Yes, it’s worth replacing the engine on a Craftsman rear-engine riding mower model 502256220 when the mower deck, transmission, and steering are still solid and the total engine swap cost stays well below the cost of a comparable replacement mower. If the chassis is worn out or multiple major systems need work, replacement is the better value.

Quick decision checklist

• Replace the engine if the deck shell is sound (not rusted through) and spindles turn smoothly.
• Replace the engine if the drive system moves consistently forward and reverse without slipping.
• Replace the engine if the steering is tight and the frame is not cracked or bent.
• Replace the engine if you can do the work (or pay for it) and still stay under about half the cost of a new mower.
• Replace the mower if it needs an engine plus major deck, drive, and electrical repairs.

Costs and effort: what to compare

Item	Typical range	Notes
Replacement engine or short block	Mid to high cost	Short block can save money if your carburetor and ignition are good.
Labor (if not DIY)	Moderate to high	Engine swaps are straightforward but time-consuming.
“While you’re in there” parts	Low to moderate	Fuel and electrical issues can mimic engine failure.
New mower	Highest	Includes warranty and avoids downtime.

Parts that commonly cause “bad engine” symptoms

Before committing to an engine, we recommend ruling out common no-start or stalling causes on this model:

• Clogged fuel flow: replace the filter 84001895 and check for old fuel.
• Intermittent crank/no crank: test the ignition switch 532365402.
• Clicks but won’t crank: test the solenoid 7701100MA and battery cables.
• Blown fuse or loose connection: inspect the fuse holder 407078MA.

Why it matters

An engine swap can be a smart investment because the deck, frame, and drive components often outlast the original engine. But if the mower has widespread wear, you can end up paying twice: once for the engine and again for the next major failure.

Last updated: January 2026

Replacing the engine on a Craftsman riding lawn mower model 502256220 typically costs $900 to $2,500 installed (engine plus labor), with the biggest swing coming from the engine itself and how much transfer work is needed. DIY replacement usually runs $500 to $1,800 for the engine and basic supplies.

What makes the price go up or down

These are the cost drivers we see most often on rear-engine riding mowers:

• Engine type and horsepower (new OEM-style vs aftermarket vs rebuilt)
• Crankshaft size and PTO setup (must match your pulley and blade drive)
• Parts transfer (carburetor, muffler, wiring harness, throttle/choke cables)
• Condition of fuel and electrical systems (contamination or corrosion adds work)
• Shop labor rate and minimum charges (pickup, diagnostics, disposal fees)

Typical cost breakdown

Use this as a planning range for a Craftsman rear-engine rider like model 502256220.

Cost item	Typical range	Notes
Replacement engine	$500 to $1,800	Most of the total cost; exact fit depends on shaft and mounting pattern
Labor (shop install)	$300 to $900	Commonly 3 to 6 labor hours depending on transfers and adjustments
“While you’re in there” parts and fluids	$50 to $250	Fuel filter, oil, clamps, wiring repairs

Parts worth replacing during an engine swap

Replacing inexpensive wear items helps protect the new engine and prevents repeat no-start or fuel-starvation issues.

• Filter 84001895 (inline fuel filter)
• Fresh fuel line and clamps (if the old line is stiff or cracked)
• Battery and cable ends (if cranking is weak or connections are corroded)
• Engine oil and spark plug (standard tune-up items)

Why it matters

An engine swap is only successful when the replacement engine matches the mower’s drive and PTO setup and the fuel and electrical systems are clean and reliable. Spending a little on supporting parts often prevents hard-starting and poor performance.

Last updated: January 2026

The Craftsman rear-engine riding mower model 502256220 uses a single-cylinder gasoline engine. To identify the exact engine manufacturer and the correct tune-up parts for your mower, we match the engine’s ID tag (model, type/spec, and code) to the engine parts list.

How to identify the engine on model 502256220

The engine ID tag is the only reliable way to confirm the exact engine family on your specific unit.

• Look for an ID label on the blower housing, valve cover area, or near the muffler
• Write down the engine model and spec/type numbers exactly
• Use those numbers when shopping for ignition, fuel, and carburetion parts
• If the tag is dirty, wipe it clean and take a clear photo for reference

Parts that commonly support engine starting and fuel delivery

If you are diagnosing a no-start or fuel-starvation symptom, these model-matched parts are common checks.

• Filter 84001895
• Ignition switch 532365402
• Solenoid 7701100MA

Quick symptom-to-check table

Symptom	Most likely system	What we check first
Cranks but will not start	Fuel or ignition	Fresh fuel, fuel flow, spark at plug
Clicks but will not crank	Starting circuit	Battery charge, cable connections, solenoid function
No click, no crank	Interlock or switch	Brake/seat switches, ignition switch output

Why it matters

Craftsman riding mowers can have different engine variants across production runs. Using the engine ID tag prevents ordering the wrong fuel filter, ignition parts, or starting components for model 502256220.

Last updated: January 2026

A Craftsman “6.75” rating is an engine size label used on many different walk-behind mowers; it is not a unique model number. For your Craftsman rear-engine riding mower, the model number is 502256220, and the correct way to identify any Craftsman mower is by reading the full model number from the ID tag.

Where to find the model number on Craftsman mowers

On Craftsman riding mowers like model 502256220, the model tag is on the tractor frame, not stamped into a walk-behind deck.

• Look under the seat on the frame or seat pan area
• Check the rear frame behind the seat
• Look under the hood near the engine compartment (if equipped)
• Clean the tag so every digit is readable
• Write down the full model number exactly as shown

Why “6.75” does not identify the mower

“6.75” typically refers to an engine power class used across many Craftsman walk-behind mower versions. Different mowers with the same engine rating can use different blades, belts, cables, and ignition parts.

Label you see	What it usually means	What to use for parts
“6.75” on engine cover	Engine power class	Mower model number from ID tag
Model number on frame tag	Exact mower identity	Correct parts diagrams and fit
Engine model/type code	Exact engine identity	Tune-up parts for that engine

Helpful next steps once you have the model number

If you are shopping parts for Craftsman model 502256220, match parts by the mower model number first, then confirm by diagram and symptom.

• For fuel delivery issues, check the filter 84001895 for restriction or leakage
• For no-crank or intermittent starting, test the ignition switch 532365402
• For clicking but no starter engagement, inspect the solenoid 7701100MA

Why it matters

Using the full model number from the ID tag prevents ordering the wrong electrical or fuel-system parts and helps you pull the correct diagrams for your exact Craftsman mower.
