Kenmore Elite 79578546806 refrigerator Parts

Kenmore Elite refrigerator model 79578546806 is a bottom-freezer design in the Kenmore 795.7854* model family. For exact exterior dimensions (width, depth, height) and total capacity for your specific color/trim variation, we recommend using the 79578546806 owner's manual.

What “size” usually means for this refrigerator

When customers ask for the “size,” it typically refers to one or more of these:

• Overall capacity (cubic feet)
• Exterior dimensions (W x D x H)
• Cutout/clearance needs (space for doors to swing and airflow)
• Door and drawer clearance (room to fully open the refrigerator doors and pull out the freezer drawer)

Typical size range for Kenmore 795 bottom-freezer models

Most Kenmore 795-series bottom-freezer refrigerators are in this general range:

• Capacity: about 22 to 25 cu. ft.
• Width: about 33 inches
• Height: about 67 to 70 inches
• Depth: commonly 30 to 35 inches (varies a lot depending on handles and door style)

Quick reference table

Measurement	Typical range for this style	What changes it most
Capacity	22 to 25 cu. ft.	model variation, interior layout
Width	~33 in.	door style, trim
Height	67 to 70 in.	hinge design, leveling
Depth	30 to 35 in.	handles, door thickness

Why it matters

Getting the correct dimensions helps you avoid fit issues in a cabinet opening, ensures proper airflow around the condenser area, and prevents door-swing problems that can lead to poor sealing and temperature swings.

Helpful tip if you are measuring for a move or tight doorway

The manual notes it is recommended to remove doors when moving the refrigerator through a narrow opening; the 79578546806 owner's manual includes handle and door-hardware guidance that can help you plan the clearance.

Last updated: January 2026

Common issues on the Kenmore Elite 79578546806 bottom-mount refrigerator include warm temperatures from dirty condenser coils, doors not sealing or closing fully, frost buildup from frequent door openings or gasket problems, and noise or vibration from leveling issues. We use the owner's manual troubleshooting and care steps to pinpoint the cause.

Most common symptoms and what to check first

• Not cooling well: clean condenser coils; confirm doors close completely.
• Frost or ice crystals on food: reduce door openings; check door alignment and gasket seal.
• Water or puddles: inspect the defrost drain path and drain tube for blockage.
• Noisy operation: level the refrigerator; check for items vibrating against the cabinet.
• Lights not working: reseat or replace the bulb; confirm the outlet has power.

Quick troubleshooting guide (symptom to likely cause)

Symptom	Most likely cause	What we recommend
Refrigerator warm	Dirty condenser coils, airflow restriction	Clean coils; avoid blocking vents
Doors will not close	Not level, bins/shelves out of position, gasket sticking	Level unit; reposition bins; clean gasket surface
Frost on frozen food	Door not sealing, door opened often	Improve seal; limit openings
Vibration/rattling	Uneven floor, leveling legs need adjustment	Re-level and stabilize
Ice tastes or smells	Old ice, unwrapped food odors, water quality	Dump old ice; clean bin; improve food wrapping

Parts that commonly relate to these problems

If troubleshooting points to a failed component, these model-matched parts are commonly involved:

• Refrigerator door gasket MDS64172919 (air leaks, frost, temperature swings)
• Lg refrigerator evaporator fan motor 4681JB1027C (poor cooling, warm spots)
• Lg refrigerator water inlet valve 5221JB2006K (ice maker or dispenser water issues)
• Refrigerator drain tube 5251JA3003D (water leaks from a clogged drain)

Why it matters

Catching airflow, door-seal, and leveling problems early helps the compressor run less, keeps food at safe temperatures, and prevents recurring frost and water leaks.

Last updated: January 2026

On Kenmore Elite model 79578546806, dH (or Er dH) points to a defrost heating problem: the refrigerator is not sensing the expected temperature rise during the defrost cycle. This can be caused by a failed defrost heater circuit, wiring issue, or a control problem; use the 79578546806 owner's manual troubleshooting section to confirm the exact checks.

What to check first (safe, quick checks)

• Reset power: unplug the refrigerator (or turn off the breaker) for 5 minutes, then restore power.
• Make sure the doors fully close and the gasket seals; warm air leaks can increase frost and trigger defrost issues.
• Look for heavy frost on the freezer back wall; that often matches a defrost system failure.
• Confirm air vents are not blocked by food packages; blocked airflow can worsen icing and temperature sensing.
• Clean condenser coils if dusty; poor heat rejection can add stress to cooling and defrost performance.

Likely causes and what they mean

What you notice	Most likely area	What it affects
Thick frost, weak airflow	Defrost heater circuit or defrost control	Evaporator stays iced over, temps rise
Intermittent dH code	Loose connection or failing sensor	Defrost cycle feedback becomes unreliable
No ice production plus dH	Cooling/airflow issue from frost buildup	Ice maker cannot harvest/fill normally

Parts that may be involved

If troubleshooting points to cooling airflow problems (fan not moving air across the evaporator), these model-matched parts are commonly involved:

• Lg refrigerator evaporator fan motor 4681JB1027C
• Refrigerator evaporator fan blade 5901JA1021A

Why it matters

A defrost heating fault lets frost build up on the evaporator, which blocks airflow between the freezer and fresh food sections. That can lead to warm temperatures, poor ice maker performance, and longer compressor run times.

For code-specific guidance that matches this Kenmore 795 platform, use Kenmore 795 model bottom freezer refrigerator error codes.

Last updated: January 2026

Water leaking from the bottom of your Kenmore Elite refrigerator model 79578546806 is usually caused by a defrost drain problem (water cannot reach the drain pan), a leak in the dispenser or ice maker water line, or a connection at the rear water valve that needs tightening. Use the 79578546806 owner's manual to locate the drain and water line routing for your exact configuration.

Most common causes (and what to check first)

• Clogged or frozen defrost drain: Meltwater backs up and spills into the cabinet, then runs out at the base.
• Leaking water line or fitting: A loose compression nut, cracked tubing, or a pinhole leak can drip down the back.
• Ice maker fill or supply leak: Leaks can show up as water under the unit even if the dispenser seems fine.
• Door not sealing well: Excess frost can increase defrost water and overwhelm a partially restricted drain.

Quick troubleshooting steps (safe DIY)

1. Unplug the refrigerator and pull it out enough to inspect behind it.
2. Check the rear water connections for moisture; tighten fittings that seep (the manual notes to tighten any connections that leak during water line hookup).
3. Inspect the water tubing for cracks, kinks, or rub marks; replace damaged tubing with the correct part.
4. Look for ice or debris at the drain area inside the freezer; clear visible blockage and confirm water can flow to the drain pan.
5. Confirm the leak source: Place a paper towel under the rear valve area and another under the front; recheck after a few hours.

Parts that commonly fix bottom leaks on this model

Symptom you see	Likely area	Model-matched part to consider
Drip behind unit near water hookup	Supply line	Refrigerator water tubing MJU62070602
Leak at rear valve or slow fill issues	Water valve/fittings	Lg refrigerator water inlet valve 5221JB2006K
Water pooling then running out front	Defrost drain path	Refrigerator drain tube 5251JA3003D

Why it matters

A small leak can turn into floor damage and can also cause icing, poor cooling, or ice maker problems. Fixing the drain path or water supply leak early helps your compressor and evaporator fan system run normally and keeps temperatures stable.

When to stop and schedule service

• Water is actively spraying or you cannot stop the leak at the shutoff
• You see heavy ice buildup behind interior panels
• The leak continues after clearing the drain and tightening fittings

Last updated: January 2026
