Kenmore Elite 79573167610 refrigerator

Kenmore Elite 79573167610 refrigerator Parts

Here are the diagrams and repair parts for Kenmore Elite 79573167610 refrigerator, as well as links to manuals and error code tables, if available.

By Schematic
By Part
SELECT DIAGRAM
?

This is the number corresponding to the part on the diagram / schematic

Browse Parts for 79573167610 Refrigerator

Kenmore Elite Refrigerator 79573167610 FAQs

On Kenmore Elite refrigerator model 79573167610, there is no separate “reset” button for the temperature sensor; the practical reset is a power reset of the control system. Unplug the refrigerator (or switch off the breaker) for 5 minutes, restore power, then allow 24 hours for temperatures to fully stabilize.

Quick reset steps (safe and effective)

  • Unplug the refrigerator or turn off the circuit breaker.
  • Wait 5 minutes (this clears many control glitches).
  • Restore power.
  • Set the controls back to your normal settings.
  • Keep doors closed as much as possible for the next few hours.
  • Check temps after 4 to 6 hours, and again at 24 hours.

For model-specific control and temperature-setting details, follow the steps in the 79573167610 owner's manual.

If the temperature is still wrong after the reset

A “sensor problem” is often airflow, frost, or a cooling-system issue. Check these common causes first:

  • Air vents blocked by food packages (refrigerator or freezer section)
  • Heavy frost on the evaporator cover (restricted airflow)
  • Dirty condenser area (poor heat release)
  • Door not sealing, causing warm air leaks
  • Fan noise changes (evaporator fan not moving air)

If you suspect the sensor itself is failing, the freezer sensor for this model is the refrigerator freezer temperature sensor ACM73919214.

What to expect after a reset

Time after power restore What’s normal
0 to 1 hour Compressor may delay start; fans may cycle
4 to 6 hours Temps begin trending toward setpoint
24 hours Best time to judge final temperature stability

Why it matters

The temperature sensor tells the control board when to run the compressor and fans. If the sensor reading is off (or airflow is restricted), you can get warm food temps, freezing in the fresh-food section, or long run times.

Last updated: February 2026

Yes. Kenmore Elite refrigerators like model 79573167610 are built as premium, feature-rich units, and they typically deliver strong temperature stability, good storage design, and convenient dispenser options when they are maintained correctly. For the best day-to-day results, follow the care, filter, and temperature guidance in the 79573167610 owner's manual.

What “good” means for the Kenmore Elite 79573167610

A “good” refrigerator is one that holds safe temperatures, runs efficiently, and stays reliable with normal upkeep.

  • Holds steady fresh food and freezer temperatures with minimal swings
  • Seals well so the compressor does not run excessively
  • Dispenses clean-tasting water and makes consistent ice when filters are maintained
  • Stays odor-controlled when the air filter is replaced on schedule
  • Has parts support for common wear items (filters, bins, ice maker components)

Maintenance that keeps performance high

Most “bad fridge” complaints come from skipped maintenance, airflow restrictions, or overdue filters.

  • Replace the water filter on schedule; a clogged filter can reduce water flow and affect ice production
  • Replace the air filter to help control odors and keep airflow fresh
  • Keep vents inside the refrigerator and freezer unblocked by food packages
  • Clean spills quickly to prevent odors and sticky door seals
  • Confirm doors close fully and gaskets seal all the way around

Helpful how-to: how to replace the water filter in a Kenmore refrigerator.

Common parts that affect satisfaction (taste, odors, ice)

If performance drops, these model-matched parts are often involved:

Symptom Most common cause Example model-matched part
Slow water dispensing Clogged water filter Genuine Kenmore refrigerator water filter 9690 AGF80300801
Refrigerator smells Old air filter, spills Lg refrigerator air filter ADQ73214408
No ice or small cubes Filter restriction, ice maker issue Lg refrigerator ice maker AEQ73130004

Why it matters

A refrigerator is only “good” if it protects food safely. Consistent temperatures and clean airflow help prevent spoilage, while fresh filters protect water taste and keep the ice maker working normally.

Last updated: February 2026

Kenmore Elite refrigerator model 79573167610 most often has problems tied to airflow, heat removal, and the ice and water system: warm temperatures from dirty condenser coils, frost buildup from defrost issues, water leaks, and ice maker or dispenser failures. Use the 79573167610 owner's manual to confirm control settings and diagnostic steps.

Most common symptoms and likely causes

  • Not cooling or weak cooling: dirty condenser coil, failed evaporator fan, sealed system or compressor issue
  • Freezer cold but fridge warm: blocked air vents, iced-over evaporator, fan or damper airflow problem
  • Ice maker not making ice: clogged filter, low water pressure, frozen fill tube, ice maker assembly failure
  • Water dispenser slow or not dispensing: restricted filter, kinked water line, inlet valve or dispenser issue
  • Water leaking: clogged defrost drain, loose water line, cracked tubing
  • Bad odors: expired air filter, spills, stagnant airflow

Quick checks we recommend first (before buying parts)

  • Set temps to typical targets: 37°F fresh food, 0°F freezer; allow 24 hours to stabilize.
  • Vacuum and brush the condenser area; confirm the condenser fan (if equipped) runs when the compressor runs.
  • Make sure packages are not blocking return vents and air towers.
  • If the unit is frosting up, do a full manual defrost (unplug, doors open) and see if cooling returns temporarily.
  • For ice and water issues, replace the filter and flush several gallons.

Parts that commonly solve these problems on 79573167610

Problem area What fails most often Example model-matched part
Water tastes bad, slow flow, no ice Clogged water filter Genuine Kenmore refrigerator water filter 9690 AGF80300801
Odors in fresh food section Saturated air filter Lg refrigerator air filter ADQ73214408
No ice or intermittent ice Ice maker assembly Lg refrigerator ice maker AEQ73130004

Why it matters

Most “not cooling” and “ice maker not working” complaints start with restricted airflow or restricted water flow. Cleaning the condenser coil and keeping filters fresh reduces compressor run time, improves temperatures, and prevents repeat failures.

Helpful DIY references

Last updated: February 2026

Most Kenmore Elite refrigerators, including model 79573167610, typically last 10 to 15 years. Regular maintenance (keeping airflow clear, cleaning condenser coils, and maintaining good door seals) helps you reach the high end of that range and reduces cooling and ice maker problems.

What affects refrigerator lifespan the most

  • Condenser coil cleanliness: Dust buildup makes the compressor run hotter and longer.
  • Door seal condition: Air leaks force longer run times and can cause frost and temperature swings.
  • Airflow and loading: Overpacking blocks vents and stresses the evaporator fan.
  • Water and ice system upkeep: Old filters can restrict flow and strain the dispenser system.
  • Room conditions: Hot garages or tight enclosures increase run time.

Maintenance schedule we recommend

Task How often Why it matters
Replace water filter Every 6 months Protects water flow and ice quality
Replace air filter (if equipped) Every 6 months Reduces odors and helps airflow
Clean condenser coil area Every 6 to 12 months Improves efficiency and compressor life
Inspect/clean door gaskets Every 3 to 6 months Prevents warm air leaks and frost

For model-specific locations and steps (filter housing, coil access, and control settings), follow the 79573167610 owner's manual.

Parts that commonly support long-term performance

If you are maintaining the water and odor systems, these model-matched parts are commonly replaced on Kenmore Elite refrigerators:

Why it matters

A refrigerator that is running longer than normal (warm temps, noisy fan, slow water dispensing, or weak ice production) is usually wearing faster. Staying ahead of airflow, filtration, and seals helps the sealed system (compressor, evaporator, condenser) avoid unnecessary strain.

Last updated: February 2026
