Kenmore 79551036011 refrigerator Parts

The Kenmore 79551036011 is a full-size side-by-side refrigerator; most models in this class are about 33 to 36 inches wide, about 65 to 71 inches tall, and about 30 to 35 inches deep (not counting the door handles). For the exact dimensions and capacity for your unit, use the 79551036011 owner's manual.

Typical size ranges for a side-by-side refrigerator

These are the measurements we use most often for planning a fit (opening, door swing, and moving path):

• Width: 33 to 36 inches
• Height: 65 to 71 inches
• Depth (cabinet): 30 to 35 inches
• Depth (with doors/handles): often 2 to 4 inches deeper than cabinet depth
• Capacity: typically 22 to 27 cubic feet

How we recommend measuring your refrigerator (quick and accurate)

Measure in inches with a tape measure; then compare to your cutout space.

• Measure width at the widest point of the cabinet
• Measure height from floor to the top hinge cover area
• Measure depth from the back to the front edge of the doors
• Re-measure depth including handles (handles can change fit and door clearance)
• Confirm you have ventilation clearance (top, sides, and back) per the 79551036011 owner's manual

Fit checklist (what to verify before you buy parts or plan a move)

What you are checking	What to look for	Why it matters
Opening width	Cabinet width plus side clearance	Prevents rubbing and vibration noise
Opening height	Height plus top clearance	Avoids hinge cover contact
Depth and door swing	Depth with handles and door swing arc	Ensures doors open fully for bins and drawers
Water line access	Room behind unit for tubing	Helps prevent kinks and leaks

Why it matters

Correct size measurements help prevent door alignment issues, poor airflow, and water line strain. If you are troubleshooting dispenser or ice issues, confirming clearances and access also makes it easier to inspect parts like the refrigerator water inlet valve 5221JA2006D and water tubing connections.

Last updated: February 2026

The Kenmore side-by-side refrigerator model 79551036011 is typically about 36 inches wide overall. For the exact cabinet and door/handle width measurements you should use for a tight cutout, confirm the dimension chart in the 79551036011 owner's manual.

What “width” can mean (measure the right one)

When people ask for refrigerator width, they usually mean one of these:

• Cabinet width: the metal case, without doors/handles
• Overall width: doors and hinges installed (often slightly wider than the cabinet)
• Width with handles: the widest point at the handles
• Required opening width: cabinet width plus side clearances for airflow and door swing

How to measure your refrigerator width

Use a tape measure and check at least these spots:

• Back (cabinet): left-to-right across the case
• Front (doors/hinges): where the unit is often widest
• Handles: measure the widest point if handles protrude
• Opening: inside edge to inside edge of the cabinet cutout

Quick reference table

Measurement you need	Where to measure	Use it for
Cabinet width	Across the case at the back	Fit into the cutout
Overall width	Across the front at doors/hinges	Avoid rubbing cabinets
Width with handles	Widest point at handles	Walkway clearance
Opening clearance	Gap on both sides	Airflow and door swing

Why it matters

A side-by-side that is even slightly too wide can prevent installation, limit door swing, and reduce airflow around the condenser area. Using the model-specific dimension chart prevents fit problems before delivery.

If you end up needing door hardware while adjusting fit or alignment, we list model-matched parts such as the refrigerator door hinge 4775JA2113A. You can also find additional parts by searching your model number on Sears PartsDirect.

Last updated: February 2026

On the Kenmore 79551036011 side-by-side refrigerator, the model number is printed on the appliance identification label, which is typically located inside the fresh food (refrigerator) compartment along the side wall near the top, or on the door frame. For the exact label location and what the tag looks like, use the owner's manual.

Common places to check first

Look in these spots in order; one of them is usually correct for Kenmore side-by-side units:

• Inside the refrigerator section on the left or right interior wall (upper area)
• On the refrigerator door frame (visible when you open the door)
• Behind the crisper drawers on the side wall
• On the ceiling of the fresh food compartment near the light housing
• On the back exterior panel near the lower area (less common, but possible)

What you should see on the label

The ID tag normally lists both the model and serial information.

Label item	What it’s used for	Example for your unit
Model number	Matching parts and diagrams	79551036011
Serial number	Production info and service history	Varies by unit

Why it matters

We use the model number to match the correct Kenmore parts and diagrams for your exact configuration (ice maker, dispenser, door style, and internal water system). Even small model-number differences can change which parts fit.

Tips for reading and using the model number

• Write the model number exactly as shown, including all digits
• Take a clear photo of the label before ordering parts
• Use the model number when selecting dispenser and water-system parts such as the refrigerator water inlet valve 5221JA2006D or the refrigerator water filter head ADQ72911006
• If the label is hard to read, gently clean it with a damp cloth and dry it (avoid harsh cleaners)

You can order replacement parts for your Kenmore 79551036011 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

To replace the water filter in your Kenmore 79551036011 side-by-side refrigerator, remove the old filter from the filter housing, install the new filter fully seated, then flush several gallons of water to clear air and carbon fines. Use the steps in the owner's manual for the exact filter location and reset method.

Step-by-step: replacing the filter

• Dispense a few cups of water first to relieve pressure and reduce dripping.
• Open the filter access door or cover (common locations are inside the fresh food compartment or at the base grille).
• Turn the filter counterclockwise (or press the release, depending on the housing) and pull it straight out.
• Check that the old O-rings came out with the filter; wipe the housing sealing surface clean.
• Insert the new filter, push in firmly, then turn clockwise until it stops (do not overtighten).
• Close the access door or cover.

Flush and reset (what to do after installation)

After installing a new filter, we recommend flushing water through the dispenser to clear trapped air and loose carbon.

Task	Typical recommendation	What you should watch for
Flush water	2 to 3 gallons	Sputtering stops; flow becomes steady
Discard first ice	First 1 to 2 batches	Cloudy cubes or small black specks can occur initially
Reset filter indicator	Use the control panel sequence	Light changes from “replace” to normal

If the filter is stuck or leaking

• Stuck filter: grip the filter body (not the cap), and turn slowly; warming the compartment slightly can help.
• Leaking at the filter: remove and reinstall to ensure it is fully seated; inspect the housing for debris.
• Low water flow after replacement: flush longer; a partially seated filter can restrict flow.
• Ongoing dispenser issues: check the refrigerator water inlet valve 5221JA2006D for proper fill and the refrigerator water tube fitting 4932JA3002C for seepage at connections.

Why it matters

A properly installed, fully seated filter helps protect the water system from restrictions and leaks, and it improves taste and odor. Flushing and resetting the indicator keeps your maintenance schedule accurate.

You can order model-matched replacement parts for Kenmore 79551036011 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 79551036011 are poor cooling, water leaks, ice maker or dispenser failures, and unusual noises. These issues usually trace back to airflow restrictions, frost buildup from a defrost problem, or a worn water system component; use the 79551036011 owner's manual for model-specific checks.

Most common symptoms and what typically causes them

• Not cooling or warm temperatures: dirty condenser coils, failed condenser fan, failed evaporator fan, heavy frost from a defrost failure
• Water leaking or puddles: clogged defrost drain, loose water line connection, cracked reservoir, leaking inlet valve
• Ice maker not making ice: low water pressure, frozen fill tube, bad inlet valve, ice buildup in the freezer
• Dispenser not dispensing ice: jammed ice, failed auger motor, dispenser door not opening
• Noises (buzzing, rattling, clicking): fan blade hitting ice, loose panels, compressor start issues

Quick checks we recommend first (before replacing parts)

1. Confirm temperatures: 37°F fresh food, 0°F freezer.
2. Clean condenser coils and verify the condenser fan runs.
3. Check door closing and gasket seal; look for gaps or condensation.
4. Inspect for frost on the freezer back wall (points to a defrost or airflow issue).
5. If you have a water/ice issue, verify the household shutoff valve is fully open and the supply line is not kinked.

Parts that commonly solve these problems on this model

If troubleshooting points to a failed component, these model-matched parts are common fixes:

Problem area	What fails	Example model-matched part
Ice dispensing	Auger drive stops turning	Refrigerator auger motor EAU59551204
Water dispensing	Valve does not open or leaks	Refrigerator water inlet valve 5221JA2006D
Leaks inside fresh food section	Reservoir cracks or splits	Refrigerator water reservoir MJM61904702
Door not sealing	Gasket torn or warped	Refrigerator door gasket 4987JJ1010M

Why it matters

Cooling, ice, and water problems often share the same root causes: restricted airflow, frost buildup, or inconsistent water supply. Fixing the underlying cause prevents repeat failures and helps protect the compressor and control system.

Helpful DIY guidance

• For filter and water-flow related issues, follow how to replace the water filter in a Kenmore refrigerator.
• If you need to remove the dispenser front to clear a jam or access components, use how to disassemble a Kenmore refrigerator dispenser.

You can order replacement parts for Kenmore 79551036011 from the parts list for this model, or search by model number on Sears PartsDirect.
