Kenmore Elite 79042623312 electric range Parts

For Kenmore Elite electric range model 79042623312, the model number format starts with a 3-digit prefix that identifies the manufacturer family (here, 790), followed by digits that narrow down the exact series and feature set. Use the full model number when looking up parts and instructions in the 79042623312 owner's manual.

Where to find the model number on a Kenmore range

On most Kenmore ranges, the model and serial tag is typically located in one of these spots:

• On the oven frame behind the storage or warming drawer
• Along the oven door frame (visible when the door is open)
• On the lower frame area near the drawer opening
• Occasionally on the back panel

How to interpret a Kenmore model number (quick breakdown)

Kenmore model numbers are built to help match the correct parts list, wiring, and control configuration.

• Prefix (first 3 digits): manufacturer identifier (example: 790)
• Middle digits: base design and platform (helps match the correct control board, cooktop type, and oven system)
• Last digits: version, color, and feature variations (important for control panel overlays, trim, and racks)

Example using your model

Section	Example	What it tells us
Prefix	790	Manufacturer family code used for many Kenmore ranges
Series/Platform	42623	Identifies the design group and major configuration
Variation	312	Points to a specific version/finish/features

Why it matters for parts and troubleshooting

Using the complete model number prevents mismatches, especially on ranges where similar-looking units use different electronics or sensors. For example, the correct oven temperature sensor and bake circuit parts must match the exact platform.

Common parts that depend on the exact model include:

• Oven temperature sensor
• Bake element
• Control panel components
• Terminal block and power wiring connections

If you are diagnosing temperature issues on this model, a common match is the range oven temperature sensor 5304504897.

Last updated: February 2026

For the Kenmore Elite electric range model 79042623312, the most common problems we see are oven temperature that is inaccurate, the oven not heating evenly, surface elements not heating correctly, and intermittent power or display issues. Many of these symptoms trace back to a failed sensor, heating element, or a loose power connection.

Common symptoms and what they usually point to

• Oven runs hot or cold: often a failing temperature sensor or calibration issue; see owner's manual for calibration steps.
• Bake not working or weak heat: commonly a worn or broken bake element.
• Oven shuts off or overheats: can involve a safety thermostat opening due to high heat or airflow problems.
• Control panel area gets very hot: cooling fan not running or restricted airflow.
• Range seems dead or power cuts in and out: loose or overheated wiring at the terminal block.

Parts that commonly fix these issues

If your symptoms match, these model-compatible parts are frequent solutions:

• Range oven temperature sensor 5304504897
• Range bake element 5304521880
• Terminal block 5304409888
• Range safety thermostat 807144901
• Range control panel cooling fan 318575612

Quick checks we recommend before replacing parts

1. Power reset: turn the breaker off for 1 minute, then back on.
2. Visual inspection (power off): look for burned wires at the terminal block and damaged connectors.
3. Element check: inspect the bake element for blisters, cracks, or separated spots.
4. Temperature verification: test with an oven thermometer across several cycles.
5. Basic electrical testing: use a meter to confirm continuity where appropriate.

Symptom-to-part cheat sheet

Symptom	Most likely part	What it does
Oven temp inaccurate	Temperature sensor	Reports oven temperature to the control
No/weak bake heat	Bake element	Provides primary heat for baking
Intermittent power	Terminal block	Connects house power cord to range wiring
Overheat shutdown	Safety thermostat	Opens circuit if temperatures get unsafe

Why it matters

Accurate heating and stable power protect the control board, improve cooking results, and prevent repeat failures caused by overheating or loose electrical connections.

Last updated: March 2026

A Kenmore Elite electric range like model 79042623312 typically lasts 13 to 15 years with normal household use and basic maintenance. Keeping the oven temperature accurate and preventing heat damage to wiring and controls are the biggest factors in reaching that lifespan.

What affects lifespan the most

• Heat management: blocked vents, heavy self-clean use, or failed cooling airflow can shorten control life.
• Oven accuracy: an out-of-calibration oven runs longer and hotter than needed.
• Electrical connections: loose or overheated power connections can damage the terminal block and wiring.
• Door seal and hinges: heat leaks make the oven work harder.
• Cleaning habits: spills left to bake on can cause smoke, odor, and corrosion.

Quick maintenance checklist (high impact)

• Verify bake temperatures and follow the calibration steps in the owner's manual.
• Keep the door closing tightly; avoid slamming the oven door.
• Use self-clean only when necessary; allow full cool-down afterward.
• If you ever smell hot plastic or see discoloration at the cord connection, stop using the range and inspect the power connection.
• Replace failed heating parts promptly, such as the range bake element 5304521880, to prevent long preheat times and overheating.

Common “end-of-life” symptoms vs. fixable issues

Symptom	Most common cause	Typical fix
Oven won’t heat or heats unevenly	Failed heating element	Replace bake element or related wiring
Oven temperature swings widely	Sensor drifting out of spec	Replace sensor, then calibrate
Control area gets unusually hot	Cooling airflow problem	Check cooling fan, vents, and obstructions
Intermittent power or burning smell	Loose electrical connection	Tighten/replace terminal block and damaged wiring

Why it matters

Knowing the 13 to 15 year average helps you decide whether to repair or replace. If your 79042623312 is within that range and the issue is a wear part (element, sensor, switch), repairs are usually straightforward and restore normal performance.

Last updated: March 2026
