Kenmore Elite 79579759904 refrigerator

Kenmore Elite 79579759904 refrigerator Parts

Here are the diagrams and repair parts for Kenmore Elite 79579759904 refrigerator, as well as links to manuals and error code tables, if available.

By Schematic
By Part
SELECT DIAGRAM
?

This is the number corresponding to the part on the diagram / schematic

Browse Parts for 79579759904 Refrigerators

Kenmore Elite Refrigerator 79579759904 FAQs

A Kenmore Elite refrigerator like model 79579759904 typically lasts 12 to 15 years. Keeping the condenser area clean, maintaining good airflow around the cabinet, and fixing small issues early (like a weak door seal or noisy fan) helps you reach the upper end of that range.

Typical lifespan and what affects it

Most refrigerators fall into a fairly consistent life-expectancy range, but real-world lifespan depends heavily on heat, airflow, and how hard the sealed system has to work.

  • Typical lifespan: 12 to 15 years
  • Often shorter when: coils are clogged with dust, the unit is packed tightly into a cabinet, doors are opened frequently, or the door gasket leaks
  • Often longer when: coils are kept clean, temperatures are set correctly, and airflow is unobstructed
Item Best practice What it helps prevent
Temperature settings Keep fridge about 37°F and freezer about 0°F Overworking the compressor, food spoilage
Airflow Leave space behind/above the refrigerator High compressor run time
Cleaning Vacuum dust from condenser area periodically Poor cooling, overheating
Door closing Make sure doors seal and close fully Frost buildup, warm temps
Maintenance checklist to help it last longer

We recommend these practical steps for Kenmore bottom-mount refrigerators:

  • Vacuum dust from the condenser area and surrounding vents.
  • Confirm the doors close on their own and the gasket seals all the way around.
  • Keep food from blocking interior air vents.
  • Replace water filters on schedule if your model uses one.
  • Address unusual noises quickly (fan rubbing, clicking, buzzing).
Why it matters

A refrigerator that runs hot or leaks cold air cycles longer, which increases wear on key components like the compressor, evaporator fan motor, and defrost system. Small airflow and sealing fixes can prevent expensive cooling failures later.

Model-specific help

For care, cleaning guidance, and operating tips specific to Kenmore 79579759904, use the 79579759904 owner's manual.

Last updated: January 2026

Kenmore Elite refrigerator model 79579759904 is a bottom-mount style refrigerator; the exact exterior dimensions and capacity vary by configuration and are listed in the product specifications for this model. For the most accurate size details (height, width, depth, and capacity), use the specifications section in the 79579759904 owner's manual.

What “size” usually means for this model

When customers ask for the size of a Kenmore bottom-mount refrigerator, they typically mean one or more of these measurements:

  • Overall width (cabinet width, not including door swing clearance)
  • Overall height (to top of hinge cover)
  • Overall depth (with doors and handles)
  • Capacity (cubic feet)
  • Clearances needed for airflow and door opening
How to measure your refrigerator correctly

We recommend measuring your unit in place so you can confirm fit through doorways and into the cutout.

  • Measure width at the widest point of the cabinet
  • Measure height from floor to the highest point (often the hinge cover)
  • Measure depth from the back to the front of the handle (if installed)
  • Add clearance for door swing and drawer pull-out (bottom freezer needs extra front clearance)
Typical size range for Kenmore 795 bottom-mount refrigerators

Most Kenmore 795-series bottom-mount units fall into a common footprint range; use this as a planning guide, then confirm the exact specs in the manual.

Spec Typical range (planning) What to verify for 79579759904
Width 32 to 36 in. Cabinet width and door swing clearance
Height 67 to 71 in. Height to top of hinge cover
Depth 30 to 35 in. Depth with handles and doors
Capacity 20 to 25 cu. ft. Total and compartment capacities
Why it matters

Correct size and clearance prevents installation problems like doors that cannot open fully, freezer drawers that hit an island, poor airflow that causes warm temperatures, and water line kinks behind the cabinet.

Last updated: January 2026

Ice on the freezer floor almost always means the defrost drain is clogged or restricted, so meltwater can’t flow to the drain pan and instead refreezes at the bottom. On Kenmore Elite model 79579759904, clearing the drain and confirming the drain tube is open typically fixes the problem; see the 79579759904 manual for access and cleaning guidance.

Most common causes
  • Defrost drain hole blocked by ice, food debris, or sludge
  • Drain tube restricted or frozen
  • Door left slightly open, causing excess frost and meltwater
  • Warm, humid air leaks from a worn or dirty door gasket
  • Freezer overpacked, blocking airflow and increasing frost buildup
Quick fix: clear the defrost drain
  1. Unplug the refrigerator.
  2. Remove the freezer drawer/baskets and the rear freezer panel (if equipped).
  3. Melt the ice at the bottom using a hair dryer on low or warm towels.
  4. Locate the drain hole under the evaporator area and flush it with hot water.
  5. If water backs up, clear the tube from the top and (if accessible) from the rear drain outlet.

If you need the drain tube itself, the model-specific replacement is the refrigerator drain tube 5251JA3003D.

Helpful flush mixture

Use a mild cleaning flush after the ice is melted:

  • 2 cups hot water
  • 1 teaspoon baking soda

Pour slowly into the drain opening, then follow with plain hot water until it drains freely.

What to check next (so it doesn’t come back)
Check What “good” looks like What to do if not
Drain flow Hot water runs to the drain pan Clear tube again; remove sludge buildup
Door seal Even contact all around Clean gasket; adjust door alignment
Airflow Vents not blocked by packages Reorganize freezer contents
Why it matters

A clogged defrost drain can cause recurring ice sheets, water leaks, and temperature swings that stress the evaporator fan and cooling system.

Last updated: January 2026

Common problems on the Kenmore Elite refrigerator model 79579759904 include warm temperatures from airflow or defrost issues, water leaking from a clogged defrost drain, dispenser or ice maker problems from low water supply, and door-related issues that keep lights on or cause poor sealing. Use the 79579759904 owner's manual to match symptoms to the correct checks.

Most common symptoms and what usually causes them
  • Not cooling or weak cooling: dirty condenser area, failed fan, frost buildup from a defrost problem
  • Freezer cold but fridge warm: restricted airflow, evaporator fan issue, iced-over evaporator
  • Water under the refrigerator or in the freezer: clogged/iced defrost drain or drain tube
  • No ice or no water dispensing: kinked tubing, clogged filter, failing inlet valve
  • Lights stay on or unit beeps when door is shut: door switch not closing properly
Quick checks we recommend before replacing parts
  1. Confirm temperature settings and allow 24 hours after changes.
  2. Make sure vents inside the fresh food section are not blocked by food packages.
  3. Clean dust from the condenser area (unplug power first).
  4. Check for frost buildup on the rear freezer panel (a strong clue of a defrost issue).
  5. Inspect the water line for kinks and verify household water supply is fully open.
Parts that commonly fix these problems on model 79579759904
Symptom Likely part area Example part for this model
Door ajar alarms, lights acting up Door sensing Refrigerator door switch 6600JB1010A
Leaking or puddles Defrost drain path Refrigerator drain tube 5251JA3003D
No water/ice, slow fill Water supply control Refrigerator water inlet valve MJX41178908
Warm temps, noisy freezer Air circulation Lg refrigerator evaporator fan motor 4681JB1027C
Why it matters

Catching the root cause early protects food, prevents water damage, and avoids overworking the compressor. For example, a simple drain restriction can look like a major leak, and a door switch issue can keep lights on and add heat inside the cabinet.

Related help: Kenmore 795 model bottom freezer refrigerator error codes

Last updated: January 2026
