Kenmore 66513039K110 undercounter dishwasher Parts

Yes. We still carry replacement parts for Kenmore dishwashers, including model 66513039K110; the key is matching parts by the full model number so you get the correct fit for items like the drain pump, water inlet valve, door latch, and heating element. Use the 66513039K110 owner's manual to confirm features and component locations before ordering.

• Use the complete model number 66513039K110 (not just “665.13039”).
• Match by symptom first (won’t drain, won’t fill, leaking, not drying).
• Compare the part name and part ID, not just a description.
• If your dishwasher is hardwired or uses a power cord, follow the connection guidance in the 66513039K110 installation guide before servicing.
• Replace seals, grommets, and clamps when you open a water path to prevent leaks.

• Confirm the symptom: drain issue vs. wash issue vs. dry issue.
• Check the basics: breaker on, water supply valve open, no kinked drain hose.
• Inspect for leaks: look for wetness under the toe panel and around the door.
• Clean the filter area: buildup can mimic pump problems.

Kenmore dishwashers are built with model-specific variations; ordering by 66513039K110 prevents wrong-fit parts, repeat repairs, and leaks after reassembly.

Last updated: February 2026

Yes, repairing a Kenmore undercounter dishwasher model 66513039K110 is usually worth it when the fix is a common wear item (seal, hose, valve, heater) and the total repair cost stays well below the price of a comparable new dishwasher; major electrical or motor repairs can tip the value toward replacement.

• Repair when the dishwasher is cleaning well overall and you’re fixing one clear failure (leak, no drain, no heat).
• Replace when you have repeated breakdowns, heavy rust in the tub, or multiple expensive parts failing close together.
• Decide by total cost, not just the part price (labor, time, and any extra parts matter).

These are common “single-part” repairs that frequently restore normal operation:

• No heat or poor drying: consider the dishwasher heating element W10518394
• Not draining: consider the dishwasher drain pump WPW10348269 and inspect the drain hose routing
• Leaking at the door: consider the dishwasher door seal and strike kit W10542314
• Not filling or filling slowly: consider the dishwasher water inlet valve WPW10327249
• Poor wash performance tied to filtration: clean or replace the dishwasher filter W10872845

Replacement is the better value when any of these are true:

• The tub is cracked, badly rusted, or the door no longer aligns reliably
• You need a high-cost combination repair (for example, control plus motor/pump work)
• The dishwasher has chronic leaks that return after seals and hoses are replaced
• You want noticeably better efficiency and quieter operation than older designs typically provide

A targeted repair can extend the life of your 66513039K110 and avoid the hassle of reinstalling a new unit. Also, many “long cycle” complaints are normal on water-saving dishwashers; the design uses spray, pauses, and soaking for cleaning, and rinse aid is important for drying performance (details in the 66513039K110 installation guide).

Last updated: February 2026

The model number for your Kenmore undercounter dishwasher is printed on the dishwasher’s model and serial tag. On model 66513039K110, you will typically find that tag on the tub frame around the door opening; check the left or right side edge where the door closes.

Check these common locations in this order:

• On the tub frame (inner door opening), along the left side
• On the tub frame (inner door opening), along the right side
• Along the top edge of the tub opening, just under the countertop lip
• On the side of the inner door panel (visible when the door is open)

Use a flashlight and wipe the area with a damp cloth if the label is covered by detergent residue.

The tag usually lists multiple identifiers. Copy the model number exactly as shown so you get the correct diagrams and replacement parts.

Kenmore dishwashers often have multiple versions that look similar, and small changes affect fit and wiring. Using the exact model number helps us match the right items such as the dishwasher electronic control board WPW10333385 or the dishwasher water inlet valve WPW10327249.

• Take a close-up photo and zoom in
• Look for an etched or stamped number near the printed label
• If the label is peeling, copy the number before it falls off
• Confirm the full suffix (letters and numbers at the end) before ordering

For diagrams and the official identification locations for this model, use the 66513039K110 owner's manual.

Last updated: March 2026
