How do I figure out what water filter I need for my Kenmore fridge?
For Kenmore refrigerator model 79579299901, the most reliable way to identify the correct water filter is to match by model number in the documentation and parts listing; start with the 79579299901 owner's manual, then confirm the filter style and installation location before ordering.
Fast ways to identify the right filter
- Check the filter housing inside the fresh food compartment (or base grille area) for a printed part number.
- Use the refrigerator model number 79579299901 (from the rating label) to match the correct filter.
- Compare the old filter’s shape and end connections (twist-in vs push-in).
- Confirm whether your refrigerator is configured “with a water filter” because water pressure requirements differ.
- If you do not use a filter, consider adding an inline filter if your water has sand or particles.
What the manual tells you (and why it helps)
Our Kenmore documentation for this model notes that water pressure requirements change depending on whether the refrigerator uses a water filter: 20 to 120 psi on models without a water filter, and 40 to 120 psi on models with a water filter. That detail helps you confirm you are shopping for the correct filter setup and that your home water supply is compatible.
Quick reference table
| Setup | Typical water pressure range | What to check |
|---|---|---|
| No water filter | 20 to 120 psi | Water valve screen, sediment in supply line |
| With water filter | 40 to 120 psi | Correct filter type, proper seating, no leaks |
Why it matters
Using the correct water filter protects the refrigerator water valve and helps prevent slow dispensing, weak ice production, and leaks at the filter head. If you are troubleshooting low water flow, the inlet valve can also be a factor; the model-specific replacement is the refrigerator water valve AJU55759303.
Last updated: January 2026
What size is Kenmore refrigerator model 79579299901?
Kenmore refrigerator model 79579299901 is a top-freezer (top-mount) refrigerator in the Kenmore 795.7929**** model group. The exact exterior dimensions (width, depth, height) vary by the specific 795.7929**** configuration; we use the owner's manual to confirm the correct measurements for your unit.
How to get the exact dimensions for your 79579299901
Use these quick checks so you get the right fit for a cabinet opening, doorway, or delivery path:
- Check the model and serial label inside the fresh food compartment (typically on the right-hand side) to confirm the full model number and configuration.
- In the owner's manual, look for a section like installation, unpacking, or refrigerator installation where dimensions and clearance diagrams are commonly listed.
- Measure the refrigerator at the widest points (handles, hinges, and door edges can add width).
- Measure depth with doors closed and note whether you are including handles.
- Plan for airflow clearance; the manual calls for 2 inches minimum from adjacent items and surfaces for proper air circulation.
Typical size range for Kenmore 795 top-freezer refrigerators
Most Kenmore 795-series top-freezer refrigerators fall into these common exterior ranges (useful for planning before you confirm the exact spec):
| Measurement | Typical range | What to include in your measurement |
|---|---|---|
| Width | 29 to 33 inches | Include hinges and handles if they stick out |
| Height | 66 to 69 inches | Measure to the top hinge cover if present |
| Depth | 30 to 34 inches | Note “case only” vs “with handles” |
Why it matters
Correct sizing prevents door swing interference, poor ventilation, and installation headaches. Clearance is also important for cooling performance and energy use, especially on a top-freezer design.
Last updated: January 2026
What is the upper part of a fridge called?
On the Kenmore 79579299901 top-mount refrigerator, the upper compartment is the freezer compartment. It is the section designed to keep foods frozen and it also supplies cold air that helps cool the fresh food (refrigerator) section below.
What the top (freezer) section does
In a top-mount refrigerator like model 79579299901, the freezer is more than storage; it is the main source of cold air for the whole appliance.
- Freezes and stores frozen foods
- Sends cold air down to the refrigerator section through vents
- Helps maintain stable temperatures when doors stay closed
- Often houses the ice maker (if equipped) and ice bin
How air moves between the freezer and refrigerator
Your refrigerator is designed so air circulates between both sections for proper cooling.
| Area | What happens | Why you notice it |
|---|---|---|
| Freezer compartment (top) | Cold air is produced and circulates | Freezer temp changes first when settings change |
| Vent/damper path | Controls how much cold air moves down | Can cause fridge too warm or too cold if blocked |
| Refrigerator compartment (bottom) | Receives cold air from the freezer | Needs clear vents for even cooling |
For the model-specific airflow layout and vent locations, use the owner's manual.
Why it matters
When customers call the top section the “upper fridge,” it can lead to confusion during troubleshooting. If the freezer is warming up, the refrigerator section usually warms up soon after because the freezer supplies the cold air.
Quick tips if the upper section is not cold enough
- Make sure freezer vents are not blocked by packages
- Keep door openings brief; frequent openings raise temperatures
- Confirm controls are set correctly and wait 24 hours between adjustments
- Check that both doors close easily and seal fully
- Allow 2 to 3 hours of run time after setup before loading food
Last updated: January 2026
What is the ER if code on a Kenmore Elite?
On Kenmore model 79579299901, the ER IF (Er IF) code points to an ice fan problem in the freezer area. That fan pushes cold air through ducts to keep the ice maker compartment cold; when airflow drops, the control reports ER IF.
What to check first (quick, safe steps)
- Power reset: unplug the refrigerator for 5 minutes, then restore power.
- Make sure freezer vents and the ice duct area are not blocked by packages.
- Look for frost or ice buildup around the fan cover area (a common cause of fan drag).
- Confirm the freezer door closes tightly and the gasket seals all the way around.
- Verify temperatures: freezer near 0°F, refrigerator near 37°F (typical targets).
Common causes of ER IF
| Likely cause | What you may notice | What usually fixes it |
|---|---|---|
| Ice buildup restricting the ice fan | Fan noise, weak airflow, intermittent code | Defrost and correct the source of moisture/air leak |
| Door seal leak letting humid air in | Frost near vents, longer run times | Clean/reshape gasket, adjust door alignment |
| Fan not running or running slowly | No airflow to ice area, warming ice | Diagnose fan circuit and replace failed component |
| Control or wiring issue | Code returns quickly after reset | Inspect connections, test components per manual |
Why it matters
The ice fan is part of the airflow system that keeps the ice maker area cold. If airflow is restricted, ice production drops and temperatures can drift, which can also increase frost buildup and energy use.
When parts are involved
If you also have water or ice maker symptoms (slow fill, no ice, leaking), the inlet valve can contribute to icing and performance issues. For this model, the correct valve listed is the refrigerator water valve AJU55759303.
Use the manual for model-specific diagnostics
For the exact troubleshooting flow, access the owner's manual for Kenmore model 79579299901 and follow the troubleshooting guide and safety steps (disconnect power before servicing).
Last updated: January 2026
