Kenmore 79094142312 electric freestanding range Parts

To reset your Kenmore electric range model 79094142312, turn the range off, then cycle power at the home breaker (or remove the fuse) for about 1 minute and restore power. After power returns, reset the clock and reselect your oven function as needed.

Quick reset steps (recommended)

• Turn all surface element knobs to OFF.
• If the oven is running, press Cancel/Off (if your control has it).
• Switch the range circuit breaker OFF (or remove the range fuse).
• Wait 60 seconds.
• Switch the breaker ON (or reinstall the fuse).
• Set the clock, then test Bake and Broil.

If the reset was after a power outage

Your 79094142312 is designed so that if power fails, you should turn the range off; when power resumes, you reset the clock and oven function. For control-specific button sequences and display messages, follow the 79094142312 owner's manual.

What a reset fixes (and what it usually does not)

Symptom	Reset helps?	What to check next
Control panel frozen or unresponsive	Yes	Try breaker reset again; check house power
Oven not heating to temperature	Sometimes	Test the frigidaire range oven temperature sensor 316490000 and inspect wiring
Oven not heating at all in Bake	Sometimes	Inspect the frigidaire range bake element 316075103 for damage
Surface element not heating	Sometimes	Check the correct surface switch and element receptacle

Why it matters

A breaker reset clears many temporary electronic control glitches and restores normal operation after a power interruption. If heating problems continue after the reset, the issue is usually a failed heating component (bake element, sensor) or a wiring connection that needs diagnosis.

Last updated: February 2026

On Kenmore electric range model 79094142312, replacing the oven temperature sensor is a straightforward repair: shut off power, remove the sensor mounting screws inside the oven, disconnect the wire connector, then install the new sensor and restore power. See the steps in the 79094142312 owner's manual.

Before you start (safety and prep)

• Turn off power at the breaker (ranges use high voltage).
• Let the oven cool completely.
• Pull the range forward only as needed; protect the floor.
• Have a Phillips screwdriver and work gloves ready.
• If you need to test the circuit, use a meter and follow how to use a multimeter to test electrical parts video.

Replacement steps (typical for this Kenmore/Frigidaire-built range)

1. Disconnect power at the breaker.
2. Open the oven door and locate the sensor probe on the rear oven wall.
3. Remove the two mounting screws holding the sensor.
4. Gently pull the sensor toward you a few inches until the connector is accessible.
5. Disconnect the wire plug (do not pull on the wires).
6. Connect the new sensor, tuck the connector back through the opening, and reinstall the screws.
7. Restore power and run a Bake test.

If the oven temperature is still off after replacement

Sometimes the sensor is fine and the oven just needs calibration. The 79094142312 control lets you adjust the user programmable offset (UPO) up to +35°F or -35°F.

• Use the calibration procedure in the 79094142312 owner's manual.
• Avoid grocery-store oven thermometers for calibration checks; they can be off by 20°F to 40°F.

Quick comparison: sensor problem vs calibration problem

What you notice	More likely cause	What to do first
Big swings, overheating, error symptoms	Sensor or wiring issue	Replace sensor, inspect connector
Consistently a little hot or cool	Calibration (UPO)	Adjust UPO and retest

Why it matters

A working oven temperature sensor helps the control board regulate bake cycles accurately. When the sensor or its connection fails, you can get undercooked food, overheating, or unreliable preheat performance.

Last updated: February 2026

The Kenmore 79094142312 electric freestanding range uses the 790.9414* platform shown in the 79094142312 use and care guide; for exact oven capacity (cubic feet) and the appliance’s exterior dimensions, use the specifications section in the manual and the 79094142312 installation guide, which lists the required cutout and clearance measurements.

What “size” usually means for a range

“Size” can refer to more than one measurement. Here’s how we recommend confirming it for model 79094142312:

• Oven capacity (cubic feet): how much the oven cavity holds
• Overall width (typically 30 inches for most freestanding ranges)
• Overall depth (varies with handle and rear panel)
• Overall height (often adjustable with leveling legs)
• Required clearances: space to walls, cabinets, and flooring

Quick reference: which document to use

What you need	Best place to check	Why
Oven capacity (cu ft)	79094142312 use and care guide	Lists model specs and operating details
Overall dimensions and clearances	79094142312 installation guide	Provides fit, spacing, and safety clearances
Rack positions and usable cooking levels	79094142312 use and care guide	Helps you understand usable interior space

Why it matters

Getting the correct “size” prevents installation surprises (cabinet fit, door swing, clearance to combustibles) and helps you choose the right accessories and parts, such as an oven rack 316496201 or heating components like the frigidaire range bake element 316075103.

Helpful tips when measuring at home

• Measure width at the widest point (often the cooktop lip).
• Measure depth with the door closed, then note handle depth separately.
• Measure height to the cooktop, and check whether leveling legs are extended.
• If you are replacing an older unit, compare opening size to the installation clearances.

Last updated: February 2026

On Kenmore electric freestanding ranges like model 79094142312, the model and serial information is typically on the serial plate located on the lower right front frame of the range. On some units, the plate can also be under the cooktop; confirm the exact location in the 79094142312 installation guide.

Where to look first (fastest checks)

• Open the oven door and look along the lower right front frame (front edge of the range body).
• Use a flashlight and look for a silver or white rating plate with model and serial numbers.
• If you do not see it on the frame, check under the cooktop (some versions place the plate there).
• Wipe grease and dust off the frame lip; the label can blend into the paint.
• Write the full model number exactly as shown (including any dots or suffix characters).

What the label usually looks like

Most Kenmore range rating plates include:

• Model number (example: 79094142312)
• Serial number
• Electrical ratings (volts/amps)
• Manufacturer information

Location	What you will see	Why it helps
Lower right front frame	Rating plate with model and serial	Best place to confirm the exact model for parts
Under the cooktop	Alternate rating plate location	Used on some builds of this range platform

Why it matters

We use the exact model number to match the correct parts and diagrams for your range, especially for electrical items like a bake element, oven temperature sensor, or surface element control switch.

Helpful tip before ordering parts

• Match the model number character-for-character.
• If the label is worn, take a clear photo and zoom in.
• Cross-check the model format in the 79094142312 owner’s manual.

Last updated: February 2026
