Kenmore Elite 79574023412 refrigerator Parts

For Kenmore Elite model 79574023412, the exact cubic-foot capacity is listed on the product rating label and in the 79574023412 use and care guide. If you do not have that number handy, you can estimate capacity by measuring the inside (usable) space and converting cubic inches to cubic feet.

How to estimate cubic feet (quick method)

We recommend measuring the interior of the fresh food compartment and freezer separately, then adding them.

• Empty enough items to measure wall-to-wall inside the compartment
• Measure width x height x depth in inches (usable space, not the outside cabinet)
• Multiply to get cubic inches
• Divide by 1,728 to convert to cubic feet
• Add refrigerator + freezer results for a total estimate

Conversion table

What you have	Convert to	Math
Cubic inches	Cubic feet	cubic inches ÷ 1,728
Inches (W x H x D)	Cubic inches	W x H x D

Where to find the exact capacity on the refrigerator

On most Kenmore Elite refrigerators, the most reliable “exact” capacity is printed on the rating label.

Common places to check:

• Inside the fresh food section on a side wall
• Near the crisper area
• Along the door frame (fresh food side)
• Behind the toe grille area (less common)

Why it matters

Cubic-foot capacity helps you choose correctly sized replacement parts and accessories (like a refrigerator water filter and air filter), and it also helps when comparing storage space across similar Kenmore 795-series refrigerators.

If you are also tracking filter maintenance for this model, we commonly see owners pair capacity checks with routine filter changes such as the genuine Kenmore refrigerator water filter 9690 AGF80300801.

Last updated: February 2026

If your Kenmore Elite refrigerator model 79574023412 is warm, runs for long periods, or makes repeated clicking and still will not cool, the compressor or its start components may be failing. We confirm compressor trouble by ruling out airflow, dirty condenser, and door-seal issues first.

Quick checks before blaming the compressor

These items commonly cause “not cooling” and “runs constantly” symptoms even when the compressor is OK:

• Make sure the doors close fully and seal all the way around.
• Reduce door openings and avoid loading large amounts of warm food at once.
• Verify the refrigerator is not installed in a hot location; do not operate above 110°F.
• Clean the condenser cover and vents with a vacuum attachment (do not remove the panel covering the condenser coil area).
• Listen for the evaporator fan and feel for airflow at the vents; poor airflow can mimic compressor failure.

Signs that point more directly to a bad compressor

A compressor issue is more likely when you see a combination of these:

• Warm fridge and freezer even after several hours of running.
• Repeated clicking every few minutes (often the start device/overload trying and failing).
• Compressor very hot to the touch after trying to run (use caution).
• Compressor silent while the refrigerator has power (could also be a control or start device).
• No improvement after cleaning condenser vents and confirming doors seal.

What “normal run time” looks like

Your manual notes that at about 70°F room temperature, it is normal for the compressor to run about 40% to 80% of the time; in warmer conditions it can run even more.

What you notice	Often normal	Often a problem
Runs a lot on hot days	Yes	No
Runs constantly and won’t cool	No	Yes
Clicking every few minutes	No	Yes
Better after cleaning vents	Yes	No

Model-specific help you can use

This model may support Kenmore Connect diagnostics, which can transmit data to a specialist over the phone. The steps and button sequence are in the 79574023412 owner’s manual.

Why it matters

A compressor replacement is a major repair, so we always eliminate simpler causes first (dirty condenser airflow, door gasket leaks, airflow restrictions). That saves time and prevents replacing expensive parts unnecessarily.

Last updated: February 2026

Common problems we see on the Kenmore Elite refrigerator model 79574023412 include weak or no cooling (often airflow, defrost, or sealed-system related), ice maker and dispenser issues, water leaks, and warm spots caused by blocked vents or dirty coils. Your 79574023412 owner's manual includes a troubleshooting guide to narrow symptoms quickly.

Most common symptoms and what they usually point to

• Not cooling or warm refrigerator section: dirty condenser coil, failed evaporator fan, stuck damper, or defrost problem
• Freezer cold but fresh food warm: airflow restriction, failed damper motor, iced-over evaporator
• Ice maker not making ice: water supply issue, ice maker failure, or dispenser/auger problem
• Water leaking or puddles: clogged defrost drain, loose water line, or door not sealing
• Frost buildup: door gasket leak or defrost sensor/heater issue
• Bad odors: overdue air filter, spills, or stagnant airflow

Quick checks we recommend before replacing parts

1. Confirm temps: 0°F freezer, 37°F fresh food.
2. Make sure vents inside the compartments are not blocked by food packages.
3. Clean the condenser area (dust buildup can cause high temps and long run times).
4. Check door closing and sealing with the “paper test” (paper should drag when pulled).
5. If ice or water is acting up, verify the household shutoff valve is fully open and the water line is not kinked.

Parts that commonly solve these problems on this model

Symptom	Common fix	Example part for 79574023412
Bad taste/slow water flow	Replace water filter	Genuine Kenmore refrigerator water filter 9690 AGF80300801
Odors in fresh food section	Replace air filter	Lg refrigerator air filter ADQ73214408
Frost/defrost trouble	Test defrost sensor circuit	Refrigerator defrost sensor assembly 6615JB2005R
Door not sealing	Replace gasket	Refrigerator door gasket, right ADX72930461
No ice or dispenser issues	Diagnose ice maker/auger	Lg refrigerator ice maker AEQ73130004

Why it matters

Cooling, ice, and leak complaints often share the same root causes: restricted airflow, poor heat rejection at the condenser, or a defrost system that cannot keep the evaporator clear. Fixing the underlying cause prevents repeat failures and food temperature swings.

Helpful DIY guidance

• How to replace the water filter in a Kenmore refrigerator
• How to get rid of refrigerator puddles
• How to fix a fridge door seal
• Kenmore 795 model bottom freezer refrigerator error codes

Last updated: February 2026

A Kenmore Elite refrigerator like model 79574023412 lasts 15 years on average. With consistent upkeep (clean airflow paths, strong door sealing, and on-time filter changes), it reaches full service life and avoids common cooling and ice maker problems.

Typical lifespan and what changes it

Most refrigerators fall into a predictable range; the difference is usually maintenance and how hard the sealed system has to work.

• Typical service life: 15 years
• Shorter life drivers: dirty condenser area, warm room temps, frequent door opening, poor door sealing
• Longer life drivers: clean condenser airflow, correct temperatures, good gasket seal, timely filter changes
• High-impact components: compressor, evaporator fan system, electronic control board

What you do	How often	Why it helps lifespan
Replace the water filter	About every 6 months	Protects the water system and keeps dispenser flow strong
Replace the air filter (if equipped)	About every 6 months	Reduces odors and helps airflow stay efficient
Check door closing and gasket seal	Monthly quick check	Prevents warm air leaks that overwork cooling
Keep condenser airflow clear	Every 6 to 12 months	Lowers compressor run time and heat load

Maintenance that pays off most

Use the 79574023412 owner's manual for the exact locations and procedures for your refrigerator’s filters, controls, and care steps.

• Keep the doors aligned and closing smoothly; a small gap makes the compressor run longer.
• If you notice odors or stale air, replace the air filter; this model family lists an air filter feature.
• If water tastes off or ice production slows, replace the water filter.
• Avoid overpacking; blocked vents cause warm spots and longer run times.
• Set stable temps (commonly 37°F fresh food and 0°F freezer) and avoid frequent adjustments.

Parts that commonly affect “end of life” decisions

When a refrigerator approaches the end of its typical lifespan, these parts often determine whether performance returns after repair.

Symptom	Common part category	Example part for this model
Warm fridge/freezer, long run times	Sealed system	Refrigerator compressor TCA38091801
Bad taste/slow water flow	Filtration	Genuine Kenmore refrigerator water filter 9690 AGF80300801
Odors persist after cleaning	Air filtration	Lg refrigerator air filter ADQ73214408

Why it matters

A refrigerator that is forced to run hot or run constantly wears the sealed system faster. Simple upkeep (filters, airflow, and door sealing) reduces run time, stabilizes temperatures, and helps your Kenmore Elite refrigerator reach its full 15-year lifespan.

Last updated: February 2026

Your Kenmore Elite refrigerator’s model number is printed on the model and serial number label inside the cabinet. For Kenmore Elite model 79574023412, the label is typically inside the fresh food section or freezer section, and it may also be referenced on the tech sheet stored under the front of the refrigerator (behind the lower grille). See the 79574023412 owner's manual for label and tech sheet location details.

Where to look for the model number label

Check these common spots first (use a flashlight and look for a white or silver sticker/plate):

• Inside the fresh food compartment on a side wall
• Inside the fresh food compartment near the crisper drawer area
• Inside the freezer compartment on a side wall
• Along the door frame area (fresh food side)
• Under the front of the refrigerator on the tech sheet (accessed from the lower front grille area)

How to read the label correctly

The label usually includes both a model number and a serial number.

• Model number: identifies the exact refrigerator design (needed for correct parts)
• Serial number: identifies your specific unit (often used for service history)
• Write the model number exactly as shown; for this unit it will match the 795.7402_ / 795.7404_ family shown in the manual, and your full model will be 79574023412

Why it matters (parts and troubleshooting)

Using the correct model number prevents ordering the wrong Kenmore refrigerator parts like a water filter, air filter, ice maker, or door gasket. It also ensures troubleshooting steps match your control panel and features.

What you’re doing	What you need	Why it helps
Ordering a replacement filter	Model number + part ID	Avoids fit and connection mismatches
Looking up error codes	Model family (795)	Matches the right diagnostic list
Scheduling service	Model + serial	Speeds up diagnosis and parts identification

Related help for this model family

If you’re seeing an error code or display issue after you find the model number, use Kenmore 795 model bottom freezer refrigerator error codes to match the code to likely causes (fan, defrost sensor, control board, etc.).

Last updated: February 2026
