Frigidaire LGEF3045KFK electric range Parts

Yes. For your Frigidaire electric range model LGEF3045KFK, looking up parts by the full model number is the most accurate way to match compatible replacement parts (like a bake element, oven temperature sensor, or surface element control switch) and avoid ordering the wrong item.

How to find the model number on the range

Use the complete model number exactly as shown on the appliance ID tag. On most freestanding ranges, the tag is commonly found in one of these spots:

• Inside the oven door frame or along the oven opening
• On the storage drawer frame (visible when the drawer is pulled out)
• Behind the lower panel or near the drawer jamb
• On the back of the range (less convenient, but possible)

For safe access and positioning details (including anti-tip bracket checks), follow the LGEF3045KFK installation guide.

How model-number lookup helps you get the right part

Model-number search narrows parts to what fits your exact configuration (controls, wiring, and heating system). For LGEF3045KFK, common part categories customers match by model include:

• Oven heating parts (bake element, broil element, convection element)
• Temperature and control parts (sensor, control board)
• Cooktop parts (radiant surface elements, control switches)
• Door and light parts (door seal, light bulb, light socket)

Examples of model-matched parts for LGEF3045KFK

What you are fixing	Example part to check	What it affects
Oven temperature inaccurate	Range oven temperature sensor 316490000	Bake temperature regulation
Oven not heating in bake	Range bake element 316505500	Primary oven heat source
Surface element not cycling correctly	Range surface element control switch 316238201	Cooktop heat control

Why it matters

Ranges often have multiple versions that look identical but use different elements, switches, or wiring. Using LGEF3045KFK ensures the part you choose matches the correct electrical connections and mounting style, which speeds up repair and reduces returns.

Last updated: February 2026

Your Frigidaire electric range model number is printed on the appliance ID plate; on model LGEF3045KFK, you will usually find it around the oven door frame or on the frame behind the storage drawer. Write the full model number exactly as shown (letters and numbers).

Where to look on a Frigidaire range

Check these common ID plate locations first:

• Oven door frame: open the oven door and look along the frame edge
• Storage drawer area: pull the drawer out and look on the frame behind it
• Lower front frame: near the drawer opening or kick area
• Side trim/frame: just inside the oven cavity edge on some builds

If the label is hard to see, use a flashlight and wipe grease or dust off the plate so the characters are readable.

What to write down (so parts match)

Record these items from the ID plate:

• Model number (example format: LGEF3045KFK)
• Serial number (helps confirm production run)
• Brand (Frigidaire)
• Electrical rating (useful for installation checks)

Quick character check

Some characters are easy to mix up. Use this as a reference:

Looks like	Often confused with	Tip
0	O	Zeros are usually more oval and appear in numeric groups
1	I, L	Ones are often straight; letters may have small hooks
5	S	Look for sharper corners on 5

Why it matters

We use the exact model number to match the correct parts and diagrams for your range, including items like the Frigidaire range oven temperature sensor 316490000 and the Frigidaire range bake element 316505500. Even one wrong character can point you to a similar looking range with different wiring, elements, or control components.

If you are checking the model for installation needs

Your installation requirements (clearances, anti-tip bracket placement, and electrical connection type) are covered in the installation guide. This is especially important if the range has been moved or you are installing it in a new location.

Last updated: February 2026

To reset your Frigidaire LGEF3045KFK electric range, we recommend doing a full power reset: turn the range off, shut off power at the breaker (or unplug), wait 5 to 10 minutes, then restore power. This clears many control glitches after a power surge or outage.

Reset steps (safe, reliable)

• Turn all surface element knobs to OFF.
• If the range is plugged in, unplug it; if it is hardwired, switch OFF the range breaker.
• Wait 5 to 10 minutes (we use 10 minutes when the control seems “stuck”).
• Restore power and set the clock.
• Test Bake at 350°F and a surface element to confirm normal operation.

If the display comes back with an error code

A reset may clear a temporary fault, but recurring codes usually point to a specific circuit (sensor, door lock, wiring, or control).

Use our troubleshooting reference: Frigidaire self-cleaning range error codes

When a “reset” is really a power or wiring issue

If the range is newly installed, moved, or recently serviced, focus on the power connection. Loose or incorrect terminal block connections can cause dead display, intermittent resets, or heating problems.

From the installation requirements, make sure:

• The correct 3-wire vs 4-wire connection method is used for your home.
• Terminal block connections are tight.
• The rear access cover is reinstalled after wiring.
• The anti-tip bracket is fully engaged after sliding the range into place.

Reference: installation guide

Parts that commonly relate to “won’t heat” after a reset

If the control resets but the oven still will not heat correctly, these model-compatible parts are common suspects:

Symptom after reset	Common cause	Example part for LGEF3045KFK
Oven temperature is inaccurate	Failed sensor	Frigidaire range oven temperature sensor 316490000
No bake heat	Failed bake circuit	Frigidaire range bake element 316505500
Control acts erratic or won’t hold settings	Control failure	Range oven control board 5304495520

Why it matters

A proper reset helps distinguish a one-time control glitch from a repeatable failure. If the problem returns quickly after power is restored, troubleshooting the sensor, heating elements, or control board prevents wasted time and repeat shutdowns.

Last updated: February 2026

On your Frigidaire LGEF3045KFK electric range, the part number is printed on the part itself; we recommend first finding the model and serial tag (usually visible when you open the oven door) so you can match the correct replacement part for your exact range configuration using the installation guide.

Where to look for the model and serial tag

Check these common locations on freestanding electric ranges like the LGEF3045KFK:

• Along the oven frame or front trim, visible when the oven door is open
• On the left or right side frame behind the door opening
• On the lower drawer frame area (storage or warming drawer), visible when the drawer is pulled out
• On the back panel of the range (easiest to see with a flashlight)

How to match the correct part once you have the tag info

Use the model number from the tag (LGEF3045KFK) to look up the exact part listing, then confirm the part number stamped on the old part.

• Match by model number first, then by part name (example: oven temperature sensor)
• Compare any numbers stamped or printed on the old part
• Confirm the part’s location and connectors match (wire plug style, mounting holes)
• For heating parts, confirm the shape and terminal position match

Common examples for this model

What you are replacing	Where the part number is usually found	Example part for LGEF3045KFK
Oven temperature sensor	Printed on the sensor body or tag	Range oven temperature sensor 316490000
Bake element	Stamped on the element bracket or tag	Range bake element 316505500
Broil element	Stamped on the element frame	Range broil element 316430900

Why it matters

Using the model and serial information prevents ordering a look-alike part that fits differently (mounting, wiring, or wattage). That is especially important on electric ranges where correct fit and secure electrical connections affect heating performance and safety.

Last updated: February 2026
