Kenmore Elite 79572482410 refrigerator

Kenmore Elite 79572482410 refrigerator Parts

Here are the diagrams and repair parts for Kenmore Elite 79572482410 refrigerator, as well as links to manuals and error code tables, if available.

By Schematic
By Part
SELECT DIAGRAM
?

This is the number corresponding to the part on the diagram / schematic

Browse Parts for 79572482410 Refrigerators

Kenmore Elite Refrigerator 79572482410 FAQs

Most Kenmore Elite refrigerators, including model 79572482410, typically last 10 to 15 years with normal household use and basic upkeep. Regular preventive maintenance helps you reach the high end of that range and reduces the chance of major sealed-system repairs.

Typical lifespan and what affects it

A refrigerator’s life is usually determined by how hard the cooling system works and how well airflow and door sealing are maintained.

  • Keep condenser airflow clear (dust buildup makes the compressor run hotter and longer)
  • Keep doors sealing tightly (warm air leaks create extra run time and frost)
  • Replace filters on schedule to maintain airflow and water flow
  • Avoid overpacking so cold air can circulate
  • Address unusual noises or warming early to prevent secondary damage

Maintenance schedule we recommend

Use this as a practical baseline; for model-specific locations and procedures, follow the 79572482410 owner's manual.

Task Typical frequency Why it helps
Clean condenser area Every 6 to 12 months Reduces compressor workload
Replace air filter About every 6 months Helps control odors and supports airflow
Replace water filter About every 6 months (or when flow drops) Protects dispenser/ice maker performance
Check door gaskets for gaps Every 3 months Prevents warm air leaks and frost

Parts that commonly impact longevity

These parts do not set the lifespan by themselves, but they often drive repair decisions as the unit ages.

Why it matters

A refrigerator that runs longer cycles, struggles to hold temperature, or develops recurring ice and water issues uses more energy and puts extra stress on the sealed system. Simple upkeep often delays the point where a major repair becomes the deciding factor.

Last updated: January 2026

Kenmore Elite refrigerator model 79572482410 is a bottom-mount style in the 795.7248 model family; the exact exterior dimensions (width, depth, height) vary by configuration and are listed in the 79572482410 owner's manual. For planning space, most 33-inch-class bottom-mount units are roughly 33 inches wide and about 68 inches tall.

How to confirm the exact dimensions for 79572482410

We recommend using the specification or installation section in the manual because it reflects the exact cabinet size, door swing, and clearance needs for your specific configuration.

  • Check the model number on the rating label to confirm 79572482410 matches your refrigerator
  • Use the dimensions listed in the manual (not a similar 795 model)
  • Measure your opening at the top, middle, and bottom (walls are often not perfectly square)
  • Include door and drawer clearance so the refrigerator can fully open
  • Account for flooring changes (new tile, thicker mats) that can affect height clearance

Clearance requirements you should plan for

Even with correct cabinet dimensions, clearances affect performance and usability.

What to allow Typical guidance for this model family Why it matters
Space behind unit About 2 inches Airflow for condenser cooling
Space in front About 24 inches Door and drawer opening room
Water supply access Nearby connection Ice maker and water dispenser hookup

Why it matters

Correct sizing prevents door interference, poor airflow (warm temperatures), and installation headaches, especially on bottom-mount refrigerators where the freezer drawer needs extra front clearance.

Last updated: January 2026

Common problems on the Kenmore Elite refrigerator model 79572482410 include warm temperatures (often airflow or sealed-system related), frost buildup from defrost or door-seal issues, dispenser and ice maker troubles, and unusual noises from fans or the compressor. Use the troubleshooting section in the 79572482410 owner's manual to match symptoms to the right checks.

Most common symptoms and what usually causes them

  • Not cooling or weak cooling: dirty condenser coil, evaporator fan not running, blocked vents, or sealed-system/compressor issues
  • Frost or ice buildup: door not sealing, frequent door openings, or a defrost system problem
  • Water leaking or puddles: clogged/iced drain, water line connection issue, or dispenser tubing problem
  • Ice maker not making ice: restricted water supply, frozen fill tube, filter restriction, or ice maker failure
  • Noises (buzzing, clicking, rattling): fan blade hitting ice, failing fan motor, or compressor/start components

Quick checks we recommend before replacing parts

  1. Confirm controls are set correctly and doors close fully.
  2. Check for blocked air vents (food packages can stop airflow).
  3. Clean dust from the condenser area and ensure good airflow around the cabinet.
  4. Inspect door gaskets for gaps, tears, or debris.
  5. If you have a water dispenser, verify household water supply is fully on and lines are not kinked.

Parts that commonly relate to these problems (for this model)

Symptom Common part involved Example part for 79572482410
Warm fridge/freezer, poor airflow Evaporator fan motor Refrigerator evaporator fan motor EAU61524007
Ice maker not working Ice maker assembly Lg refrigerator ice maker AEQ73110210
Bad taste/slow water flow Water filter Kenmore refrigerator water filter 9490 ADQ73613402
Odors in fresh food section Air filter Lg refrigerator air filter ADQ73214408

Why it matters

Cooling and ice-making problems often start as airflow, filtration, or door-seal issues; fixing those early helps prevent food spoilage, excessive frost, and strain on the compressor and sealed system.

Last updated: January 2026
