Kenmore Elite 79577552600 refrigerator Parts

For Kenmore Elite refrigerator model 79577552600, the overall exterior size is typically about 33 inches wide, 31 inches deep, and 67.75 inches tall. For the exact dimensions and required installation clearances for your specific configuration, use the owner's manual.

How to measure your refrigerator (so you get the right fit)

We recommend measuring the cabinet and the path into the kitchen before you move or replace the unit.

• Measure width at the widest point (usually door edges)
• Measure height from floor to top hinge cover (include leveling legs if raised)
• Measure depth two ways: cabinet only, then with doors/handles
• Confirm door swing and drawer pull-out clearance
• Measure entry doors and hallways for delivery or removal

Typical size vs. what you should plan for

Even when the cabinet size is 33 x 31 x 67.75 inches, real-world space needs are usually larger because of airflow clearance and door/drawer movement.

What you’re planning for	What to use	Why
Cabinet opening	Refrigerator width and height	Ensures it physically fits
Front-to-back space	Depth with doors/handles	Prevents sticking out too far
Ventilation	Clearance specs in the manual	Helps cooling performance
Usability	Door swing and freezer drawer clearance	Prevents binding and dents

Why it matters

A bottom-mount refrigerator like the Kenmore 79577552600 needs proper clearance for air circulation and for the freezer drawer to open fully. Tight installs can lead to warm temperatures, higher run time, and door alignment issues.

Parts that commonly come up during a move or reinstall

If you’re disconnecting water or re-leveling after moving, these parts are commonly involved:

• Refrigerator water tubing MJU62070602 (water line routing)
• Refrigerator water inlet valve 5221JB2006K (no water to dispenser or ice maker after reconnect)
• Refrigerator door stop 4620JJ2009A (door swing control)

You can order replacement parts for model 79577552600 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

Most Kenmore Elite refrigerators, including model 79577552600, typically last 10 to 15 years with normal household use and basic maintenance. Keeping airflow clear, cleaning the condenser area, and fixing small issues early helps you reach the upper end of that range; see the owner's manual for care guidance.

Typical lifespan and what affects it

A refrigerator’s life depends most on how hard the sealed system and fans have to work.

• 10 to 15 years is the normal lifespan range for modern refrigerators
• Heavy use (large households, frequent door openings) shortens lifespan
• Poor ventilation around the cabinet increases compressor run time
• Dirty condenser coils raise operating temperatures and wear
• Worn door gaskets cause warm air leaks and longer run cycles

Quick maintenance checklist (high impact)

Use this list to reduce strain on the compressor, evaporator fan, and defrost system.

• Keep vents inside the fresh food section and freezer unblocked
• Set temps to typical targets: 37°F fresh food, 0°F freezer
• Clean dust from the lower grille area and condenser zone periodically
• Confirm doors close fully; avoid overloading door bins and shelves
• Replace water system parts promptly if you notice leaks or low flow

Repair vs. replace: a practical rule of thumb

When a unit is older, the decision usually comes down to repair cost versus remaining life.

Refrigerator age	What we typically recommend	Why
0 to 5 years	Repair is usually worth it	Most components still have strong remaining life
6 to 10 years	Repair common failures	Good chance of several more years with maintenance
11 to 15 years	Compare repair cost to replacement value	Major cooling repairs can be less cost-effective

Why it matters

A Kenmore Elite bottom-mount refrigerator that runs longer than necessary uses more energy and puts extra wear on the sealed refrigeration system. Simple upkeep helps stabilize temperatures, protect food, and reduce expensive breakdowns.

Parts and resources

If you’re maintaining or troubleshooting your 79577552600, we stock common components used in cooling and water systems, such as the refrigerator defrost sensor assembly 6615JB2005H and lg refrigerator water inlet valve 5221JB2006K. You can also search by model number on Sears PartsDirect.

Last updated: February 2026

Common problems on a Kenmore Elite bottom-mount refrigerator like model 79577552600 include poor cooling from airflow restrictions (frost on the evaporator), water leaks from a clogged defrost drain, ice maker issues (slow ice or bad-tasting ice), and door sealing or alignment problems. Use the troubleshooting section in the owner's manual to match symptoms to the most likely cause.

Most common symptoms and what usually causes them

• Not cooling well (fresh food warm, freezer OK or both warm): dirty condenser area, evaporator frost buildup, failed fan motor, or a sealed-system issue.
• Frost buildup in freezer or on food: door not closing fully, frequent door openings, or a defrost system problem.
• Water puddles under the refrigerator or inside compartments: defrost drain restriction; the drain tube can be involved.
• Loud or unusual noises: evaporator fan, condenser fan, or compressor-related components.
• Ice maker or dispenser problems: temperature not cold enough, door left open, water supply restriction, or dispenser switch/control issues.

Model-relevant checks we recommend first (fast, no parts)

1. Confirm doors close and seal all the way; warm air leaks drive frost and temperature swings.
2. Give temperature changes 24 hours to stabilize before judging results (important for ice production too).
3. If doors are hard to open right after closing, wait about 5 minutes for pressure to equalize (this is normal).
4. If ice tastes or smells off, discard the first batches after installation and replace old stored ice.

Parts that commonly relate to these problems

If troubleshooting points to a failed component, these parts are commonly involved on this model:

Symptom	Likely system	Example part on this model
Frost buildup, warm fridge	Defrost system	Refrigerator defrost sensor assembly 6615JB2005H or lg refrigerator defrost heater 5300JK1005D
Water leaking/puddles	Defrost drain	Refrigerator drain tube 5251JA3003D
No water/ice, slow fill	Water supply	Lg refrigerator water inlet valve 5221JB2006K
Light or door alarm issues	Door sensing	Lg refrigerator door switch 6600JB1010A

Why it matters

Most “not cooling” and “frost” complaints are really airflow and moisture problems. Fixing door sealing, drain flow, and defrost performance early prevents ice blockage, temperature swings, and food spoilage.

For model-specific fault displays and troubleshooting patterns, we also use the Kenmore 795 model bottom freezer refrigerator error codes guide. For ordering replacement parts by model number, we recommend starting with the parts list for 79577552600 or searching on Sears PartsDirect.

Last updated: February 2026
