Kenmore Elite 79579783901 refrigerator Parts

Most Kenmore Elite refrigerators, including model 79579783901, typically last 12 to 15 years with normal household use. Consistent cleaning, good airflow around the cabinet, and keeping the doors sealing properly are the biggest factors that help you reach (or beat) that range; see the 79579783901 owner's manual for care and cleaning guidance.

What affects lifespan the most

• Condenser coil cleanliness: dust buildup makes the compressor run longer and hotter.
• Ventilation and room temperature: extreme heat increases run time and wear.
• Door seal condition: air leaks force longer run times and can cause frost issues.
• How often doors are opened: frequent openings add heat and moisture.
• Leveling and alignment: helps doors close fully and reduces gasket wear.

Quick maintenance schedule (simple and realistic)

Task	How often	What it helps prevent
Clean condenser area/coils	Every 6 to 12 months	Overheating, long run times
Wipe door gaskets and door liner	Monthly	Air leaks, mold, poor sealing
Confirm doors close on their own	Monthly	Warm spots, frost, compressor strain
Replace water filter (if equipped)	About every 6 months	Low flow, taste/odor issues

Signs your refrigerator is nearing end-of-life

• Compressor seems to run almost constantly even after the unit has had up to 24 hours to fully cool
• Temperatures swing (food spoils faster, freezer softens)
• Excess frost or recurring water puddles
• Doors do not close firmly or the gasket is torn or warped
• Unusual vibration or rattling that leveling does not correct

Why it matters

A refrigerator that runs longer than normal uses more electricity and puts extra stress on sealed-system components. Basic upkeep (especially coil cleaning and door sealing) reduces run time and helps your Kenmore Elite bottom-mount refrigerator stay reliable for the full 12 to 15 years.

Last updated: February 2026

On Kenmore Elite model 79579783901, the model and serial number are printed on an identification label inside the fresh food (refrigerator) compartment. You will find that label on the right-hand side wall of the refrigerator section; check it before ordering parts or scheduling service.

Where to look (fast checklist)

• Open the refrigerator (top) door, not the freezer drawer
• Look along the right interior wall of the fresh food compartment
• Check near the front edge where the door gasket seals
• Use a flashlight; the label can be small and easy to miss
• Write down both the model number and the serial number

What the label typically includes

Item on label	What it’s used for	Example for this unit
Model number	Matching parts and diagrams	79579783901
Serial number	Date/production info for service	Varies by unit
Electrical ratings	Confirming power requirements	Varies by unit

Why it matters

We use the exact model number to ensure parts fit your specific Kenmore Elite bottom-mount refrigerator. Even small model variations can change door hardware, water system parts, or electrical components.

Helpful tip before ordering parts

If you are replacing a common wear item, match the model first, then confirm the part by description and ID. For example, the interior light turning on and off with the door is controlled by the refrigerator door switch 6600JB1010A.

For diagrams and additional model identification details, use the 79579783901 owner’s manual.

Last updated: February 2026

On Kenmore Elite refrigerator model 79579783901, the ice maker typically does not use a dedicated “reset” button. Instead, you reset it by using the ice maker power switch on the ice maker module (set to OFF, then back to ON) and allowing the freezer to reach 15°F or below; see the 79579783901 owner's manual for the exact control location and labels.

What to check on this model (most common “reset” steps)

• Locate the ice maker module and find the power switch labeled OFF (O) and ON (I).
• Flip the switch to OFF (O) for about 30 seconds.
• Flip it back to ON (I).
• Confirm the freezer is 15°F (-9°C) or colder; the ice maker will not run warmer than that.
• If the unit was just installed or recently reconnected, allow 12 to 24 hours for ice production.
• Discard the first few batches of ice after installation (about 20 cubes) to clear the water line.

Where the control is usually located

On bottom-mount Kenmore 795 refrigerators, the ice maker controls are typically on the ice maker assembly in the freezer compartment, near the ice bin and dispenser chute.

Control you may see	What it does	What it is not
Power switch (OFF/ON)	Turns ice making off and on (acts like a reset)	Not a “test” button
Shutoff arm	Helps stop production when bin is full	Not an off switch
Cube size / water amount button	Adjusts cube size by changing fill amount	Not a reset control

If it still will not make ice

• Make sure the ice bin is installed correctly and not overfilled.
• Check for a frozen fill tube or ice jam in the dispenser path.
• Verify the water supply valve to the refrigerator is fully open.
• If you suspect a water supply issue, the refrigerator water inlet valve MJX41178908 is a common part involved in filling the ice maker.

Why it matters

Using the OFF/ON switch and confirming freezer temperature solves most “no ice” complaints without replacing parts. This model’s ice maker is temperature-dependent and will only start cycling once the freezer is cold enough.

Last updated: February 2026

On Kenmore Elite model 79579783901, DH typically indicates a defrost heater (defrost heating) issue, meaning the refrigerator is not heating properly during the automatic defrost cycle and frost can build up on the evaporator, reducing cooling. Use the 79579783901 owner's manual to confirm the display message and follow the troubleshooting steps.

What you’ll notice when DH is showing

Common symptoms line up with restricted airflow and longer run times:

• Refrigerator section warming up while the freezer may still seem cold
• Frost or ice buildup behind the rear freezer panel
• Fan noise changes as airflow gets blocked by frost
• Ice maker slows down or stops making ice
• Temperature swings after door openings

Quick checks we recommend first

Do these safe, high-value checks before testing parts:

• Power reset: Unplug the refrigerator for 5 minutes, then plug it back in.
• Confirm it is not in a special mode: If the display shows OFF, the unit may be in Demo Mode; the manual explains how to exit it.
• Check door closure: A door not sealing can increase frost and trigger defrost-related problems.
• Listen for the evaporator fan: If airflow is weak, frost buildup is more likely.
• Look for obvious ice blockage: Heavy frost behind the freezer back panel points to a defrost system problem.

Parts commonly involved in a DH (defrost heat) problem

A DH code is usually tied to the defrost circuit (heater, sensor, or control). For this model, these parts are often involved in cooling and defrost performance:

What can fail	What it affects	Example part for this model
Defrost heater	Melts frost off the evaporator	Lg refrigerator defrost heater 5300JK1005D
Temperature sensing	Detects coil temperature for defrost control	Refrigerator temperature sensor and cover ACQ73244001
Main control	Commands defrost and monitors inputs	Refrigerator electronic control board EBR60028302

Why it matters

When the defrost heater system is not working, frost builds up on the evaporator and blocks airflow. The compressor can run longer, food temperatures rise, and you can end up with repeated cooling complaints that look like a “bad fridge” but are actually a defrost failure.

For model-specific error-code behavior and reset guidance, we also use the Kenmore 795 model bottom freezer refrigerator error codes reference.

Last updated: February 2026

Water leaking from the bottom of your Kenmore Elite refrigerator model 79579783901 is usually caused by a defrost drain problem (water cannot flow to the drain pan), a leak in the water supply/dispenser line, or a loose water line connection. Use the steps in the 79579783901 owner's manual to access the right areas safely.

Most common causes (and what to check first)

• Clogged or frozen defrost drain: Meltwater backs up and spills into the fresh food section, then runs down to the floor.
• Leaking water line connection: The manual calls out checking for drips at fittings after turning the water on.
• Cracked or loose dispenser tubing: Small splits can drip and track down to the bottom.
• Ice maker left Off too long with ice bin installed: Melted ice can leak from the dispenser area if the bin is not emptied.

Quick troubleshooting steps (10 to 20 minutes)

1. Unplug the refrigerator before removing panels or reaching near the base grille.
2. Look for the water source:

• Water only after defrost cycles often points to the defrost drain.
• Water near the back lower area often points to water line fittings or the inlet valve.

3. Inspect the water line connections and dry them; then restore water and watch for fresh drips.
4. Check the dispenser and ice bin area for melting ice or water trails.
5. If you see leaking at the valve or fittings, inspect the valve body and tubing.

Parts that commonly fix bottom leaks on this model

Symptom you see	Likely area	Part to consider
Drip at back, near water hookup	Water supply connection	Refrigerator water tubing MJU62070602
Drip or seep at valve body	Inlet valve	Refrigerator water inlet valve MJX41178908
Water pooling inside then running out	Defrost drain path	Refrigerator drain tube 5251JA3003D

Why it matters

Bottom leaks can damage flooring and also create ice buildup in the freezer if the defrost drain is restricted. Fixing the source quickly helps your Kenmore 795 bottom-mount refrigerator cool correctly and prevents repeat puddles.

Last updated: February 2026

Common problems on the Kenmore Elite 79579783901 bottom-mount refrigerator include warm temperatures from airflow issues, ice maker and dispenser troubles, water leaks, door sealing problems, and control or compressor-related failures. We use the troubleshooting steps in the 79579783901 owner's manual to pinpoint the cause before replacing parts.

Most common symptoms and what usually causes them

• Refrigerator or freezer too warm: door opened often, warm room, overloaded shelves, or blocked air vents (items pushed against vents)
• Ice maker slow or not making ice: freezer temp too warm, heavy ice usage, water supply restriction, or dispenser/ice chute issues
• Water leaking or puddles: clogged/iced drain path, loose water line connections, or a seeping inlet valve
• Frost buildup or ice crystals: door not closing fully, gasket not sealing, frequent door openings
• Noisy operation (vibration/rattling): unit not level, weak/uneven floor, items touching the cabinet

Quick checks we recommend before buying parts

1. Confirm temps and adjust correctly: adjust the refrigerator control first, then wait 24 hours before rechecking; adjust the freezer next if needed.
2. Check door closure and gasket seal: clean the gasket and the surface it touches; make sure bins and shelves are fully seated.
3. Look for blocked vents: move packages away from air outlets and returns.
4. Inspect for leaks: check the water line and fittings; look for water near the inlet valve area.
5. Listen for fan noise: a failing evaporator fan can cause warm temps and odd sounds.

Parts that commonly fix these issues on model 79579783901

Symptom	Likely area	Example part for this model
Lights stay off or dispenser acts odd when door closes	Door switch	Refrigerator door switch 6600JB1010A
Water dispenser/ice maker not filling well	Water inlet valve	Refrigerator water inlet valve MJX41178908
Puddles inside or under the unit	Drain system	Refrigerator drain tube 5251JA3003D
Warm temps, poor airflow, fan noise	Evaporator fan	Lg refrigerator evaporator fan motor 4681JB1027C
Frost, sweating, poor seal	Door gasket	Refrigerator door gasket MDS64172919

Why it matters

Temperature and airflow problems can quickly lead to food spoilage, frost buildup, and extra compressor run time. Fixing simple causes (blocked vents, poor door seal, leveling) often restores normal cooling without unnecessary part replacement.

For display or diagnostic codes on Kenmore 795 bottom-freezer models, use our Kenmore 795 model bottom freezer refrigerator error codes reference to match the code to the most likely failure.

Last updated: February 2026

Kenmore Elite refrigerator model 79579783901 is a bottom-freezer refrigerator in the Kenmore 795 family. For the exact exterior width, depth, height, and total capacity for your specific unit (including the color code), use the specifications and installation section in the 79579783901 owner's manual.

Where the exact size is listed

Use these spots to get the authoritative numbers for delivery and cabinet planning:

• Model and serial label inside the fresh food compartment (often on a side wall)
• Installation and clearances section of the 79579783901 owner's manual
• Handle and door removal section if you need to fit through a doorway
• Leveling and door alignment section to account for leveling leg height

How we recommend measuring for delivery and fit

Even with published specs, we recommend confirming your real-world measurements:

• Measure width at the cabinet’s widest point; note whether handles add width.
• Measure height floor to top hinge cover; include leveling leg adjustment.
• Measure depth two ways: cabinet only, then cabinet plus handles.
• Confirm clearance to open doors fully and pull out freezer baskets.
• Leave space behind for airflow and the water line if you have an ice maker.

Planning guide (what to record)

What you need	Record it as	Why
Width	inches (cabinet, then with handles)	Doorway and cutout fit
Height	inches (min and max with leveling legs)	Overhead cabinet clearance
Depth	inches (cabinet, then with handles)	Walkway and counter alignment
Capacity	cubic feet	Storage planning

Why it matters

Exact sizing prevents delivery problems and protects performance. Proper clearances keep airflow open, help doors close correctly, and make water line routing easier for the dispenser and ice maker.

Last updated: February 2026
