Kenmore Elite 25344743110 refrigerator Parts

Your Kenmore Elite refrigerator model 25344743110 has a capacity measured in cubic feet, which is the usable interior volume. The most accurate capacity for your exact model is listed on the model’s rating label and in the 25344743110 owner's manual.

Use these quick checks (no tools required):

• Check the rating label (often inside the fresh food compartment on a side wall, ceiling, or near a crisper frame).
• Look for wording like “Capacity”, “Total volume”, or “cu. ft.”
• Confirm you’re reading the full model number: 25344743110.
• Use the 25344743110 owner's manual to match the label location and terminology.
• If the label is missing or unreadable, use the measurement method below for a close estimate.

Cubic feet is calculated from interior dimensions:

Formula:

• Cubic inches = width × height × depth
• Cubic feet = cubic inches ÷ 1,728

Multiplying only two dimensions (for example, depth × height) gives square inches, not volume. To get cubic feet, you must multiply width × height × depth, then divide by 1,728.

Most Kenmore Elite refrigerators in this general family fall in the roughly 20 to 27 cu. ft. range depending on configuration and insulation thickness. The rating label and 25344743110 owner's manual give the exact number for your unit.

Last updated: February 2026

Kenmore is a brand name, and the actual manufacturer is identified by the model number prefix. For Kenmore Elite refrigerator model 25344743110, the 253 prefix indicates it was manufactured by Frigidaire (Electrolux). You can confirm the full model and serial information on the refrigerator’s identification tag and in the owner's manual.

We use the first three digits of many Kenmore model numbers as the quickest identifier.

• Find the model/serial tag inside the fresh food compartment (commonly on a side wall)
• Verify the model number is exactly 25344743110
• Use the prefix 253 to identify the manufacturer as Frigidaire (Electrolux)
• Record the serial number too; it helps match the correct parts list
• Use the model number when ordering parts like a gasket, control board, or fan motor

These prefixes are widely used to identify who built the unit.

Knowing who built the refrigerator helps us match the correct diagrams and components (for example, the right door gasket, evaporator fan motor, or electronic control board) so you avoid ordering a look-alike part that will not fit.

• If you’re troubleshooting display or beeping issues, use Kenmore 253 series french door refrigerator error codes.

Last updated: February 2026

Yes. We still carry replacement parts for Kenmore appliances, including the Kenmore Elite refrigerator model 25344743110. The key is matching the exact model number to the correct part so the fit, wiring, and mounting points are right.

Use your model number (for example, 25344743110) and then confirm the part by name and identifier.

• Find the model tag inside the fresh food compartment or on the cabinet wall
• Search parts by the full model number (all digits)
• Match the part name to your symptom (cooling, odor, door seal, noise)
• Cross-check the part identifier (part ID) before ordering
• Use the diagrams and part lists in the 25344743110 owner's manual to confirm location and compatibility

These are examples of parts we commonly see replaced on this model:

Kenmore parts availability is strong, but Kenmore uses multiple manufacturers across different model series. Using the exact model number (like 25344743110) prevents ordering a look-alike part that will not mount correctly or connect to your harness.

Last updated: February 2026

To reset your Kenmore Elite refrigerator model 25344743110, we recommend doing a power reset: unplug the refrigerator (or switch the breaker off) for about 5 minutes, then restore power and allow 24 hours for temperatures to stabilize. For model-specific reset steps, use the 25344743110 owner's manual.

• Power reset: Unplug for 5 minutes, then plug back in.
• Breaker reset: Turn the refrigerator circuit breaker OFF for 5 minutes, then ON.
• Control lock check: If the controls do not respond, make sure Control Lock is not enabled.
• Cooling off mode: If the unit is running but not cooling, confirm cooling was not turned off.
• After reset: Wait for fans and compressor to restart; normal cycling can take several minutes.

These checks pinpoint common causes on Kenmore 253-series designs:

• Confirm temperature settings are at normal mid-range (not warmest).
• Check door sealing for gaps, tears, or a door not closing fully; a bad gasket causes warm temps and frost.
• Listen for the evaporator fan in the freezer; if it is not running, cooling performance drops fast.
• Clean airflow paths (blocked vents, overpacked shelves) so cold air can circulate.
• Look for heavy frost on the freezer back wall; that often points to a defrost problem.

Helpful next steps:

• Kenmore 253 series french door refrigerator error codes
• If you suspect a fan issue, the freezer evaporator fan motor 297309000 is a common repair part for this model.

A reset clears minor control glitches, but temperature problems usually come from airflow, door sealing, or defrost issues. Resetting first saves time and helps you confirm whether the problem is electronic or mechanical.

Last updated: February 2026

Your Kenmore Elite refrigerator’s model number is printed on the appliance’s rating label. On Kenmore Elite model 25344743110, you’ll typically find that label inside the fresh food compartment (often on a side wall), inside the freezer, or behind the lower toe grille. For diagrams and label locations, use the 25344743110 owner's manual.

Check these common spots first (use a flashlight and look for a sticker or metal plate):

• Inside the refrigerator compartment on the left or right side wall
• Inside the freezer compartment on a side wall
• On the inner door frame (refrigerator or freezer door)
• Behind the lower crisper drawers (on the back wall)
• Behind the toe grille or kick plate at the bottom front

The rating label usually includes several identifiers. We recommend writing down:

• Model number (example format: 25344743110)
• Serial number (helps match production changes)
• Electrical ratings (volts/amps) if you’re troubleshooting
• Brand name (Kenmore)

Using the exact model number prevents ordering the wrong part. Even small differences can change fit and wiring, especially for items like a control board, temperature sensor, or door gasket.

Last updated: February 2026

Common problems we see on the Kenmore Elite refrigerator model 25344743110 include cooling issues (warm fridge or freezer), ice maker and water dispensing troubles, frost buildup from defrost failures, and noisy operation from fan or airflow problems. Use the 25344743110 owner's manual to confirm control settings and basic checks first.

• Not cooling or weak cooling: dirty condenser area, failed condenser fan, sealed-system/compressor issue, or a control problem
• Freezer cold but fridge warm: airflow restriction, evaporator fan problem, iced-over evaporator, or damper/air channel issue
• Frost buildup or ice on the back wall: defrost heater/thermostat issue or door not sealing
• Noisy humming, rattling, or squealing: evaporator fan motor, condenser fan motor, or vibration from the cabinet/lines
• Bad odors: old food spills, clogged drain, or a saturated air filter

1. Verify temperature settings and allow 24 hours after any adjustment.
2. Make sure vents inside the refrigerator and freezer are not blocked by food packages.
3. Check door closing and gasket contact all the way around.
4. Clean dust from the condenser area (unplug first).
5. Listen for the evaporator fan: it should run when the compressor is running and the door switch is closed.

If your Kenmore Elite shows an error code, match it to the symptom and follow the recommended checks in Kenmore 253 series french door refrigerator error codes.

Catching airflow, defrost, and door-seal problems early prevents temperature swings that spoil food and reduces compressor run time, which helps protect major components like the compressor and control board.

Last updated: February 2026

On Kenmore Elite refrigerator model 25344743110, the ER IF (or Er IF) code points to an ice fan problem in the freezer. That fan moves cold air through the door air ducts to keep the ice maker area cold, so ice production and freezer temperatures can be affected.

• Power reset: unplug the refrigerator (or switch off the breaker) for 5 minutes, then restore power.
• Freezer door closure: make sure the door fully seals and is not held open by bins or packages.
• Ice buildup: look for frost or ice blocking the fan area or air ducts.
• Airflow blockage: avoid overpacking the freezer; keep vents clear.
• Temperature settings: confirm the freezer is set to a normal target (commonly around 0°F).

If the fan is not running or is noisy, the most common repair is replacing the evaporator fan motor: freezer evaporator fan motor 297309000.

If you also see heavy frost buildup (which can stop the fan or block airflow), the defrost system is a common next check, including: freezer defrost heater 216730700 and the defrost thermostat.

The ice fan is what delivers freezer air to the ice maker compartment. When it fails or airflow is blocked, the ice maker can slow down or stop, and the freezer can develop uneven temperatures that lead to thawing and refreezing.

Use the troubleshooting and error code guidance in the 25344743110 owner's manual to confirm the exact reset procedure and access steps for the freezer fan area.

Last updated: February 2026
