Kenmore Elite 11086762700 dryer Parts

For Kenmore Elite dryer model 11086762700, the heating element part typically runs about $50 to $120, and the total installed cost is commonly $150 to $350 when you include labor and a service call. Your exact total depends on whether you replace only the element or also repair heat-damaged wiring.

Typical cost breakdown

• Heating element (part only): $50 to $120
• Labor (if hiring a technician): $100 to $250
• Service call/diagnostic (sometimes separate): $0 to $100
• Optional wiring repair: $10 to $40

Scenario	What’s included	Typical total
DIY element replacement	Part only	$50 to $120
DIY plus wiring kit	Element + wiring kit	$60 to $160
Professional repair	Parts + labor + service call	$150 to $350

Parts that commonly apply to this repair

If your 11086762700 is not heating, we usually check the heater circuit parts together because a failed thermostat or damaged connector can take out a new element.

• Dryer heating element WP8544771
• Dryer heating element wire kit 279457
• Dryer high-limit thermostat WP8557403

What to check before you buy parts

These quick checks help avoid replacing the wrong part and help explain why costs vary.

• Confirm the dryer has the correct power supply; many electric dryers can run but not heat if one leg of power is missing.
• Check for a crushed or blocked vent; restricted airflow can overheat the heater housing.
• Look for burnt terminals at the heater connections; that often means you also need a wire/terminal kit.
• If you notice a burning odor on first heat after repair, that can be normal for a new element.

For model-specific troubleshooting steps and safety notes, use the 11086762700 owner’s manual.

Why it matters

A heating element replacement is one of the most common electric dryer repairs, but airflow problems and heat-limit issues can cause repeat failures. Fixing the root cause (venting, thermostats, wiring) keeps drying times normal and protects the new heater.

Last updated: January 2026

To hard reset your Kenmore Elite dryer model 11086762700, unplug the power cord (or switch the breaker off) for 1 to 5 minutes, then restore power and start a cycle. If the controls are locked, unlock them first so the buttons respond.

Hard reset steps (safe and effective)

• Press STOP twice to end the current cycle and clear the selection.
• Unplug the dryer (or turn both dryer breakers off for electric models).
• Wait 1 to 5 minutes.
• Restore power.
• Close the door and press and hold START until the dryer starts (some loads require holding START for a few seconds).

For model-specific button behavior (STOP, START, and Control Locked), use the 11086762700 owner's manual.

If it still will not run or keeps showing a code

A “reset” clears many temporary control issues, but it will not fix airflow, power-supply, or failed-part problems. These checks solve the most common causes:

• Control Locked is on: Press and hold CYCLE SIGNAL for 3 seconds to unlock.
• PF (power failure): Press and hold START to restart.
• AF (airflow restriction): Check for a crushed vent, lint buildup, or a blocked exterior hood.
• L2 (power supply issue): The drum may turn but the heater may not; check house fuses/breakers.
• No heat but tumbles: Verify the venting is clear and the correct heated cycle is selected.

What the codes usually point to

What you see	What it usually means	What to do next
PF	Cycle was interrupted by power loss	Restart with START; then hard reset if needed
AF	Venting is restricted	Clean venting and lint path
L2	Home power issue affecting heat	Check both breakers/fuses; confirm cord/terminal connection

Parts that commonly relate to “no heat” or overheating symptoms

If airflow is good and power is correct, heat problems often involve temperature sensing or the heater circuit. For this model, common related parts include the dryer thermistor WP8577274, the dryer high-limit thermostat WP8557403, and the dryer heating element WP8544771.

Why it matters

Resetting is a fast first step, but repeated PF, AF, or L2 messages usually mean the dryer is protecting itself (airflow restriction) or not getting proper power for heat. Fixing the root cause prevents long dry times, overheating, and repeat shutdowns.

Last updated: January 2026

Kenmore Elite dryer model 11086762700 uses diagnostic codes to point you to a power issue, venting problem, or a control-related service fault. Common codes you may see include PF, AF, L2, and F-series service codes; use the steps below to correct the cause and clear the display.

Common codes and what they mean

Code	What it indicates	What to do first
PF	Power failure interrupted the cycle	Press and hold START to restart the dryer
AF	Vent may be crushed or blocked	Inspect and clear the venting from dryer to outside
L2	Home power supply issue; drum may turn but heater may not	Check both breakers/fuses; confirm cord/terminal connections
F-series (example: F1, F2, F20)	Service fault (control or interface related)	Power-cycle once; if it returns, schedule service

Quick troubleshooting steps we recommend

• PF: Restore power, then press and hold START to resume.
• AF: Check the vent run for crushing, lint buildup, and a clogged exterior hood.
• L2: Verify the dryer has full 240V supply; electric dryers typically use two breakers or fuses.
• Run a Timed Dry heated cycle (not Air Only) to confirm heat operation.
• Clean the lint screen before every load to keep airflow strong.

Parts that commonly relate to heat or airflow symptoms

If the dryer runs but heat is inconsistent, cycles end early, or airflow is weak, these model-compatible parts are often involved during diagnosis:

• Dryer thermistor WP8577274 (temperature sensing)
• Dryer heating element WP8544771 (electric heat source)
• Dryer blower wheel WP697772 (moves air through the drum and vent)

Why it matters

These codes help you avoid guesswork. AF and restricted airflow can cause long dry times and overheating; L2 can leave the drum tumbling with little or no heat; F codes typically point to an electronic issue that needs a repair decision.

For the full list of display messages and model-specific troubleshooting steps, use the 11086762700 owner’s manual and the Kenmore elite dryer error codes reference.

Last updated: January 2026
