Kenmore Elite 66513963K012 undercounter dishwasher Parts

To hard reset a Kenmore Elite dishwasher model 66513963K012, we recommend doing a full power reset: turn the dishwasher’s breaker OFF (or unplug it) for about 5 minutes, then restore power and restart a cycle. This clears many control glitches without changing any settings.

Hard reset steps for model 66513963K012

1. Turn the dishwasher OFF.
2. Cut power at the breaker (preferred) or unplug the power cord.
3. Wait 5 minutes.
4. Restore power.
5. Press START/RESUME and close the door within 3 seconds to begin a cycle.

For control and cycle behavior details specific to this model, use the 66513963K012 use & care manual.

If you need to stop a stuck cycle first

This model supports a control reset through the Cancel/Drain function.

• Open the door slightly and wait for spraying to stop.
• Press CANCEL/DRAIN once, then close the door within 3 seconds to drain.
• If you want to fully reset the control before choosing a new cycle, press CANCEL/DRAIN twice.
• Re-select the cycle and options.
• Press START/RESUME.

What to expect after a reset

Reset type	What it does	Best for
Power reset (breaker/unplug)	Reboots the electronic control	Random beeping, frozen buttons, odd lights
Cancel/Drain reset	Stops the current cycle and clears the selection	Wrong cycle selected, cycle won’t advance

Why it matters

A hard reset is often the fastest way to clear a temporary control-board “lockup” caused by a power blip or interrupted cycle, so you can get back to normal washing without replacing parts.

Last updated: January 2026

Repairing a Kenmore Elite dishwasher like model 66513963K012 is worth it when the problem is a common wear item (seal, latch, valve, drain issue) and the total repair cost stays well below the cost of replacement. If the failure is a major electrical or motor-related repair, replacement can make more sense.

Quick decision checklist

We use these practical checkpoints to decide whether to repair or replace:

• Repair if the issue is a leak, no-fill, or no-drain that points to a serviceable part
• Repair if the tub and racks are in good shape and you like the cleaning performance
• Replace if you have repeated breakdowns in a short period
• Replace if the repair requires multiple major assemblies (pump/motor plus control)
• Replace if you want newer efficiency, quieter operation, or updated features

Common repairs that are usually “worth it”

On the 66513963K012, these are typical fix paths that often restore normal operation without replacing the whole unit:

• Door leaks: inspect the door gasket and lower door seal
• Won’t fill: check water supply, then the inlet valve and float system
• Won’t drain: check for kinks/clogs, then the drain pump
• Won’t start: confirm door latching and control lock settings

If you’re chasing a leak at the door, start with the 66513963K012 use & care manual. If the seal is torn, flattened, or pulling away from the tub, the compatible replacement is the dishwasher door seal W11177741.

Cost and complexity comparison

Repair type	Typical effort	When it’s a good choice
Seal, latch, valve	Low to medium	One clear symptom, no other issues
Drain pump or heater	Medium	Unit otherwise runs well
Control board or pump and motor	Medium to high	Only if the dishwasher is in great condition overall

Why it matters

A dishwasher replacement is a full project (fit, hookups, leveling, and potential cabinet adjustments). A targeted repair can keep your Kenmore Elite 66513963K012 running reliably, especially when the root cause is a single failed component.

Last updated: January 2026

On the Kenmore Elite 66513963K012 dishwasher, we force a drain by canceling the active cycle: open the door to pause, press CANCEL/DRAIN once, then close the door within 3 seconds. If water is in the tub, it will run a drain sequence for about 2 minutes (until the Cancel/Drain light turns off). See the steps in the 66513963K012 use & care manual.

Step-by-step: force a drain (Cancel/Drain)

• Open the door slightly to stop the cycle; wait for spraying to stop.
• Press CANCEL/DRAIN once.
• Close the door within 3 seconds.
• Let the dishwasher drain fully (about 2 minutes).
• When the Cancel/Drain light turns off, the drain sequence is complete.

If it still will not drain

If the drain cycle runs but water remains, the issue is usually a restriction or a failed drain component.

• Check for kinks or clogs in the drain hose routing.
• If connected to a garbage disposer, confirm the disposer inlet knockout plug was removed.
• Check for food blockage at the drain path and sump area.
• If the unit hums but does not move water, the drain pump may be jammed or failing.

Common causes and what to check

Symptom	Most likely cause	What we recommend
Drain cycle runs, water remains	Drain hose kink or clog	Inspect hose routing and clear blockage
Hums during drain, little/no water movement	Pump obstruction or weak pump	Inspect pump area; consider replacing the pump
Drains slowly	Partial restriction in hose or disposer inlet	Clear restriction; verify high loop/air gap setup

If you determine the pump is not moving water, the compatible replacement for this model is the dishwasher drain pump WPW10348269.

Why it matters

Standing water can lead to odors, poor wash performance, and repeated drain errors. Running the correct Cancel/Drain sequence first helps you separate a control issue from a true drain system problem.

Last updated: January 2026

For Kenmore Elite dishwasher model 66513963K012, the most common problems we see are poor cleaning, water not draining, leaks, and “won’t start” symptoms. Many of these trace back to filter maintenance, loading issues, water supply problems, or a worn seal or pump-related component; see the 66513963K012 use & care manual for model-specific care and troubleshooting steps.

Most common symptoms and what usually causes them

• Dishes still dirty or gritty: clogged filter, blocked spray arm, or low incoming water temperature
• Water left in the tub: kinked drain hose, drain restriction, or a weak drain pump
• Leaks at the door: worn door seal or lower door seal, or door not closing squarely
• Detergent not dispensing: dispenser blocked by tall items or a failing dispenser
• Won’t fill or fills slowly: water supply turned off, float stuck, or inlet valve issue

Quick checks we recommend first (fast, no parts)

1. Clean the filter system and reinstall it fully seated.
2. Confirm spray arms spin freely and aren’t blocked by large pans.
3. Run hot water at the sink until it’s hot before starting a cycle.
4. Use automatic dishwasher detergent (not hand soap) and add rinse aid.
5. Verify the door closes and latches firmly.

Parts that commonly solve these problems on 66513963K012

Problem	Part to inspect/replace	What it affects
Leaking at door	Dishwasher door seal W11177741	Seals the tub opening to prevent drips during wash
Not draining / water remains	Dishwasher drain pump WPW10348269	Pumps water out through the drain hose
Won’t fill / low water	Dishwasher water inlet valve W11175771	Controls water entering the dishwasher
Poor cleaning	Dishwasher filter W10872845	Keeps food soil from recirculating onto dishes

Why it matters

These issues often get worse over time: a dirty filter can reduce cleaning and increase odors, a small door leak can damage surrounding cabinetry, and a weak drain can leave standing water that affects the next load.

Last updated: January 2026
