On the LG DLGX5681W dryer, the Flow Sense (duct blockage sensing) alert clears when you restore proper airflow. Clean the lint filter and fix any vent restrictions, then power the dryer off and back on. Use the duct-check steps in the DLGX5681W owner's manual to confirm the exhaust is flowing correctly.

What “Flow Sense” is actually telling you

Flow Sense is not a button-reset sensor; it is an airflow restriction indicator. When the dryer detects reduced exhaust flow, it alerts you so you can clean or repair the household ductwork to remove restrictions.

Common causes to correct first

• Lint screen clogged or coated with residue
• Crushed, kinked, or overly long vent duct
• Clogged wall cap or bird screen
• Excess lint buildup inside the vent run
• Loose duct connections leaking air

Quick reset steps (after fixing airflow)

1. Turn the dryer off.
2. Unplug the dryer (or switch the breaker off) for 5 minutes.
3. Restore power.
4. Run a timed dry cycle for a few minutes and watch for the alert to return.

If the alert comes back right away

Focus on the venting system. The manual’s installation test (duct check) is designed to flag restrictions and guide you to repair or replace damaged ducting.

Duct check results: what to do

What you see during duct check	What it means	What to do next
Good airflow indication	Venting is acceptable	Keep the vent clean and recheck seasonally
Poor airflow indication (restriction)	Exhaust is blocked or damaged	Clean, shorten, or replace ducting; clear the outside hood

Why it matters

Restricted venting makes the DLGX5681W dry slower, run hotter, and waste energy. Keeping the exhaust path clear improves efficiency and helps prevent repeat Flow Sense alerts.

Last updated: February 2026

On an LG DLGX5681W Sensor Dry cycle, long dry times usually happen when airflow is restricted (lint filter or venting), the load is too large or mixed, or the dryer keeps recalculating time based on moisture readings. Cleaning and correcting airflow typically restores normal cycle length; see the DLGX5681W owner's manual.

What’s normal for Sensor Dry on this model

Sensor Dry cycles are designed to adjust automatically. The display shows an estimated time remaining, but that time can change as the dryer recalculates drying time for best results.

Common reasons Sensor Dry runs long

• Lint filter is not cleaned before the load
• Exhaust duct is blocked, dirty, crushed, or the run is too long
• Load is not sorted (heavy items mixed with lightweight items)
• Large load of heavy fabrics (towels, jeans, comforters)
• Dryer is overloaded (air cannot circulate through the drum)
• Dryer is underloaded (sensors can “hunt” and extend time)

Fixes that usually shorten dry time

1. Clean the lint filter before every load (and mid-cycle for very linty loads).
2. Check airflow: make sure the vent hood opens fully outside and the duct is not kinked.
3. Sort and size loads: dry heavy fabrics separately and keep load sizes consistent.
4. Use the right settings: on Sensor Dry, choosing More Dry or Very Dry increases cycle time; Less Dry or Damp Dry decreases it.

Quick troubleshooting table

Symptom	Most likely cause	Best first step
Dryer runs a long time, clothes still damp	Vent restriction	Inspect and clean venting path
Time remaining keeps changing	Normal Sensor Dry recalculation	Let cycle finish; improve airflow
Heavy items still damp, light items dry	Mixed load	Separate heavy and lightweight items
Dryer seems hot but still slow	Poor airflow or lint buildup	Clean lint filter and venting

When a part is the likely cause

If airflow and load size are correct but drying is still slow, a heating or temperature-sensing issue can extend cycles. For this model, common suspects include the dryer thermistor AGM30045804, the dryer blower thermostat 6931EL3002M, or the dryer high-limit thermostat 6931EL3003C.

Why it matters

Restricted airflow and incorrect load setup force longer run times, reduce drying performance, and can trigger duct blockage sensing behavior. Keeping the lint system and venting clear is the fastest way to get Sensor Dry back to consistent cycle times.

Last updated: February 2026

If your LG DLGX5681W Sensor Dry cycle is not drying, the most common causes are restricted airflow (lint filter or venting), a heat problem (gas ignition or thermostats), or a sensor/temperature input issue that makes the cycle end early. Use the checks in the DLGX5681W owner's manual.

Quick checks that fix most “not drying” complaints

• Clean the lint filter before every load; the display can show a “Check Filter” reminder when the dryer turns on.
• Confirm the lint filter is installed correctly; never run the dryer without it.
• Check the exhaust path for restriction: crushed flex duct, long runs, clogged wall cap, or lint buildup.
• Avoid overloading; Sensor Dry time can change as the dryer recalculates drying time.
• Try a Time Dry cycle as a comparison; if Time Dry also struggles, the issue is usually airflow or heat.

Sensor Dry specifics (why it can stop too soon)

Sensor Dry cycles use moisture sensing to adjust time automatically. If airflow is poor or the load is mixed (very small items with heavy items), the dryer can “think” clothes are dry sooner than they are.

Best practices for Sensor Dry loads

• Dry similar fabrics together (towels with towels, synthetics with synthetics)
• Use the recommended dryness level for the cycle, then increase dryness if needed
• For very small loads, use a short Time Dry instead of Sensor Dry

Heat and control issues to check (gas model symptoms)

If the drum tumbles but clothes stay cool or damp, focus on heating and temperature control components.

Symptom	Most likely area	Common next step
Runs but no heat	Ignition or gas valve circuit	Inspect igniter and gas valve operation
Heats briefly then stops	Overheat protection tripping	Check venting, then thermostats
Ends early, inconsistent dry	Temperature sensing	Test thermistor and wiring

Model-matched parts we commonly see involved:

• LG dryer burner igniter 5318EL3001A
• Dryer gas valve AGM30063309
• Dryer thermistor AGM30045804
• Dryer high-limit thermostat 6931EL3003C

Why it matters

Sensor Dry depends on accurate airflow and temperature feedback. A clogged vent can cause long dry times and overheating, while a failed thermistor or thermostat can cause poor heat control and under-drying.

Last updated: February 2026

For the LG DLGX5681W dryer, the most common problem we see is restricted airflow (lint buildup or a blocked/too-long vent run). Poor airflow causes long dry times, overheating, and safety shutoffs; the dryer may also show a duct blockage alert from its airflow sensing system. See the DLGX5681W owner's manual for airflow alerts and troubleshooting steps.

Most common symptoms (and what they usually point to)

• Clothes take too long to dry: lint filter needs cleaning, exhaust duct is blocked/dirty, or the duct run is too long
• Dryer stops mid-cycle or seems to overheat: airflow restriction triggering protection features
• Lint on clothes: lint filter not cleaned properly or lint screen parts not sealing well
• No heat on gas model: gas supply off, ignition/heating components failing
• Noise or thumping: worn drum belt, idler pulley, or support rollers

Quick checks we recommend first (fast, high-impact)

1. Clean the lint filter every load; never run the dryer without it installed.
2. Inspect the vent path from dryer to outside; remove lint, crushed ducting, and tight bends.
3. Confirm you are using heavy metal venting, not plastic or thin foil duct.
4. Avoid overloading; heavy fabrics and large loads dry slower even when the dryer is working correctly.
5. If the display shows tE1/tE2, the manual points to a thermistor issue.

Common causes and the parts that often fix them

Symptom	Most likely cause	Parts on this model page that commonly apply
Long dry times, hot cabinet	Blocked venting or poor airflow	Dryer lint screen by LG 5231EL1001C, dryer blower thermostat 6931EL3002M
Loud squeal, drum not turning well	Worn belt or pulley	Dryer drum belt 4400EL2001F, dryer idler pulley 4560EL3001A
Thumping/rumbling	Worn drum rollers	Dryer drum support roller 4581EL2002H
tE1/tE2 error	Temperature sensing problem	Dryer thermistor AGM30045804

Why airflow problems matter

Restricted exhaust airflow traps heat and moisture in the drum. That increases drying time, wastes energy, and can trigger airflow restriction alerts and shutdown behavior designed to protect the dryer.

Helpful reference

• For code meanings and what to check next, use LG dryer error codes.

Last updated: February 2026
