LG LFXS24623S/01 refrigerator Parts

On the LG LFXS24623S bottom-mount refrigerator, the most common “problem” is usually a symptom such as warm fresh food, a freezer that is too cold, no ice, or water not dispensing. These issues typically trace back to airflow restrictions, a failing fan or sensor, or a water supply component; use the LFXS24623S owner's manual to match symptoms to checks.

Most common symptoms and what they usually mean

• Fresh food warm, freezer OK: restricted airflow (blocked vents, overpacked shelves) or a weak evaporator fan.
• Freezer too cold or temps swing: temperature sensor or control issue.
• No ice or slow ice: water supply problem, inlet valve issue, or ice maker fault.
• Water dispenser slow: clogged water filter or air in the water line.
• Clicking, then not cooling: compressor start components (overload protector) or compressor problem.

Quick checks we recommend first (no tools)

1. Confirm settings: refrigerator about 37°F, freezer about 0°F.
2. Make sure vents are not blocked by food packages.
3. Clean condenser area and verify the unit has breathing room.
4. If water or ice is affected, replace the filter and purge air.
5. Listen for the evaporator fan; it should run when cooling is needed.

Parts that commonly solve these problems (when diagnosis points there)

Symptom	Likely system	Example part for LFXS24623S
Warm fresh food, poor airflow	Cooling/air circulation	LG refrigerator evaporator fan motor 4681JB1027C
Temps erratic	Temperature sensing	Refrigerator temperature sensor 6500JB2002X
No water or no ice fill	Water supply	LG refrigerator water inlet valve AJU72992601
Slow water, bad taste/odor	Filtration	LG kenmore refrigerator water filter ADQ36006101

Why it matters

A bottom-mount refrigerator depends on steady airflow from the evaporator and accurate sensor feedback. When airflow is blocked or a fan or sensor drifts out of range, the fresh food section is usually the first place you notice warming, even if the freezer still seems “cold.”

Helpful DIY guidance

• LG bottom freezer refrigerator error codes
• How to replace the water filter in an LG refrigerator

You can order replacement parts for your LG LFXS24623S from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

If your LG LFXS24623S refrigerator is leaking from the bottom, the most common causes are a clogged defrost drain that overflows into the base, a water-supply leak feeding the ice maker or dispenser, or a drain-tube issue that lets defrost water miss the drain pan. Use the LFXS24623S owner's manual to confirm access points and cleaning steps for your exact configuration.

Quick checks that usually pinpoint the leak

• Look for clear water vs. dirty water: clear water often points to the water line, inlet valve, or filter housing; dirty water often points to the defrost drain and debris.
• Check the freezer floor and back wall: ice buildup or a sheet of ice often indicates a defrost drain restriction.
• Inspect the drip pan area: if the pan is cracked, shifted, or overflowing, water can appear to leak “from the bottom.”
• Check the ice maker and dispenser area: leaks can run down inside the cabinet and exit at the front.
• Confirm the doors seal and close fully: warm air intrusion increases frost, which can overwhelm the drain.

Most likely causes and what to do

What you notice	Most likely cause	What we recommend
Water appears after defrosting; ice in freezer bottom	Defrost drain partially clogged	Clear the drain path; flush with warm water and remove debris
Leak happens when dispensing water or making ice	Water supply connection or inlet valve seep	Inspect fittings and tubing; replace the LG refrigerator water inlet valve AJU72992601 if it seeps
Water trails from rear bottom; recurring puddles	Drain tube misrouted, split, or restricted	Inspect and replace the refrigerator drain tube 5251JA3003D if damaged
Slow water flow; filter recently changed; drips near filter area	Filter not seated or O-ring issue	Reseat/replace the LG kenmore refrigerator water filter ADQ36006101 and purge air

Why it matters

Bottom leaks can damage flooring and also signal airflow and defrost problems that lead to warm temperatures, frost buildup, and ice maker issues. Fixing the root cause early helps protect the compressor and keeps food temperatures stable.

Helpful DIY guidance

• Follow how to replace the water filter in an LG refrigerator for correct filter seating and flushing.
• Use how to diagnose a faulty refrigerator water inlet valve if the leak only happens during ice making or dispensing.
• If you need parts beyond the ones listed for LFXS24623S, search by model number on Sears PartsDirect.

Last updated: February 2026

Yes. For your LG LFXS24623S refrigerator, a genuine LG-compatible water filter is worth it when you want reliable fit, steady water flow, and consistent taste and odor improvement; it also helps prevent nuisance leaks or bypass issues that can happen with off-brand filters.

What you get from a genuine filter

A refrigerator water filter improves drinking water quality and helps protect the dispenser and ice maker water path from sediment buildup.

• Better taste and odor by reducing chlorine-related flavor
• Reduced sediment that can clog small passages in the dispenser and ice maker
• More consistent fit and seal in the filter head (fewer leaks)
• Predictable performance when changed on schedule

For model-specific filter location and replacement steps, use the LFXS24623S owner's manual.

The correct replacement filter for this model

The parts list for LG LFXS24623S includes a compatible replacement: LG kenmore refrigerator water filter ADQ36006101.

• Replace on a regular schedule (most refrigerator filters are changed about every 6 months)
• Flush water after installing a new filter to clear carbon fines and air
• If flow is slow, try removing and reinstalling the filter to confirm it is fully seated

Quick decision guide

Your priority	Best choice	Why
Lowest hassle and best fit	Genuine LG-compatible filter	Fewer sealing and fit problems
Best taste from dispenser	Replace filter on schedule	Old filters commonly cause off-taste
Protect ice maker performance	Use a quality filter and flush after changes	Helps prevent sediment-related restrictions

Why it matters

On a French door, bottom-mount refrigerator like the LG LFXS24623S, the water filter affects both drinking water and ice production. A restricted or poorly sealing filter can cause slow dispensing, hollow ice, or intermittent ice maker fills.

Helpful DIY guidance

• How to replace the water filter in an LG refrigerator
• How to change the water filter in an LG refrigerator

You can order replacement parts for your LG LFXS24623S from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026
