What are the parts of a gas stove?
A Crosley gas range like model C31000PAW is built around a cooktop (burners, grates, knobs, ignition) and an oven (racks, door, gasket, broil system). Exact layouts vary by model, but these are the core components you’ll see on most gas stoves.
- Surface burners: burner heads and caps that shape the flame
- Grates: support cookware over the burners
- Control knobs and valves: regulate gas flow and flame size
- Ignition system: spark igniters and wiring that light the burners
- Oven burner and broil burner: provide bake and broil heat
- Oven cavity and racks: cooking space and adjustable shelf positions
- Oven door system: hinges, handle, glass, and door seal (gasket)
- Leveling and safety hardware: leveling legs and anti-tip hardware
These are examples of parts we commonly see replaced on this Crosley model when there’s wear, damage, or missing hardware:
| Part | What it affects | Common symptom |
|---|---|---|
| Range burner control knob WP74002419 | Burner control and usability | Loose, cracked, or missing knob |
| Door hinge W10876639 | Door alignment and sealing | Door sagging, not closing evenly |
| Oven rack WPW10282492 | Rack support and positioning | Bent rack, won’t slide smoothly |
| Grate (black) W11400301 | Cookware stability | Warped grate, rocking pans |
Knowing the main parts helps you troubleshoot faster. For example, uneven flames usually point to burner or ignition issues, while heat loss and long preheat times often relate to the oven door seal, hinges, or burner performance.
- If a burner won’t light, clean the burner ports and dry the cap and head fully.
- If the flame is weak or yellow, check for clogged ports and confirm proper gas supply.
- If the oven seems cool, verify you’re using Bake (not Broil) and allow full preheat.
- If the door doesn’t seal, inspect hinge alignment and look for gaps around the door.
For a deeper overview of stove components and what they do, use our what are the main parts of a stove guide.
Last updated: February 2026
Why is my CROSLEY oven not igniting?
If your Crosley C31000PAW gas range oven is not igniting, the most common causes are a weak/hot-surface igniter, a gas supply issue, or a problem in the bake ignition circuit (wiring, safety valve, or control). Start by confirming you have gas and power, then watch and listen for ignition.
- Make sure the range has power (clock/display on, oven light works).
- Confirm the gas shutoff valve is fully open.
- Try a cooktop burner; if it will not light, the issue is usually gas supply.
- Set the oven to Bake and listen: repeated clicking or no sound helps narrow the cause.
- Look through the oven bottom vents (if visible) for an igniter glow.
| What you notice | Most likely cause | What to do next |
|---|---|---|
| No igniter glow at all | No power to igniter, failed igniter, wiring/control issue | Check power, then inspect wiring and igniter connections |
| Igniter glows but no flame | Weak igniter or gas safety valve not opening | Replace igniter first in most cases |
| Flame lights but goes out | Flame sensing/ignition stability issue | Clean burner area, check burner alignment and air shutter |
| Strong gas smell | Gas present but not igniting | Stop, ventilate, and do not keep cycling Bake |
- Weak igniter: In gas ovens, a weak igniter can glow but not pull enough current to open the safety valve.
- Gas supply problem: Shutoff valve partially closed, empty LP tank (if propane), or supply interruption.
- Dirty or misaligned bake burner: Spills can block burner ports and delay ignition.
- Control or wiring issue: Loose connector, damaged wire, or a failing control not sending power to the igniter.
We list model-specific parts for the C31000PAW, but the igniter and gas valve are not shown in the parts provided here. For common oven-related hardware you may see during access or reassembly, match what you remove to the correct item, such as the oven screw W11693756.
A gas oven that will not ignite can lead to delayed ignition, poor baking performance, or a gas odor. Diagnosing by symptom (no glow vs glow/no flame) helps you replace the right part the first time.
Last updated: February 2026
How do I find the model number on my C31000PAW?
The model number for your Crosley gas freestanding range is printed on the appliance’s rating label. On most ranges like the C31000PAW, you can find that label around the oven door frame or on the storage drawer frame when the drawer is pulled out.
Check these common spots in this order:
- Open the oven door and look along the left or right door jamb (front frame)
- Look along the bottom front frame under the oven door
- Pull out the storage drawer and check the frame behind it
- Check the back panel of the range (if you can safely access it)
The rating label is usually a small sticker or metal plate. It typically includes:
- Model number (example: C31000PAW)
- Serial number
- Gas type (natural gas or LP)
- Electrical rating (volts/amps)
| What you see | What it means | What to do next |
|---|---|---|
| C31000PAW | Full model number | Use it to match diagrams and parts |
| Extra letters or numbers after the model | Revision or series info | Include it when ordering if shown |
| Serial number only | Not enough for parts matching | Keep looking for the model line |
Using the exact model number from the rating label helps us match the correct Crosley range parts (like an oven rack, door hinge, or burner control knob) so the replacement fits and functions correctly.
Once you confirm the model number, use the parts list for C31000PAW to choose the exact replacement. For example, if you need a knob, compare your existing knob to options like the range burner control knob WP74002419 or range burner control knob WP74002353.
Last updated: March 2026
