Kenmore Elite 79661433710 dryer Parts

On your Kenmore Elite dryer model 79661433710, the model number is printed on the identification plate inside the dryer door. Open the door and look along the door opening on the cabinet frame for the label; it also lists the serial number.

Where to look (fast checklist)

• Open the dryer door fully.
• Look for a sticker or metal plate on the cabinet frame around the door opening.
• Check the left and right sides of the door opening, plus the top edge.
• Write down the full model number and serial number exactly as shown.
• Keep the info with your purchase date for future parts and service needs.

What the label typically includes

Label item	What it’s used for	Example for this page
Model number	Matching the correct parts diagrams and parts	79661433710
Serial number	Identifying production run details	Varies by unit
Purchase date (you record it)	Warranty and service reference	Your receipt

Why it matters

We use the model number to match the exact configuration of your dryer so you get the right Kenmore Elite parts the first time (for example, a drum belt, heating element, or door switch can vary by series).

Tip for ordering parts

If the label is worn or hard to read, use a flashlight and take a close-up photo. Then compare the number to what’s shown in the 79661433710 owner’s manual.

Last updated: January 2026

To hard reset your Kenmore Elite dryer model 79661433710, unplug the power cord (or switch the breaker off) for 1 to 5 minutes, then restore power and try a cycle. This clears many temporary control glitches, but it will not fix airflow restrictions or failed safety parts.

Hard reset steps (safe and effective)

• Press POWER to turn the dryer off.
• Unplug the dryer; if you cannot access the plug, turn the dryer circuit breaker off.
• Wait 1 to 5 minutes.
• Restore power.
• Press POWER, select a cycle, then press START.
• If the panel is unresponsive, check whether Control Lock is enabled (see below).

If the controls are locked (Control Lock)

This model uses a Control Lock feature that disables all controls except POWER. To toggle it, press and hold CHIME for 3 seconds (the display shows Control Locked when enabled). See the 79661433710 owner's manual for the exact button location and display behavior.

When a reset does not solve it

A “reset” often seems to work temporarily when the real issue is power, heat, or airflow. Use these quick checks:

• Confirm the plug is fully seated in the outlet.
• Check the house breaker/fuse; reset the breaker if tripped.
• If the dryer runs but does not heat, remember an electric dryer can run with no heat if one leg of power is lost.
• Clean lint buildup and verify strong airflow at the outside vent.
• If the VENT indicator stays on after you clear a restriction, run several consecutive cycles; the dryer may need multiple cycles to reset the vent performance indicator.

Quick guide: what a reset can and cannot do

Symptom	Reset helps?	What usually fixes it
Display frozen, buttons lag	Yes	Hard reset; then retry cycle
“Control Locked” shown	No	Turn off Control Lock (CHIME 3 sec)
Runs but no heat	Rarely	Power supply check; heating circuit diagnosis
Long dry times, VENT light	No	Vent cleaning; airflow correction

Why it matters

Resetting is a fast first step, but dryers protect themselves when they sense unsafe heat or poor airflow. Fixing venting and power issues prevents repeat shutdowns, long dry times, and overheating.

Last updated: January 2026

Yes. Kenmore Elite is Kenmore’s premium line, and the Kenmore Elite dryer model 79661433710 is built to deliver higher-end features and performance than standard Kenmore models, including advanced cycle options and smart features described in the 79661433710 owner's manual.

What “high end” means for Kenmore Elite dryers

Kenmore Elite typically focuses on convenience, fabric care, and feature depth rather than being a basic, entry-level dryer.

Common “premium” traits include:

• More specialized cycles and options (for example, downloadable cycles through app features)
• Smart connectivity features such as Remote Start (when set up with the Kenmore Smart app)
• More control options (such as Control Lock and chime settings)
• Better load-sensing and drying control compared with basic timed-dry-only models

Features we see called out for model 79661433710

Based on the use and care information for the 796.6143* series, this dryer supports connected features and additional cycles through the app.

Feature area	What you can expect	Why it feels “high end”
Smart features	Remote Start and connected operation	Adds convenience and monitoring from a mobile device
Cycle expansion	“My Cycle” downloads additional cycles	More tailored drying for specific fabrics
Efficiency options	Energy Saver option on Normal	Helps reduce energy use (with longer dry time)

Why it matters

If you are comparing dryers, “high end” usually shows up in better fabric care, fewer re-dries, and more ways to customize cycles. It also affects repair decisions; premium models often justify replacing key wear parts (belt, rollers, idler) to keep performance strong.

Parts that commonly support “premium performance” over time

These are normal wear items that can affect noise, tumbling, and drying results:

• Dryer drum belt 4400EL2001F (drum turns smoothly and consistently)
• Drum support rollers (reduce thumping and vibration)
• Idler pulley (maintains correct belt tension)
• Lint screen and grille (helps airflow and drying efficiency)

Last updated: January 2026
