Frigidaire FGGF3054MFH gas range Parts

Yes. Looking up parts by the exact model number is the most reliable way to get compatible replacement parts for your Frigidaire gas range, including the FGGF3054MFH, because it filters results to the correct diagrams and part lists for your specific build.

How to find the correct model number

We recommend matching the model number exactly as printed on the appliance’s serial plate. For this Frigidaire range, the Use & Care information points you to the serial plate area near the storage drawer or lower front panel on some models.

• Check the serial plate and copy the full model number (letters and numbers)
• Use the complete model number, not a partial family code
• If a character is unclear, re-check under good lighting (O vs 0 is common)
• Keep the serial number too; it can help confirm the correct variation

Reference: FGGF3054MFH manual

What you can look up once you have the model number

When you search by model number, we can narrow you to the correct parts breakdown for common repairs like ignition, temperature sensing, and oven lighting.

What you need	Why it helps	Example for this model
Model number	Ensures parts match your exact range	FGGF3054MFH
Part name	Helps you choose the right section/diagram	Oven igniter, temperature sensor
Part ID	Confirms the exact item to order	316490000

Common parts customers search by model number

These are examples of model-matched parts that are commonly replaced on gas ranges like the FGGF3054MFH:

• Oven burner igniter (no heat or slow ignition): tappan range oven burner igniter 316489403
• Oven temperature sensor (baking temps off): Frigidaire range oven temperature sensor 316490000
• Oven light bulb (light out): appliance light bulb, 40-watt 316538904
• Spark/ignition issues at surface burners: range spark module 5304508269

Why it matters

Gas range parts can look similar but differ by mounting, wiring connectors, and calibration. Searching by the exact model number helps prevent returns and gets your oven or cooktop working correctly the first time.

Last updated: February 2026

To reset your Frigidaire FGGF3054MFH gas range, we recommend doing a simple power reset: turn the range off, disconnect power for about 30 seconds, then restore power and reset the clock and any oven settings per the FGGF3054MFH owner's manual.

Quick reset steps (power reset)

• Turn all surface burner knobs to OFF.
• Unplug the range, or switch OFF the range circuit breaker.
• Wait 30 seconds.
• Restore power.
• Reset the clock and reselect any oven function settings.

If the range was just installed and nothing heats

A reset helps after a power interruption, but if the oven and surface burners are not operating after installation, focus on power and wiring first.

• Confirm the breaker is fully ON (cycle it OFF then ON).
• Make sure the power cord is fully seated (if your installation uses a cord).
• Check for a tripped GFCI outlet (if applicable).
• If the oven will not ignite, watch for a weak or no-glow igniter; a failing igniter can prevent the gas valve from opening.
• If surface burners will not spark, ignition wiring or the spark system may need attention.

Common symptoms and what they point to

Symptom	Most likely cause	What to do next
Display is blank	No power to range	Check breaker, outlet, wiring
Clock reset after outage	Normal after power loss	Set clock in the manual
Oven will not ignite	Igniter issue	Inspect/replace tappan range oven burner igniter 316489403
Surface burners do not click/spark	Spark system issue	Inspect range spark module 5304508269 and wiring

Why it matters

A reset clears minor control glitches after a power interruption. If the range still will not heat or ignite, the issue is usually power supply, ignition components (igniter, spark module), or wiring, and fixing the root cause prevents repeated failures.

Last updated: February 2026

A Frigidaire gas range like model FGGF3054MFH typically lasts 13 to 15 years. With regular cleaning, correct burner operation, and timely repairs (igniters, sensors, gas valve), many owners get closer to 15 to 20 years of service.

What affects lifespan the most

• Cooking frequency and heat load (daily high-heat cooking shortens life)
• Spillovers and grease buildup around burner heads and igniters
• Ignition health (weak igniters cause delayed lighting and extra wear)
• Oven temperature accuracy (a drifting sensor can overwork the burner)
• Self-clean use (heavy use adds heat stress to wiring and controls)

Maintenance that adds years (FGGF3054MFH)

Use the care and cleaning guidance in the FGGF3054MFH owner's manual. Focus on these habits:

• Keep surface burner ports clear; clean and dry caps and heads after boilovers.
• Wipe up oven spills promptly (once cool) to reduce smoke and corrosion.
• Replace a dim oven light so you do not open the door repeatedly while cooking.
• If bake or broil ignition gets slow, replace the correct igniter instead of repeatedly retrying.
• Confirm racks and door are seated correctly after cleaning to prevent hinge and seal wear.

Common “end-of-life” symptoms and likely fixes

Symptom	Most common cause	Typical repair
Oven takes long to ignite or won’t heat	Weak igniter	Replace tappan range oven burner igniter 316489403
Oven temperature swings or bakes unevenly	Sensor drifting	Replace Frigidaire range oven temperature sensor 316490000
Clicking or no spark at surface burners	Spark system issue	Check wiring, switches, spark module

Why it matters

A gas range usually fails gradually, not all at once. Catching ignition and temperature issues early helps cooking performance, reduces gas odor complaints from delayed ignition, and prevents repeated stress on the control system.

Last updated: February 2026

On the Frigidaire FGGF3054MFH gas range, an F11 error code means the keypad (touchpad) is shorted or sending a stuck signal to the electronic oven control. This is commonly triggered by heat, moisture, or a failing control panel interface.

What to do first (safe, quick checks)

• Press Cancel/Off to clear the code and wait 30 to 60 seconds.
• If the code returns, turn off power to the range at the breaker for 1 minute, then restore power.
• Wipe the control area dry if there was recent boiling, steaming, or cleaning.
• If keys feel stuck, press each key once to confirm none are physically jammed.
• If F11 comes back quickly, plan on a control-panel repair (keypad or control assembly).

What usually causes F11

Likely cause	What you may notice	Typical fix
Moisture or cleaner residue in keypad	F11 after heavy steam or wipe-down	Dry out; power reset
Shorted keypad (touch membrane)	Random beeps, keys activate by themselves	Replace keypad/control panel
Wiring issue at control	Intermittent F11 when oven heats	Inspect and repair connections

Parts that are often involved

F11 is a control-input problem, not a bake burner problem. If you are also having ignition issues (no heat, delayed ignition), troubleshoot those separately.

• For ignition symptoms, the oven igniter is a common wear item; see tappan range oven burner igniter 316489403.
• For temperature complaints (too hot or too cool), the sensor is a common suspect; see Frigidaire range oven temperature sensor 316490000.

Why it matters

A shorted keypad can make the oven start, stop, or change settings unexpectedly. Clearing the code may get you cooking again temporarily, but a repeating F11 points to a control interface that needs attention.

For control and feature operation steps (Bake, Broil, self-clean, and settings), follow the FGGF3054MFH owner's manual.

Last updated: February 2026

On the Frigidaire gas range model FGGF3054MFH, we find the model and serial number on the serial plate behind the lower storage area: open the storage drawer (some models) or remove the lower front panel (some models). For exact illustrations, use the FGGF3054MFH owner's manual.

Quick ways to locate the tag

• Pull out the bottom storage drawer fully and look along the frame opening.
• If your unit has a lower front panel instead of a drawer, remove that panel and look behind it.
• Use a flashlight; the plate is often on a vertical surface and can be easy to miss.
• Write down the model number and serial number exactly as shown.
• Take a clear photo of the plate for ordering parts later.

What the plate looks like (what to record)

Item on plate	Why we need it
Model number (FGGF3054MFH)	Matches parts and diagrams to your exact range
Serial number	Helps confirm production details when troubleshooting
Purchase date (your records)	Useful for service history and maintenance tracking

Why it matters

We use the model number to ensure parts like an igniter, temperature sensor, or burner components match your exact Frigidaire configuration. Even small model variations can change fit, wiring, or gas orifice sizing.

Last updated: February 2026

If your Frigidaire FGGF3054MFH gas range smells like gas, treat it as a safety issue first: follow the “What to do if you smell gas” steps in the FGGF3054MFH owner's manual, then address common causes like a burner that is not igniting cleanly, clogged burner ports, or a weak igniter that delays ignition.

What to do right now (safety first)

• Do not try to light any burner or the oven.
• Do not touch electrical switches or use a phone in the building.
• Call your gas supplier from a neighbor’s phone and follow their instructions.
• If you cannot reach your gas supplier, call the fire department.

Common causes when the smell happens only during use

A brief, faint odor at initial ignition can happen, but a persistent gas smell usually points to delayed ignition or incomplete combustion.

• Dirty or misaligned surface burner parts: food spills can clog burner ports and disrupt the flame.
• Weak oven igniter: the igniter can glow but still be too weak to open the gas valve quickly, causing a “whoosh” start and gas odor.
• Ignition circuit issues: a failing switch, harness, or spark module can cause inconsistent sparking.
• Gas valve/regulator concerns: improper gas flow can affect ignition and flame quality.

Quick checks you can do (after the area is safe)

• Confirm burner caps are seated flat and centered.
• Clean burner ports with a soft brush; clear debris from around the igniter electrode.
• Watch the flame: it should be steady and mostly blue; large yellow tips suggest poor combustion.
• For oven bake, note whether ignition is delayed (long wait before flame lights).

Parts that commonly fix gas-odor complaints on this model

Symptom	Most likely area	Example part for FGGF3054MFH
Oven smells like gas before it lights	Bake ignition is weak/delayed	Tappan range oven burner igniter 316489403
Clicking but poor/erratic surface ignition	Spark/ignition circuit	Range spark module 5304508269
Oven temperature seems off and cooking is inconsistent	Temperature feedback (not a gas leak)	Frigidaire range oven temperature sensor 316490000

Why it matters

A gas odor can signal unburned gas from delayed ignition or a leak. Addressing it quickly protects your home and helps your range ignite reliably and heat evenly.

Last updated: February 2026
