LG LBC24360ST/03 bottom-mount refrigerator Parts

A bad compressor in an LG LBC24360ST bottom-mount refrigerator usually shows up as warming temperatures with little or no steady compressor run sound, or repeated clicking from the lower rear area as the compressor tries to start and then shuts off. Confirm basics first before replacing major parts.

Quick checks before blaming the compressor

• Verify the refrigerator has power and the interior lights come on.
• Listen for a steady low hum from the compressor area; repeated clicking every few minutes points to a start or overload issue.
• Check that the condenser fan (near the compressor) runs when the unit is calling for cooling.
• Make sure the condenser coil is not packed with dust.
• Confirm the freezer is not heavily frosted, which can mimic a sealed-system problem.

Parts that commonly cause “clicking” or no-start symptoms

In many cases, the compressor is fine and a start-protection part is opening due to heat or electrical load.

Symptom	More likely cause	Example part for LBC24360ST
Clicks, then silence; compressor never stays on	Overload protector or start components	Refrigerator compressor overload protector 6750CL0001D
Runs but cooling is weak	Airflow issue, dirty coil, fan problem, or sealed-system issue	Refrigerator condenser coil ACG73946401
Warm fridge, freezer also warming; fan noise missing	Evaporator fan not moving air	LG refrigerator evaporator fan motor 4681JB1027C

Model-specific diagnostic help (built-in)

Your LG LBC24360ST has a Smart Diagnosis feature that can transmit data to LG support when instructed. The steps and phone placement details are in the LBC24360ST owner’s manual.

Why it matters

A compressor replacement is one of the highest-cost refrigerator repairs. Ruling out airflow problems, dirty coils, and overload/start protection issues first helps you avoid replacing the compressor when a smaller part is actually failing.

Last updated: January 2026

Most LG refrigerators typically last 13 years with normal home use and basic maintenance. For the LG LBC24360ST bottom-mount refrigerator, keeping airflow clear, doors sealing tightly, and temperatures stable helps the compressor and sealed system run longer; see the LBC24360ST owner's manual for care and operating guidance.

Typical lifespan and what affects it

A refrigerator’s life depends more on operating conditions and maintenance than brand alone.

• Condenser cleanliness (dust buildup makes the compressor work harder)
• Door gasket condition (air leaks cause longer run times)
• Room temperature and ventilation (tight cabinets trap heat)
• How often doors are opened and how full the compartments are
• Defrost and airflow health (ice buildup or a weak fan reduces cooling)

Quick maintenance checklist (best ROI)

These steps help prevent common cooling and ice maker complaints.

• Vacuum condenser area and grills every 6 to 12 months
• Confirm freezer and fresh food temps are stable (typical targets: 0°F freezer, 37°F fridge)
• Inspect and clean door gaskets; replace if torn or permanently deformed
• Keep vents inside the refrigerator and freezer unblocked
• If you have water and ice, replace filters on schedule and keep supply pressure steady

Parts that commonly impact longevity on this model

If cooling performance drops, these parts are frequent suspects on bottom-mount designs.

Symptom	Common cause	Example part for LBC24360ST
Warm fridge, freezer OK	Weak/iced evaporator airflow	LG refrigerator evaporator fan motor 4681JB1027C
Temps swing, frost issues	Sensor/defrost feedback problem	Refrigerator defrost sensor assembly 6615JB2005N
Poor cooling, long run times	Sealed system or compressor issue	Refrigerator compressor TCA38091801

Why it matters

A refrigerator that runs longer than normal to hold temperature uses more energy and puts extra wear on the compressor and sealed system. Catching airflow, gasket, and sensor problems early is the simplest way to extend service life.

Last updated: January 2026

Excess frost or ice buildup in the freezer area is one of the most common problems we see on LG bottom-mount refrigerators like model LBC24360ST. In many cases, it traces back to a defrost issue, a door that is not sealing tightly, or airflow being blocked by ice.

Quick checks that solve a lot of “LG refrigerator” complaints

• Make sure the freezer drawer closes fully and nothing is preventing it from sealing.
• Look for gaps, rips, or hardened spots on the freezer door gasket.
• Check for heavy frost on the back freezer panel (a classic sign of a defrost or airflow problem).
• Confirm vents are not blocked by food packages.
• If you notice a burning-plastic smell or smoke, unplug the refrigerator immediately and contact Sears PartsDirect support or a qualified technician.

What to inspect first (most likely causes)

If the freezer is frosting up, start with the items that most often create the problem.

Symptom you notice	Most common cause	What to do next
Frost around the drawer opening	Door not sealing, drawer not closing	Inspect gasket and alignment; clean sealing surfaces
Frost sheet on back freezer wall	Defrost system not clearing ice	Check defrost sensor and evaporator area for ice
Warm fridge, freezer packed with frost	Evaporator fan airflow restricted by ice	Defrost and check fan operation
Random temperature swings	Sensor or control issue	Run basic checks; follow diagnostic steps in the manual

Parts that are commonly involved

These parts are often part of the troubleshooting path for frost, temperature, and airflow problems on this model:

• Refrigerator defrost sensor assembly 6615JB2005N (helps the control manage defrost operation)
• Refrigerator evaporator fan motor 4681JB1027C (moves air across the evaporator and through the compartments)

Why it matters

Frost buildup is not just an inconvenience; it can block airflow through the evaporator, forcing longer run times, warmer fresh-food temperatures, and inconsistent cooling.

Model-specific tip

Use the troubleshooting and diagnostic steps in the LBC24360ST owner's manual for the correct checks and access instructions.

Last updated: March 2026
