Kenmore 41742142100 washer Parts

Your Kenmore washer model number is printed on the identification plate; on Kenmore model 41742142100 (a front-load “tumble action” washer), it’s located at the top, inside the door opening. Use that full model number to match the correct replacement parts and manual information in the 41742142100 owner's manual.

Where to look on Kenmore washers

For most Kenmore washers, the model and serial tag is in one of these spots:

• Front-load washers: inside the door opening, along the top or door frame
• Top-load washers: under the lid, around the tub opening
• Some models: on the back panel near the power cord, or behind/near the control panel

What the model number looks like (and why it matters)

Kenmore model numbers are often 10 to 12+ characters and may start with a prefix such as 417 (common on many Kenmore front-load designs). The exact model number is what we use to ensure parts like a door lock, drain pump, or water inlet valve fit correctly.

Quick check table

What you see	What it usually means	What to do next
Model number (example: 41742142100)	Identifies the exact washer design	Use it to select parts and diagrams
Serial number	Identifies your specific unit	Keep it for service records
Partial number (example: “417.” only)	Incomplete identifier	Find the full number on the same plate

Tips to avoid common mix-ups

• Write the model number exactly as shown, including all digits
• Don’t use the control panel label alone; it can match multiple models
• If you’re ordering a door-related part, confirm the model first; front-loaders commonly use a door lock/catch system such as the door catch 131763256

Why it matters

Kenmore washers can look similar across series, but internal components (door lock system, drain path, dispenser plumbing, and controls) vary by model. Using the correct model number prevents wrong-part returns and speeds up repair.

Last updated: February 2026

Yes, it’s usually worth repairing a Kenmore washer when the fix is a common wear part and the total repair cost is clearly less than replacing the machine. For Kenmore model 41742142100, we use the 41742142100 owner’s manual to confirm symptoms, safe checks, and basic care steps before choosing parts.

Quick way we decide: repair vs replace

• Repair when the washer still fills, tumbles, and drains but has a specific failure (leak, won’t latch, won’t drain).
• Repair when the cabinet and tub are solid and there’s no repeated breakdown pattern.
• Replace when multiple major systems are failing (drain, spin, controls) or the outer tub/bearing area is damaged.
• Repair when the issue is a single, accessible part such as a door latch, drain hose, or inlet valve.
• Replace when repair cost approaches the price of a comparable new washer.

Common repairs that are often “worth it” on this model

These are typical front-load washer fixes that usually restore normal operation quickly:

Symptom	Likely area	Example part for 41742142100
Door won’t lock or cycle won’t start	Door latch/lock	Door catch 131763256
Won’t drain, water left in tub	Drain pump or restriction	Washer drain pump (check pump and hoses)
Leaks at the front door	Door boot/bellows	Bellows (door boot)
Slow fill or no fill	Water inlet valve or screens	Washer valve

What to check before spending money

• Confirm the symptom and any error code steps in the 41742142100 owner’s manual.
• Unplug the washer and check for a kinked or clogged drain hose.
• Inspect the door seal area for debris that prevents a tight close.
• Verify both hot and cold supply valves are fully open.
• Run a rinse and spin test cycle after any cleaning or hose adjustment.

Why it matters

A targeted repair keeps a good Kenmore front-load washer running for years, and it avoids replacing the machine for a problem that’s often caused by one part (like a latch, hose, or valve) or a simple blockage.

Last updated: February 2026

A Kenmore washer typically lasts 10 to 15 years. For the Kenmore 41742142100 front-load washer, routine care (cleaning, correct loading, and stable installation) helps you reach the high end of that range; neglected maintenance and chronic vibration shorten it. See the 41742142100 owner’s manual for model-specific care steps.

Typical lifespan and what affects it

Most washers fail early for a few predictable reasons:

• Overloading (stresses the motor, bearings, and suspension)
• Frequent unbalanced loads (increases vibration and tub wear)
• Poor drainage (pump strain, standing water, odors)
• Hard water and heavy detergent use (buildup, valve and dispenser issues)
• Door seal neglect on front-loaders (mildew, leaks)

What “end of life” usually looks like

Common symptoms that signal major wear:

• Loud rumbling during spin (often tub bearing wear)
• Repeated leaking at the door area
• Slow or no drain, or recurring drain errors
• Excessive shaking even after leveling
• Intermittent no-fill or weak fill

Quick maintenance plan (best ROI)

Use this checklist to extend service life:

• Wipe the door boot dry after loads; leave the door ajar to vent
• Run a monthly cleaning cycle (hot wash with washer cleaner)
• Use HE detergent and measure carefully
• Check and clean the drain path if you notice slow draining
• Confirm the washer is level and stable on the floor

Parts that commonly impact longevity

If performance problems point to a specific failure, these model-matched parts are often involved:

Symptom	Common part area	Example model-matched part
Won’t drain / drains slowly	Drain system	Washer drain pump 137108000
Door won’t latch / won’t start	Door lock/catch	Door catch 131763256
Excessive vibration	Suspension	Level shock 5304485917

Why it matters

A washer that is draining correctly, staying balanced, and sealing properly runs cooler and with less mechanical stress. That reduces wear on high-cost assemblies (tub, bearings, motor controls) and helps your Kenmore 41742142100 reach its normal 10 to 15 year lifespan.

Last updated: February 2026
