GE GLD6700N10BB dishwasher Parts

No. GE dishwashers are not all the same size. Your GE GLD6700N10BB is a standard built-in style, and most built-in GE dishwashers are designed for a 24-inch-wide opening, but GE also makes compact 18-inch models and other configurations.

Common GE dishwasher size categories

Most GE dishwashers fall into a few fit categories. Always confirm the required cabinet opening and hookup locations in the GLD6700N10BB installation guide.

• Standard built-in: typically fits a 24-inch-wide opening
• Compact built-in: typically fits an 18-inch-wide opening
• Portable or countertop: varies widely; not intended for a standard built-in cutout
• Panel-ready/custom front: same basic opening size as standard built-in, but door thickness and clearances can change

What to measure before you buy or replace

Even when the width is “standard,” depth and height can vary by model and installation.

• Cabinet opening width (inside-to-inside)
• Opening height (floor to underside of countertop)
• Available depth (including door clearance to walkways)
• Toe-kick height and how far the unit can recess
• Water line, drain hose, and electrical routing space

Quick fit guide (typical ranges)

Use this as a planning reference; use the manual for exact specs.

Dishwasher type	Typical width	Typical height	Typical depth
Standard built-in	~24 in.	~33.5 to 35 in.	~24 in.
Compact built-in	~18 in.	~33.5 to 35 in.	~24 in.

Why it matters

A dishwasher that is even slightly too tall, too deep, or mismatched at the hookups can cause installation problems, door interference, leaks, or vibration. Confirming the opening and installation requirements up front prevents return trips and protects parts like the door seal and drain connections.

Last updated: January 2026

Yes. On the GE GLD6700N10BB dishwasher, a clogged drain path can trigger an FTD-type fill/drain problem because the dishwasher expects the tub to be mostly empty before it starts a new fill. Standing water from a blockage can confuse the fill and drain sensing.

What to check first (fast, common fixes)

• Cancel the cycle and let the unit attempt to drain.
• Check the sink drain for slow draining; a backed-up sink often means the dishwasher cannot drain.
• If the dishwasher drains into a disposer, run the disposer to clear it.
• If you have an air gap, clean it (a plugged air gap is a common cause of poor draining).
• Inspect the drain hose routing for kinks or crushing behind or under the dishwasher.

Drain system checkpoints for this model

Use the install steps in the GLD6700N10BB installation guide to confirm the drain hose is seated correctly on the pump outlet and clamped securely, and that the hose is routed through the cabinet without pinching.

Symptom	Most likely drain-related cause	What we do next
Water left in tub after cycle	Air gap clogged, disposer not cleared, hose kinked	Clear air gap, run disposer, straighten hose
Hums but drains slowly	Partial blockage in hose or drain line	Remove blockage, verify high loop/air gap setup
Won’t drain at all	Failed drain pump or severe blockage	Check pump operation; replace if needed

Parts that commonly relate to drain problems

If the drain path is clear but the dishwasher still will not evacuate water, the drain pump is a common next suspect.

• Dishwasher drain pump WD26X10025

Why it matters

FTD-style errors are often a symptom, not the root cause. Restoring normal draining prevents false fill/drain sensing, reduces cycle interruptions, and helps protect the pump and motor from strain.

For code-specific meaning and reset steps, use GE electronic dishwasher error codes.

Last updated: January 2026

To force-drain a GE GLD6700N10BB dishwasher, press the START/RESET pad a second time after starting a cycle; the unit cancels the cycle and pumps the water out (typically about 2 minutes). This is the quickest way to clear standing water before troubleshooting a drain problem. See the GLD6700N10BB owner's manual.

Quick steps to force a drain

• Close and latch the door.
• Press START/RESET once to start a cycle.
• Press START/RESET again to cancel; the dishwasher will pump out.
• Wait until the START/RESET light stops flashing.
• Open the door and confirm most water has drained.

If it still will not drain (common causes)

After a cancel-drain, standing water usually points to a restriction in the drain path or a pump issue.

• Check the drain hose under the sink for kinks or crushing.
• If connected to a garbage disposer, make sure the disposer inlet plug was removed.
• If you have an air gap, check for clogs.
• Clean the filter area; a blocked filter can slow or stop draining.
• If the dishwasher hums but does not move water, the drain pump may be jammed or failing.

Parts that commonly affect draining (for this model)

Symptom	What to check	Model-matched part
Water remains in tub	Drain pump not pumping	Dishwasher drain pump WD26X10025
Slow drain, debris in sump	Filter clogged	Dishwasher filter WD12X10109
Leaks or poor drain routing	Drain hose damaged or loose	Drain tube WD24X10045

Why it matters

Cancel-draining clears the tub so you can safely inspect the filter, drain hose, and pump area. It also helps confirm whether the control is commanding a drain and whether the drain system can actually move water out.

Related help

• Use dishwasher not draining video for a step-by-step drain troubleshooting walkthrough.

Last updated: January 2026

A GE dishwasher typically lasts about 10 years on average. For your GE GLD6700N10BB, lifespan depends most on water quality, how often it runs, and routine maintenance like cleaning filters and keeping the spray system clear; see the GLD6700N10BB owner's manual for care and cleaning guidance.

Typical lifespan and what affects it

Most dishwashers fall into a similar range, but these factors move the needle the most:

• Hard water (mineral buildup) shortens pump, valve, and heater life
• Heavy daily use wears the circulation system and door components faster
• Poor draining leaves debris that strains the drain pump
• Overloading can reduce cleaning performance and increase rewash cycles
• Skipped maintenance (filters, spray arms, seals) leads to leaks and wash issues

Maintenance that helps you reach (or beat) 10 years

We recommend these habits for the GLD6700N10BB:

• Clean the filter area regularly; replace the dishwasher filter WD12X10109 if it is damaged or won’t clean up
• Inspect and rinse spray components; replace the dishwasher spray arm WD22X10047 if jets are clogged or the arm is cracked/warped
• Watch for slow fills or no-fill symptoms; a failing dishwasher water inlet valve WD15X10003 can cause weak wash performance
• Address standing water quickly; a weak or noisy dishwasher drain pump WD26X10025 can lead to recurring drain problems
• Keep door seals clean and seated to prevent leaks and moisture damage

Quick reference: “repair or replace” guidance

What you’re seeing	Most common cause	Best next step
Not cleaning well	Clogged filter or spray arm	Clean first; replace filter/spray arm if damaged
Not draining	Drain pump or blockage	Clear blockage; consider drain pump replacement
Not filling or fills slowly	Inlet valve or supply issue	Check supply; consider inlet valve replacement
Loud grinding/humming	Pump/motor wear or debris	Check for debris; evaluate pump and motor assembly

Why it matters

A dishwasher near the 10-year mark often develops performance problems (poor cleaning, draining issues, leaks) that can usually be traced to a few serviceable parts. Catching those early helps protect the motor, wiring, and cabinetry.

Last updated: January 2026
