Kenmore 11072702100 gas dryer Parts

On a Kenmore gas dryer like model 11072702100, the model number is printed on the model and serial number plate. We typically find that plate just inside the door opening on the cabinet frame; open the door and check the rim area carefully.

• Open the dryer door and inspect the cabinet frame around the opening.
• Check the upper edge of the door opening first, then the left and right sides.
• Look for a sticker or metal plate labeled Model and Serial.
• Wipe dust off the label; numbers can be faint.
• Record both the model and serial number for parts lookup and service.

We use the exact model number to match the correct Kenmore parts diagrams and compatible replacement parts. Even small model-number differences can change items like the dryer door switch, operating thermostat, or drum belt.

Your 11072702100 owner’s manual explains that you will need the complete model and serial numbers when requesting information or service, and it references the model/serial number plate.

Last updated: February 2026

To hard reset your Kenmore gas dryer model 11072702100, unplug it (or switch the breaker off) for about 1 minute, then restore power and try a normal start. This clears many temporary control and start-up issues and gets you back to a clean power-up state.

• Turn the dryer OFF.
• Unplug the power cord (or turn the circuit breaker OFF).
• Wait 60 seconds.
• Restore power.
• Close the door firmly, set a cycle, then press PUSH TO START.
• If the dryer still will not run, use the troubleshooting checks below.

The 11072702100 uses a mechanical timer and start switch; most “won’t start” problems are power, door, or a failed start-interlock component.

• Confirm the outlet has power; reset the breaker or replace a blown fuse.
• Make sure the door is fully closed; the dryer will not run with an open door.
• Press PUSH TO START firmly.
• Check the door switch for a failed actuator or no “click”; replace if needed using dryer door switch WP3406107.
• If the motor hums but the drum will not turn, inspect the belt and idler; replace worn parts such as dryer drum belt 341241.

A hard reset fixes temporary “stuck” conditions, but it will not correct a real failure like a bad door switch, broken belt, or a power supply problem. Doing the quick checks above prevents repeat no-start issues and reduces downtime.

For model-specific operating and troubleshooting details, follow the steps in the 11072702100 owner’s manual.

Last updated: February 2026

For a Kenmore dryer, replacing a heating element typically costs $20 to $100+ for the part and about $100 to $350 total if you hire a technician (part plus labor). On gas dryer model 11072702100, “no heat” is often caused by gas-heat components, not an electric heating element; use the 11072702100 owner’s manual troubleshooting section to confirm symptoms first.

• DIY part-only (electric dryers): $20 to $100+ (more if it’s a full heater housing/assembly)
• Service call and labor: commonly $80 to $250 depending on your area
• Total installed (typical): $100 to $350
• Same-visit extras: vent cleaning, clamps, or a second part if testing finds another failure

This model is a gas dryer, so it does not use the same “heating element” found in many electric dryers. If the dryer runs but won’t heat, common gas-heat fixes include:

• Replacing the gas valve coils: dryer valve coil kit 279834
• Replacing the igniter: whirlpool dryer burner igniter kit 279311
• Replacing a failed operating thermostat: dryer operating thermostat WP3387134
• Addressing restricted airflow (lint screen, vent, outside hood)

• Confirm the dryer tumbles but produces no heat (different from “won’t start”).
• Clean the lint screen and verify strong airflow at the outside vent hood.
• If heat starts then stops, suspect coils or a thermostat rather than airflow alone.
• If you smell gas or suspect a leak, follow the safety steps in the manual and stop using the dryer.

Pricing depends on whether you are replacing a simple component or diagnosing a heat-system failure. On a gas dryer like the Kenmore 11072702100, buying an “electric heating element” by mistake adds cost and delays the repair.

Last updated: February 2026

On Kenmore dryers, the F01 (F1) code indicates an electronic control problem (a fault the control detects in its circuitry or inputs). On your Kenmore gas dryer 11072702100, treat F01 as a control and wiring diagnosis, not a single sensor that always fixes it.

• Unplug the dryer (or switch off the breaker) for 5 minutes to reset the control.
• Restore power and run Timed Dry (no Auto/More Dry) to see if the code returns.
• If the code returns immediately, stop cycling power and move to inspection steps.
• If the dryer is gas and you smell gas, shut off the gas supply and follow the safety steps in the manual.

F01 is most often tied to the control system and its connections.

• Loose or oxidized wire connections at the control or user interface
• Pinched or damaged harness (especially where it passes through panels)
• Moisture or corrosion on the control board
• Failed electronic control board or user interface (depending on design)

If the dryer will not start or stops unexpectedly, a failed door switch can contribute to control faults; the model-matched option is the dryer door switch WP3406107.

When the control cannot reliably read its inputs or operate outputs, the dryer can stop mid-cycle, refuse to start, or behave unpredictably. Correcting wiring issues first prevents unnecessary part replacement.

Use the troubleshooting and safety guidance in the 11072702100 owner’s manual to follow the recommended reset and diagnostic approach for your exact Kenmore dryer.

Last updated: February 2026
