Frigidaire FGGF3054MFC gas range Parts

If your Frigidaire FGGF3054MFC gas range smells like gas, treat it as a safety issue first: turn all burner knobs OFF, avoid switches or phones in the home, and contact your gas supplier from outside or a neighbor’s phone. A brief odor at ignition can be normal; a persistent smell points to a leak or incomplete ignition.

• Turn all surface and oven controls to OFF.
• Do not try to light the range.
• Do not touch electrical switches or use a phone inside the building.
• Call your gas supplier from a neighbor’s phone and follow their instructions.
• If you cannot reach the gas supplier, call the fire department.

For the full safety steps and installation requirements, follow the installation guide.

If the odor happens mainly when a burner or the oven is running, these are the most common causes:

• Burner ports clogged or wet, causing delayed ignition and unburned gas
• Misaligned burner cap or burner head on the cooktop
• Weak or failing igniter (oven or broil), causing slow ignition
• Gas valve issue (less common, but important)
• Range not level, affecting burner flame pattern and ignition consistency

If bake or broil ignition is slow or inconsistent, these parts are frequent fixes for this model family:

• Tappan range oven burner igniter 316489403 (bake ignition)
• Range oven igniter 5304506545 (broil ignition)

A persistent gas odor can indicate unburned gas or a leak. Addressing ignition problems quickly helps prevent flare-ups, soot, poor baking performance, and unsafe conditions.

Last updated: February 2026

On the Frigidaire gas range model FGGF3054MFC, the cooktop (main top) is not removable, so we do not remove the top for service. For most repairs, we access components by removing burner parts, the oven bottom panel, or pulling the range out after shutting off utilities; see the installation guide.

Use the access method that matches the repair:

• Surface burner cleaning/inspection: remove grates, burner caps, and burner heads; clean ports and reassemble.
• Oven burner/igniter service: remove the oven racks, then remove the oven bottom panel and any burner shield/baffle.
• Temperature problems: test the oven temperature sensor and wiring at the rear of the oven cavity.
• Ignition problems: inspect igniters, spark module, and harness connections.
• Deep cleaning behind the range: shut off gas and power, then pull the range out only as far as needed.

• Turn all burner knobs to OFF and let the range cool.
• Shut off the gas supply at the shutoff valve.
• Unplug the power cord (or switch off the breaker).
• Avoid reaching over burners; keep flammables away.
• If you smell gas, do not operate switches; contact your gas supplier.

Trying to lift or remove a non-removable cooktop can bend the main top, damage gas components, or create a gas leak risk. Using the correct access panels gets you to the igniter, burner, and sensor safely and faster.

Last updated: February 2026

Yes. Looking up parts by model number is the most accurate way to get compatible replacement parts for your Frigidaire gas range model FGGF3054MFC, because the model number ties directly to the correct diagrams, part lists, and revisions shown in the FGGF3054MFC owner's manual.

On this Frigidaire range, the identification plate is on the right-hand surface of the oven front frame. You can access it by opening the storage drawer, warmer drawer, or broiler drawer (depending on your configuration), then reading the plate.

When you record the information, capture:

• Model number (example: FGGF3054MFC)
• Serial number
• Lot number or letter (often used to match production changes)
• Fuel type and pressure rating listed on the plate

Once you have the full model number, we use it to match parts by exact fit and function.

Typical steps:

• Enter FGGF3054MFC exactly as shown on the identification plate
• Use the parts diagrams to locate the section (surface burners, oven burner, controls)
• Match the part by description and ID, then confirm it fits your symptom
• If multiple similar parts appear, use the lot/serial info to choose the correct revision

These are common examples of parts you can identify quickly once you search by model number:

Frigidaire ranges can have look-alike parts that do not interchange. Using the exact model number (and the serial or lot info when needed) prevents ordering a burner igniter, sensor, or burner cap that mounts differently or has different electrical connectors.

Last updated: February 2026

On the Frigidaire gas range model FGGF3054MFC, the model and serial number identification plate is located on the right-hand surface of the oven front frame. You access it by opening the storage drawer (or the warmer or broiler drawer on some configurations); see the diagram in the FGGF3054MFC installation guide.

• Turn all burner knobs to OFF and let the range cool.
• Pull the storage drawer straight out and open it fully.
• Look at the right side of the oven front frame (the front frame behind the drawer opening).
• Record the model number and serial number exactly as printed.
• Keep the numbers with your paperwork for parts ordering and service.

Frigidaire ranges can look similar across multiple versions. Using the identification plate information prevents ordering the wrong igniter, temperature sensor, spark module, or gas valve for FGGF3054MFC.

Last updated: February 2026
