How do I tell what model my Kenmore dryer is?
Your Kenmore dryer’s model number is printed on the model and serial number label; on model 11068422700, that label is located at the top inside the dryer door well. Once you have the full model number and serial number, you can match the correct parts, wiring, and venting requirements.
Where to look for the model number label
We recommend checking these common spots in this order:
- Top inside the dryer door well (most common for Kenmore 110-series dryers)
- Inside the door opening on the cabinet frame
- On the back panel (less common)
- Near the lint screen housing (some designs)
For a picture-based reference and the exact wording used for “model and serial number label,” use the 11068422700 owner's manual.
How to read the number once you find it
Kenmore model numbers often start with a prefix that helps identify the platform.
| What you see | What it usually means | Why it helps |
|---|---|---|
| 110.xxxxxxxxx | Common Kenmore/Whirlpool-built platform | Best match for parts like belts, thermostats, and switches |
| 796.xxxxxxxxx | Common Kenmore/LG-built platform | Parts and service procedures differ |
| 417.xxxxxxxxx | Common Kenmore/Frigidaire-built platform | Error codes and components differ |
Write the model number exactly as shown (all digits), then record the serial number too.
Why it matters for parts and troubleshooting
Using the exact model number prevents ordering the wrong component and helps you follow the right disassembly steps.
Common model-specific parts that vary by platform include:
- Drum belt length and rib count (example: dryer drum belt 341241)
- Heating system components (example: dryer element 279838)
- Door safety circuit parts (example: dryer door switch WP3406107)
- Thermal safety parts and thermostats
Quick tips before you order parts
- Copy the model number and serial number into your phone notes
- Take a clear photo of the label for reference
- Match the part by part name and part ID, not by appearance alone
Last updated: February 2026
How much to replace a dryer start switch?
For Kenmore dryer model 11068422700, replacing the start switch typically costs $25 to $75 for the part, plus labor if you hire service (often $150 to $300 total depending on rates and access). If the dryer will not start, we also check power, door closure, and the push-to-start action first.
Typical cost breakdown
- DIY part only: $25 to $75 (most common range for a push-to-start style switch)
- Service call/labor: $100 to $250+ (varies by area and whether the dryer must be disassembled)
- Total installed: $150 to $300 is common for a straightforward visit
| Scenario | What you pay for | Typical total |
|---|---|---|
| DIY replacement | Part only | $25 to $75 |
| Pro replacement | Part + labor/service call | $150 to $300 |
| Not the switch | Diagnosis + different part | Varies |
Before you buy a start switch (quick checks)
The manual and installation guide both point to a few basics that commonly mimic a bad start switch:
- Confirm a cycle is selected (not an Off area).
- Press the start control firmly.
- Make sure the door is fully closed.
- Verify the dryer has the correct power supply; many electric dryers need 240V.
- Check both household fuses or breakers (some dryers use two).
For the exact start procedure and “won’t start” checks, use the 11068422700 owner’s manual.
When the switch is the likely problem
A start switch is a strong suspect when:
- The dryer has power, but nothing happens when you press start.
- You have to press very hard or wiggle the button to get it to run.
- The button feels loose, sticks, or does not “click” consistently.
Why it matters
A weak start switch can cause intermittent no-start complaints that look like a motor or timer issue. Verifying power, door switch operation, and correct cycle selection first helps you avoid replacing the wrong part.
Last updated: February 2026
How to hard reset a Kenmore dryer?
For Kenmore dryer model 11068422700, a hard reset is a power reset: unplug the dryer (or switch the breaker off) for about 1 minute, then restore power and start a Timed Dry heated cycle. This clears most control and cycle interruptions.
Hard reset steps (safe, works for most issues)
- Turn the Cycle Selector to Off.
- Unplug the dryer (or turn OFF the circuit breaker).
- Wait 1 minute.
- Restore power.
- Close the door fully.
- Select Timed Dry with heat (not Air Only).
- Press PUSH TO START firmly.
For cycle and control details specific to this model, follow the 11068422700 owner's manual.
If it still will not start after the reset
The installation checklist for this dryer points to a few common “no start” causes:
- Controls are set to a running or On position
- Start button was not pushed firmly
- Dryer is plugged in (or direct-wire power is reconnected)
- House fuse is intact, or the breaker is not tripped
- Dryer door is fully closed (a failed door switch can prevent starting)
If the door feels fine but the dryer acts like it is open, the dryer door switch WP3406107 is the common interlock part to check.
What the reset does (and does not) do
| Situation | Power reset helps? | What to check next |
|---|---|---|
| Control seems “stuck” or cycle will not restart | Yes | Door closed, cycle set, press Start firmly |
| Dryer runs but no heat | Sometimes | Venting, heater circuit, thermostats, thermal cut-off |
| Dryer will not run at all | Sometimes | Power supply, door switch, start switch, motor circuit |
Why it matters
A power reset is the fastest way to clear a paused cycle or minor control glitch without replacing parts. If the dryer still will not start, the next steps are verifying power and the door interlock, because the dryer will not run with an open-door signal.
Last updated: February 2026
What does sru cll mean on a dryer?
On Kenmore dryer model 11068422700, “SRU CLL” is best treated as a service/diagnostic prompt on the display, not a normal cycle option. The practical next step is to reset power and then check the basics that commonly trigger control messages.
What to do first (fast checks that fix many display messages)
- Unplug the dryer or switch off the breaker for 2 minutes, then restore power.
- Confirm the door closes fully and the Start button is pressed firmly.
- Verify the dryer has full 240V power (a tripped breaker can leave you with partial power).
- Clean the lint screen; check the exhaust duct for crushing or blockage.
- Start a Timed Dry heated cycle (avoid Air Only) and watch whether the message returns.
If the message returns: what to troubleshoot next
These checks match the most common dryer conditions that lead to service-type prompts.
| Symptom you also see | Most likely area | Example part used on this model |
|---|---|---|
| Won’t start | Door circuit | Dryer door switch WP3406107 |
| Runs but no heat | Heating circuit | Dryer element 279838 |
| Stops, then no heat | Thermal protection opened | Dryer thermal cut-off fuse kit 279816 |
| Long dry times, very hot cabinet | Vent restriction, overheating | Dryer high-limit thermostat WP3977767 |
Why it matters
A service-style display message often shows up when the dryer is protecting itself from an electrical, heating, or airflow problem. Fixing airflow and power issues first prevents repeat no-heat failures and nuisance shutdowns.
Where to confirm the exact display meaning for your control
Use the model documentation to run any built-in checks and follow the recommended reset/diagnostic steps: 11068422700 installation guide. For additional Kenmore display-code patterns, compare symptoms in Kenmore 110 series electronic control model dryer error codes.
Last updated: February 2026
