Kenmore 11086681100 electric dryer Parts

On Kenmore electric dryer model 11086681100, a failing heating element most often shows up as a dryer that tumbles normally but produces little to no heat, so clothes stay damp after a full cycle. In some cases, heat can be inconsistent, causing long dry times.

Common symptoms you can check

• Dryer runs but there is no heat on any heat setting
• Very long dry times even with small loads
• Heat that cuts in and out during the cycle
• Burning smell (lint or wiring overheating can mimic a bad element)
• Dryer repeatedly trips a breaker (can be element, wiring, or motor load)

Quick checks before replacing parts

1. Clean airflow first: clean the lint screen, check the lint chute, and confirm strong airflow at the outside vent.
2. Confirm power supply (electric dryers): the dryer can run on 120V but needs full 240V to heat; a tripped breaker leg can cause “runs but no heat.”
3. Try a timed dry cycle: moisture-sensing cycles can end early if the sensor bars are dirty.

What typically fails (and what it looks like)

What you notice	Likely area to inspect	What it means
Tumbles, no heat	Heating circuit (element, thermostats, wiring)	Element may be open or a safety device opened
Long dry times	Venting, blower wheel, lint buildup	Restricted airflow overheats the heater housing
Heat comes and goes	Cycling thermostat, loose connection	Intermittent heating or poor electrical contact

Parts that are commonly involved

If you confirm good airflow and correct power but still have no heat, inspect the heater wiring and connections. On this model, the dryer heating element wire kit 279457 is a common fix when terminals are heat-damaged.

Why it matters

A weak or failed heating element can turn a simple load into multiple cycles, and restricted airflow can overheat components. Fixing airflow and electrical issues first helps prevent repeat failures.

Last updated: January 2026

To hard reset your Kenmore electric dryer model 11086681100, disconnect power for a few minutes so the control can fully clear, then restore power and try a normal cycle. This often fixes a frozen control panel, a stuck cycle, or a no-start caused by a temporary glitch.

Hard reset steps (safe and effective)

• Turn the dryer OFF.
• Unplug the power cord; if you cannot access the plug, switch the dryer circuit breaker OFF.
• Wait 1 to 5 minutes.
• Restore power (plug back in or turn the breaker ON).
• Select a Timed Dry cycle and press Start.

If the dryer still will not start after a reset

A reset will not fix a failed door switch, broken belt, or motor problem. Check these common causes next:

• Confirm the door closes firmly and the latch engages.
• Test the door switch; a bad switch can prevent starting (see dryer door switch W10820036).
• Listen for a motor hum with no drum movement; that can point to a belt or idler issue.
• If the drum does not turn, inspect the belt and idler pulley (see belt 341241 and dryer idler pulley WP691366).
• If the control shows an error, use Kenmore 110 series electronic control model dryer error codes to match the code to a likely failure.

Quick checks: reset vs. repair

Symptom	Reset helps most when	More likely a part issue when
Control panel unresponsive	Buttons stopped responding mid-cycle	Panel responds but dryer will not start
Dryer will not start	Power glitch after outage	Door switch, belt, motor, or thermal cut-off problem
Cycle stuck or acting odd	Cycle logic froze	Repeats every load with no change

Why it matters

Hard resetting clears the electronic control’s temporary memory and restores normal operation without replacing parts. If the problem returns quickly, checking start-interlock parts (door switch, belt drive, motor) prevents repeat no-start situations.

Last updated: January 2026

For the Kenmore electric dryer model 11086681100, the typical exterior size is about 27 inches wide, 43.5 inches high, and 27.5 inches deep, with a 7.0 cu. ft. drum capacity. These are the common specs for this model family and help you plan fit, venting, and clearance.

Quick size specs

Spec	Typical measurement
Width	27 in.
Height	43.5 in.
Depth	27.5 in.
Capacity	7.0 cu. ft.

What to measure at home (so it fits the first time)

• Width: measure the cabinet side-to-side at the widest point.
• Height: measure floor to the top of the cabinet (include leveling legs if extended).
• Depth: measure front-to-back; include the door and control panel if they protrude.
• Clearance: leave room behind for the power cord and vent duct.
• Door swing: confirm the door can open fully without hitting a wall or washer.

Why it matters

Dryer “size” affects more than the space it sits in. Correct dimensions help prevent crushed venting (long dry times), make stacking or side-by-side layouts easier, and reduce installation surprises when moving the dryer through doorways and hallways.

Related DIY help

If you are planning a move, reinstall, or airflow check, we recommend reviewing how to keep a dryer clean and economical to reduce lint buildup and keep drying performance consistent.

Last updated: January 2026

For Kenmore electric dryer model 11086681100, replacing a heating element typically costs about $150 to $350 total (part plus labor). If you do it yourself, the cost is usually $40 to $150 for the part, depending on whether you replace just the element or an element-and-housing style assembly.

Typical cost breakdown

• Heating element part: $40 to $150
• Service call / diagnostic (if used): $75 to $125
• Labor (install): $75 to $200
• Total installed cost (common range): $150 to $350

Repair approach	What you pay for	Typical total cost
DIY replacement	Part only	$40 to $150
Pro repair	Part + labor + possible service call	$150 to $350

Before you buy a heating element (common “no heat” checks)

A Kenmore electric dryer can run but not heat for reasons other than the element. We recommend checking these first because they can change the total repair cost.

• Confirm the dryer has 240V power (a tripped breaker can leave you with 120V and no heat)
• Clean the lint screen and verify strong airflow at the exhaust
• Check the thermal fuse and high-limit thermostat (often open when venting is restricted)
• Inspect element coil for a visible break or burn spot
• Look for heat-damaged wiring at the heater terminals; a repair kit like dryer heating element wire kit 279457 can be needed if connectors are burnt

Why it matters

A failed heating element is common, but restricted venting and overheated wiring can cause repeat failures. Fixing airflow issues and any damaged heater wiring helps the new element last longer and keeps drying times normal.

Related DIY help

• Kenmore 110 series electronic control model dryer error codes

Last updated: January 2026
