:

• Replace the water filter F2WC9I1 on schedule
• Clean dust from the condenser area so it can shed heat
• Confirm water supply is fully open and not kinked
• Make sure the unit is level and the door closes tightly

Last updated: February 2026

Kenmore model 10689593102 is made by Whirlpool. On Kenmore appliances, the first three digits of the model number identify the manufacturer; the 106 prefix is a Whirlpool-built unit. For model-specific details, we recommend checking the 10689593102 owner's manual.

You can verify the maker by reading the first three digits of the Kenmore model number.

• Find the full model number on the rating label (inside the cabinet or on the side/back panel)
• Use the first three digits as the manufacturer prefix
• Match the prefix to the maker (examples below)
• Use the full model number when ordering parts to avoid fit issues

These prefixes are widely used across Kenmore appliances and help identify who built the unit.

Knowing Whirlpool built Kenmore 10689593102 helps you troubleshoot and choose compatible parts more accurately. For example, maintenance items like the water filter F2WC9I1 are tied to the exact design used by the original manufacturer.

Last updated: February 2026

If your Kenmore 10689593102 freestanding ice maker is not making ice, the most common causes are no water supply, restricted water flow (often a clogged filter), a drain or recirculation problem, or a control issue. Start with water supply and cleaning checks, then move to pump and electrical tests using the 10689593102 owner's manual.

• Confirm the unit is powered on and the ice bin is seated correctly.
• Verify the shutoff arm or ice level sensor is not stuck in the “full” position.
• Make sure the water supply valve is fully open and the supply line is not kinked.
• Check for a frozen or blocked water path; warm the area gently and clear any visible ice.
• If cubes are small or production is slow, replace the water filter F2WC9I1.

Turn off power before accessing internal parts.

• Use a multimeter to check for voltage at the pump(s) during the appropriate cycle.
• Inspect harness plugs for corrosion or loose pins.
• If the pump hums but does not move water, the pump is typically the fix.
• If multiple functions fail (pumps, lights, cycle control), the control board is a common suspect.

An ice maker that runs without proper water flow can overwork pumps and extend freeze times; a simple water supply or filter issue can look like a major failure. Starting with water flow prevents unnecessary part replacement.
