How to reset a Kenmore Elite dryer?
To reset your Kenmore Elite dryer model 11087731701, we recommend a hard reset: unplug the dryer (or switch off the breaker) for 1 to 5 minutes, then restore power and try a cycle. If the controls are locked, clear the control lock per the 11087731701 owner's manual.
- Turn the dryer OFF.
- Unplug the power cord (or turn the circuit breaker OFF).
- Wait 1 to 5 minutes.
- Restore power.
- Select a normal cycle and press Start.
Control lock is a feature, not a failure. Use the control-lock steps listed in the 11087731701 owner's manual. If the panel still will not respond after unlocking, power-cycle again and try a different cycle selection.
A reset will not fix a failed safety device or airflow problem. These checks solve most “won’t start” complaints:
- Confirm the dryer has full power (electric dryers typically need 240V; a tripped breaker can leave the motor dead).
- Make sure the door closes firmly; a weak latch can prevent starting.
- Clean the lint screen and check the vent for restrictions.
- Listen for abnormal squealing or thumping; a seized drum support or idler can stall the motor.
- If the dryer runs but heat is inconsistent, a temperature-sensing issue can cause odd cycling.
| Symptom | Common cause | Example part for this model |
|---|---|---|
| Door won’t “click” shut | Worn latch | Catch 279570 |
| Loud rumble/squeal | Worn rollers/idler | Dryer repair kit 4392067 |
| Heat cycles oddly | Sensor/thermistor issue | Dryer thermistor WP8577274 |
Resetting clears temporary control glitches, but dryers also stop for safety reasons (overheating risk, door not shut, motor overload). Fixing airflow and worn moving parts helps the dryer start reliably and dry faster.
Last updated: January 2026
What size is Kenmore Elite dryer?
Kenmore Elite dryer model 11087731701 is a full-size, extra-large capacity dryer; it is typically listed at about 7.5 cu. ft. Capacity and exact cabinet dimensions for your specific configuration are shown in the 11087731701 owner's manual.
Most Kenmore Elite 110-series full-size dryers fall into these common ranges:
| Spec | Typical value/range | What it affects |
|---|---|---|
| Capacity | ~7.0 to 7.5 cu. ft. | Load size, cycle time |
| Width | ~27 in. | Fit in standard laundry alcoves |
| Height | ~38 to 39 in. | Clearance under shelves/cabinets |
| Depth | ~30 to 32 in. | Closet fit, door clearance |
- Measure width across the front of the cabinet (not the door).
- Measure height from the floor to the top of the cabinet.
- Measure depth front-to-back; note if the door or controls protrude.
- Add 4 to 6 inches behind the dryer for the exhaust duct and power cord.
- Confirm the door swing space so the door opens fully.
Correct sizing prevents a tight install that kinks the exhaust duct (long dry times), blocks airflow (overheating), or leaves too little clearance for electrical connections and routine lint cleaning.
Last updated: January 2026
Where is the model number on Kenmore Elite dryer?
On Kenmore Elite dryer model 11087731701, the model number is printed on the rating label. You will typically find that label on the door opening (cabinet frame) when you open the dryer door, or on the back of the dryer near the top.
- Open the dryer door and look around the door opening on the cabinet frame
- Check the inside edge of the door itself
- Look on the back panel near the top of the dryer
- If your dryer has a lower access panel, check just inside that area for an additional label
The label usually includes the model number (11087731701) and often the serial number. It may also list electrical information and the brand name (Kenmore).
| Location | How to spot it | Why it helps |
|---|---|---|
| Door opening (cabinet frame) | Sticker or metal tag visible with door open | Fastest way to confirm the exact model |
| Back of dryer (near top) | Label on rear panel | Helpful if the door label is worn |
| Inside door edge | Label along the door perimeter | Common on some Kenmore designs |
Using the exact model number ensures we match the correct Kenmore Elite dryer parts and diagrams for your unit, especially for fit-critical items like a dryer heating element WP8544771 or a drum support roller.
- Write down the full model number exactly as shown
- Use the model number to confirm compatible parts and troubleshooting steps
- For additional identification details and safety information, reference the 11087731701 owner's manual
Last updated: January 2026
