Kenmore Elite 79578763800 refrigerator Parts

A Kenmore Elite refrigerator like model 79578763800 typically lasts 12 to 15 years. Consistent cleaning, good airflow around the cabinet, and prompt repair of cooling or water-leak issues help you reach (and often exceed) that normal service life; see the 79578763800 use & care guide for model-specific care steps.

What affects lifespan the most

These are the biggest factors we see for bottom-mount refrigerators:

• Condenser coil cleanliness: dust buildup makes the compressor run longer and hotter.
• Door seal condition: air leaks force longer run times and can cause frost and moisture issues.
• Air circulation inside: blocked vents reduce cooling performance and increase run time.
• Room temperature and usage: hot kitchens, frequent door openings, and large warm loads add wear.
• Water system health: slow fills, leaks, or ice maker issues can lead to secondary damage.

Maintenance checklist (simple, high impact)

We recommend these habits for the Kenmore 795.7875/7876 family:

• Vacuum and brush the condenser area on a regular schedule.
• Wipe door gaskets and door liners; keep them clean and pliable.
• Keep food from blocking interior air vents.
• Set temperatures to normal targets (about 37°F fresh food, 0°F freezer).
• Replace worn sealing parts promptly; a torn gasket is a common life-shortener.

Common “wear items” vs. major system parts

The manual notes that some items are considered expendable (filters, light bulbs, etc.). Here’s a practical way to think about it:

Category	Examples	Typical impact on lifespan
Routine wear items	Water filters, light bulbs	Low, but neglect can create performance issues
Airflow and sealing parts	Door gaskets, fan motors	Medium to high; affects run time and moisture control
Sealed system components	Compressor, refrigerant tubing	Highest; failures are usually end-of-life level repairs

Why it matters

A refrigerator that runs “too much” is often reacting to heat load, dirty coils, or air leaks. The 79578763800 use & care guide even notes that at normal room temperatures, compressor run time can be roughly 40% to 80% of the time, and higher in warmer conditions. Keeping run time reasonable reduces wear on the compressor and fans.

Last updated: February 2026

Your Kenmore Elite refrigerator’s model number is printed on the identification label inside the fresh food (refrigerator) compartment; on model 79578763800, that label is located on the right-hand side wall. Use the format shown in the 79578763800 owner’s manual to record the model and serial number.

Where to look for the model number label

Check these common label locations first (starting with the most likely for this Kenmore Elite bottom-mount):

• Right-hand side wall inside the refrigerator compartment (fresh food section)
• Upper side wall near the front frame, behind bins or shelves
• Ceiling area inside the refrigerator compartment (less common)
• Side wall inside the freezer drawer (some configurations)
• Behind the base cover or kick plate (occasionally)

What the model number looks like

Kenmore Elite bottom-mount models in this family often use a 795-prefix format. Your full model number should match the complete number on the label (not just the series).

What you see	What it means	Example
795.7876***	Model family and variation; *** is typically a color/finish code	795.78763800
Serial number	Unique production identifier	Varies

Why it matters

We use the exact model number to match the correct parts and diagrams for your refrigerator. Even small differences (like the color/finish digits) can change which door gasket, water inlet valve, or ice maker kit fits.

Quick tips before you write it down

• Copy the model number and serial number exactly as printed (including dots and all digits).
• Take a clear photo of the label for future reference.
• If you are ordering parts, match by model first, then confirm by part ID (for example, refrigerator door switch 6600JB1010A).

Last updated: February 2026

Kenmore is a brand name, so replacement parts for Kenmore Elite refrigerator model 79578763800 are made by the original component manufacturers that supplied the refrigerator and its systems. The most reliable way to match the correct maker and fit is to cross-reference the part listing and diagrams in the 79578763800 owner's manual.

What this means when you shop for parts

Kenmore parts can be sourced from multiple manufacturers across different assemblies (cooling system, ice maker, lighting, door hardware). For your 79578763800 bottom-mount refrigerator, we recommend matching by model number and then confirming by part ID.

• Match parts using the full model number 79578763800
• Use the part ID on the part listing to avoid look-alike parts
• Confirm the part’s location using the exploded-view diagrams
• For electrical parts, compare wire connectors and mounting style
• For water system parts, confirm tubing size and connection type

Examples of manufacturer-supplied components on this model

These are examples of model-matched parts that illustrate how Kenmore-branded appliances use supplier components:

System area	Example part on 79578763800	What it does
Door and lighting	Refrigerator door switch 6600JB1010A	Turns interior lights on/off and signals door status
Water dispensing	Refrigerator water inlet valve MJX41178908	Controls water flow to the dispenser and ice maker
Cooling airflow	Refrigerator evaporator fan motor 4681JB1027C	Circulates cold air through the fresh food section

How to identify the right part maker and exact match

We use the part ID and manufacturer part number to ensure the replacement is the correct supplier-built component for your Kenmore model.

• Find the symptom and related section in the troubleshooting pages
• Locate the assembly diagram for that section
• Match the callout number to the part list
• Verify the part ID and manufacturer part number before ordering

Why it matters

Kenmore appliances often share similar-looking parts across model families, but small differences (connector style, bracket shape, valve ports, gasket profile) can prevent a correct fit. Using the model-specific documentation and part IDs helps you get the right replacement the first time.

Last updated: February 2026

Water leaking from the bottom of your Kenmore Elite refrigerator model 79578763800 is usually caused by a defrost drain that is clogged and overflowing into the base, or a water supply connection that is dripping (often at the inlet valve or tubing). Start by checking for ice or debris in the drain area, then inspect the water line connections for slow drips.

Quick checks (most common causes)

• Clogged defrost drain: Meltwater cannot flow to the drain pan, so it backs up and leaks out.
• Dripping water line connection: A loose compression nut or ferrule can seep and run down to the floor.
• Cracked or pinched water tubing: Small splits can leak only when the dispenser or ice maker calls for water.
• Leaking water inlet valve: The valve can seep or leak at the fittings.
• Door not sealing well: Excess frost can increase defrost water and overwhelm a partially restricted drain.

What to do first (safe, practical steps)

1. Unplug the refrigerator before inspecting anything near wiring or fans.
2. Pull the unit out slightly and look for water trails on the back panel and floor.
3. Check the water supply hookup and tighten any fitting that’s damp (the manual notes to check for drips at connections after turning the water on). See the 79578763800 owner’s manual.
4. If the leak seems to happen after defrosting, clear the drain path and make sure the drain pan area is not blocked.

Parts that commonly fix bottom leaks on this model

If you find the leak is coming from the water system, these model-matched parts are common solutions:

Leak location	What you’ll often see	Part to consider
Back lower area near valve	Drips at fittings or valve body	Refrigerator water inlet valve MJX41178908
Along water line routing	Wet tubing, cracks, kinks	Refrigerator water tubing MJU62070602
Freezer drain outlet area	Water pooling, ice buildup	Refrigerator drain tube 5251JA3003D

Why it matters

A small leak can turn into floor damage and can also cause icing, poor cooling airflow, and recurring puddles. Fixing the source (drain restriction vs. water supply seep) prevents repeat leaks and protects the sealed refrigeration system area.

Last updated: February 2026

Common problems on the Kenmore Elite bottom-mount refrigerator model 79578763800 include warm temperatures from dirty condenser coils, airflow problems from a failed evaporator fan, doors not sealing or closing fully, and ice maker or water dispenser issues tied to the water supply and filtration. Use the 79578763800 owner's manual troubleshooting and care sections to match symptoms to the right fix.

Most common symptoms and what usually causes them

• Not cooling or weak cooling: dirty condenser coils, evaporator fan not running, or defrost system trouble
• Freezer frost or ice crystals: door not closing properly, frequent door openings, or gasket sealing issues
• Doors will not close completely: unit not level, food packages blocking, bins or shelves out of position, sticky gaskets
• Noisy operation: normal operating sounds, or a fan motor starting to fail
• Ice tastes bad or smells: old ice, unwrapped food odors, dirty ice bin, or water quality issues

Quick checks we recommend before replacing parts

1. Confirm doors seal and close: push doors firmly shut; check for packages or bins preventing closure.
2. Clean condenser coils: dirty coils reduce heat transfer and make the compressor work harder.
3. Check airflow: make sure vents are not blocked by food containers.
4. Reset expectations after changes: after cleaning or temperature adjustments, allow time for temperatures to stabilize.
5. For ice issues: discard the first batches after an ice maker install; empty and wash the ice bin if odors persist.

Parts that commonly solve these problems (when diagnosis points there)

Symptom	Common part involved	Example part for 79578763800
Warm fridge/freezer, poor airflow	Evaporator fan motor	Refrigerator evaporator fan motor 4681JB1027C
Water dispenser or ice maker not filling	Water inlet valve	Refrigerator water inlet valve MJX41178908
Door not registering closed, lights acting up	Door switch	Refrigerator door switch 6600JB1010A
Ice or water tastes/odors persist	Water filtration and maintenance	How to replace the water filter in a Kenmore refrigerator

Why it matters

Cooling and ice maker complaints often trace back to basics: clean coils, good door sealing, and steady airflow. Fixing those first prevents unnecessary part replacement and helps the sealed refrigeration system run under normal load.

Last updated: February 2026

On Kenmore Elite refrigerator model 79578763800, the ER IF (Er IF) error code points to an ice fan problem in the freezer area. That fan pushes cold air through ducts to keep the ice maker compartment cold, so ice production and freezer airflow can be affected.

What you’ll notice when ER IF shows up

• Ice maker slows down or stops making ice
• Ice in the bin melts or clumps
• Freezer temperature may drift warmer than normal
• You may hear unusual fan noise (rubbing, buzzing, or no fan sound)
• Frost buildup near the ice room or air ducts

Quick checks we recommend (safe DIY)

1. Power reset: Unplug the refrigerator (or turn off the breaker) for 5 minutes, then restore power.
2. Check for ice blockage: Look for frost or ice restricting airflow around the ice room vents.
3. Confirm door closure: Make sure doors seal fully; warm air leaks can cause frost that jams airflow.
4. Verify temperature settings: Start at 37°F for fresh food and 0°F for freezer; then allow 24 hours to stabilize before changing settings (per the 79578763800 owner’s manual).
5. Listen for the fan: After the unit runs a bit, listen for a steady fan sound from the freezer area.

Parts that commonly relate to airflow and icing

If the error keeps returning after clearing frost and confirming settings, these parts are common suspects in airflow-related problems:

Symptom	Common cause	Example part for this model
Fan noise or no airflow	Fan motor or fan blade issue	Refrigerator evaporator fan motor 4681JB1027C / refrigerator evaporator fan blade 5901JA1021A
Frost and recurring ice blockage	Defrost system not clearing frost	Lg refrigerator defrost heater 5300JK1005D
Water puddles then icing	Drain path restricted	Refrigerator drain tube 5251JA3003D

Why it matters

The ice fan is part of the refrigerator’s cold-air circulation for the ice maker area. When airflow is restricted (ice buildup) or the fan system is failing, temperatures rise where the ice maker needs consistent cold, which triggers ER IF and reduces ice performance.

Last updated: February 2026

The cubic-foot capacity for Kenmore Elite refrigerator model 79578763800 is listed in the specifications information for your exact model and is also commonly shown on the refrigerator’s rating label. Use the 79578763800 owner’s manual to locate the spec section and confirm the total capacity.

Fast ways to find the capacity on the refrigerator

Look for the rating label first; it’s the quickest way to match your exact unit.

• Inside the fresh food compartment on a side wall near the crisper drawers
• On the cabinet frame behind the refrigerator door (hinge side)
• Behind the toe grille (kick plate) area
• On the back exterior panel near the power cord
• In the specifications section of the 79578763800 owner’s manual

What “cubic feet” means (and what it does not)

Capacity is the total interior volume; usable space can feel smaller depending on shelves, ice maker, and bins.

Term you may see	What it refers to	Why it matters
Total capacity (cu. ft.)	Combined refrigerator + freezer volume	Best number for comparing models
Refrigerator capacity	Fresh food section only	Helps if you store more refrigerated items
Freezer capacity	Bottom freezer section only	Helps if you bulk-freeze food

Why the full model number matters

Your full model number 79578763800 identifies the exact configuration (doors, ice room, shelving, and options). That is why we use the model-specific spec listing rather than a broad “typical” capacity range.

• Different revisions can change interior layout
• Ice maker and bin style can affect usable space
• Shelf and drawer designs vary by configuration

Why it matters

Knowing the exact cubic feet helps you compare replacement refrigerators accurately and choose correctly sized replacement parts such as bins, drawers, and shelves.

Last updated: February 2026
