Kenmore 11064622300 electric dryer Parts

Your Kenmore dryer’s model number is printed on the model and serial number label; on Kenmore model 11064622300, that label is located at the top inside the dryer door well. Once you have the full model number, we can match the correct parts, diagrams, and specifications.

Where to look for the model number label

Check these common spots first (in this order):

• Top inside the dryer door well (most common on Kenmore 110-series dryers)
• Inside the door opening on the cabinet frame
• On the back panel of the dryer cabinet
• Near the lint screen housing (varies by design)

For the exact label location and how it’s shown for your unit, use the 11064622300 owner's manual.

What the model number looks like (and why it matters)

Kenmore model numbers are usually a long string of digits. Many Kenmore dryers start with 110, which is especially helpful when you are selecting compatible parts like a belt, heating element, or door switch.

Quick guide

What you see	What it tells us	What we use it for
Model number (example: 11064622300)	Exact dryer design	Correct parts list and diagrams
Serial number	Production code/date info	Service history and identification
Brand name (Kenmore)	Brand family	General compatibility grouping

Tips to avoid ordering the wrong part

• Write the model number exactly as shown (all digits, no spaces)
• Take a clear photo of the label before it wears or fades
• Use the full model number when choosing common wear items (belt, idler pulley, thermal fuse)
• If the dryer will not start, confirm the door closes and the switch clicks; the dryer door switch WP3406107 is a common related part

Why it matters

Kenmore dryers can look similar across series, but internal components (like the dryer element, thermostats, and drum support parts) can differ. Using the exact model number keeps troubleshooting accurate and prevents returns.

Last updated: February 2026

To hard reset your Kenmore electric dryer model 11064622300, unplug it (or switch the breaker off) for at least 1 minute, then restore power and start a new cycle. This clears many control glitches; if it still will not run, a start, door, or heat safety issue is more likely than a “reset” problem.

Hard reset steps (safe and effective)

• Turn the cycle selector to OFF.
• Unplug the dryer (or turn both dryer breakers off if it is hardwired).
• Wait 1 to 5 minutes.
• Restore power.
• Close the door, select a cycle, then press Push to start (per the 11064622300 owner's manual).

If the dryer still will not start after resetting

These checks come straight from common “won’t run” causes and the setup checklist:

• Confirm the dryer is plugged into a grounded outlet.
• Check the home electrical supply; many electric dryers use two fuses or two breakers, so verify both are on.
• Make sure the door is fully closed; a failed door switch can prevent starting (see dryer door switch WP3406107).
• Verify controls are set to an On/running position and the start button is pushed firmly.
• If the dryer ran recently and then stopped, inspect airflow; a restricted vent can overheat the dryer and open a safety device.

Quick troubleshooting table

Symptom after reset	Most common cause	What we check first
No lights, no response	Power supply issue	Breakers/fuses, outlet power
Lights on, will not start	Door circuit issue	Door fully closed, door switch
Runs but no heat	Heating circuit or airflow	Venting, then heating parts
Stops mid-cycle	Overheating from poor venting	Lint screen, vent path

Why it matters

A hard reset fixes temporary control states, but it will not bypass safety circuits. On model 11064622300, start failures are most often power, door-switch, or airflow related. Keeping the vent straight and unkinked (see the 11064622300 installation guide) also helps prevent overheating shutdowns.

Last updated: February 2026

The average lifespan of a Kenmore electric dryer like model 11064622300 is about 13 years. Regular vent cleaning, avoiding overloading, and replacing wear parts (belt, rollers, thermal fuse) on time are what most often determine whether it reaches that full service life.

What affects lifespan the most

These are the biggest factors we see with electric dryers:

• Airflow and vent length: long or restricted venting overheats the dryer and shortens component life.
• Heat stress: repeated overheating can damage thermostats, the heating element, and wiring.
• Wear items: belts, drum rollers, and idler pulleys wear gradually and get noisy or slip.
• Lint buildup: lint in the lint chute, blower housing, or ducting reduces airflow.
• Electrical supply: loose connections or incorrect voltage can cause intermittent heat or no-heat issues.

For venting limits and recommended hood styles, follow the installation guide.

Typical “end of life” symptoms (and common fixes)

Many dryers are worth repairing when the cabinet and drum are in good shape.

Symptom	Common cause	Example part that may help
Drum will not turn, motor runs	Worn or broken belt	Dryer drum belt 341241
Runs but no heat	Failed heating circuit component	Dryer element 279838
Stops mid-cycle or will not start	Overheat protection opened	Dryer thermal cut-off fuse kit 279816
Loud squeal or thump	Worn rollers or idler	Dryer repair kit 4392065

Why it matters

A dryer that is overheating or struggling to move air does not just dry slower; it also accelerates wear on the heating system and safety thermostats. Keeping the exhaust path short and clear is the simplest way to protect performance and extend the life of model 11064622300.

Last updated: March 2026
