Whirlpool WTW5100HC3 laundry, residential, washer Parts

Yes. On a Whirlpool WTW5100HC3 washer, using too much detergent can create excessive suds that interfere with water-level sensing and normal draining; that can trigger an E3-type error condition or related cycle stoppage until the washer can correct the water level.

What to do right away (quick reset steps)

• Pause the cycle and let suds settle for 10 to 15 minutes.
• Run a Rinse and Spin (or a rinse-only cycle if available) with no detergent.
• If suds remain, run a second rinse.
• Reduce the next load size; overloading makes oversudsing worse.
• Switch to HE detergent and measure carefully (especially with soft water).

Why too much detergent can trigger errors

High-efficiency top-load washers like the WTW5100HC3 use sensors and timed drain routines. When there is too much foam, the washer can:

• Misread the tub water level (foam traps air and changes pressure readings)
• Struggle to drain properly (foam can slow water movement)
• Extend the cycle or stop to protect the motor and prevent overflow

If you suspect a drain-related issue along with the error, inspect the drain path and pump.

Parts to check if the problem keeps coming back

If E3 (or a similar drain/water-level error) returns even with correct detergent use, these model-compatible parts are common inspection points:

• Pump assembly, drain W11399437 (clogs, jammed impeller, weak pumping)
• Hose asm - d W10899966 (tub-to-pump hose blockage)
• Hose W11244231 (drain hose kinks or restrictions)
• Hose WP353244 (pressure switch hose issues that affect water-level sensing)

Symptom guide: oversudsing vs. a real drain problem

What you notice	More likely cause	What we recommend
Lots of foam, slippery residue, error appears mid-cycle	Too much detergent	Rinse out suds; reduce dose
Little to no foam, water left in tub, humming during drain	Drain restriction or pump issue	Check hoses and drain pump
Error happens on many loads regardless of detergent	Sensing or drain hardware	Inspect drain and water-level hose

Why it matters

Oversudsing is one of the fastest ways to cause poor rinsing, long cycle times, and repeat error codes. Using the right amount of HE detergent helps the washer drain correctly and keeps the control from stopping the cycle.

For code definitions and what Whirlpool commonly means by each code family, use our Whirlpool belt drive top load washer error codes reference.

Last updated: January 2026

A common problem on Whirlpool front-load washers is poor draining (often followed by a no-spin), usually caused by a clogged drain pump filter, a restricted drain hose, or debris in the pump. Your Whirlpool WTW5100HC3 is a top-load washer, so it will not have the same front-load pump filter access setup.

Common front-load washer issues (what customers report most)

• Slow or no drain, then the washer will not spin
• Musty odors from moisture and detergent residue
• Leaks at the door area (boot or clamp issues)
• Excess vibration from an unbalanced load or leveling problems
• Error codes related to draining or door lock

How this relates to Whirlpool WTW5100HC3 (top-load)

Even though WTW5100HC3 is not a front loader, the most similar, high-frequency issue is still a drain restriction or a weak pump. If your top-load washer will not drain or drains slowly, we typically check the drain path and pump components.

• Inspect the drain hose for kinks and a clogged standpipe
• Check the tub-to-pump hose for socks, lint, or debris
• Listen for the pump running but not moving water
• If it drains but will not spin, verify the lid is locking

Parts that commonly relate to drain or no-spin symptoms on WTW5100HC3

Symptom on WTW5100HC3	Likely area	Model-compatible part to check
Won’t drain or drains slowly	Drain pump	Pump assembly, drain W11399437
Drains but won’t spin	Lid lock system	Lid lock-sol W11700916
Slow drain, intermittent drain	Drain path restriction	Hose asm - d W10899966

Why it matters

Drain problems can leave water in the tub, cause long cycle times, create odors, and prevent high-speed spin. Fixing the drain path early helps protect the drive system and improves drying performance.

Related help: how to fix a washing machine

Last updated: January 2026

On a Whirlpool top-load washer like model WTW5100HC3, the model number is printed on the appliance’s ID tag, most often under the lid along the top rim of the washer opening or on the rear panel. Match the full model number exactly before ordering parts.

Where to look on the washer

Check these common ID-tag locations first:

• Under the lid, along the top edge (rim) of the tub opening
• On the underside of the lid
• On the back of the washer cabinet (rear panel)
• Along the side edge of the lid opening near a hinge
• On the cabinet frame behind the control console area

What to write down (so parts fit)

We recommend copying the information exactly as shown on the tag:

• Model number (example: WTW5100HC3)
• Serial number (helps confirm production series)
• Any revision or engineering code listed

If the tag is worn or hard to read, take a clear photo and zoom in; that prevents mixing up similar characters like 0 and O.

Why it matters

Whirlpool washers often have multiple versions that look identical but use different components (lid lock, drain pump, control board, belt). Using the exact model number helps us match the correct diagrams and compatible parts.

Quick examples of parts that depend on the exact model

System	Example part type	Example from this model’s parts list
Lid/door safety	Lid lock	Lid lock-sol W11700916
Draining	Drain pump	Pump assembly, drain W11399437
Drive system	Belt	Washer drive belt WPW10006384

Last updated: March 2026
