Kenmore 79691373210 dryer Parts

To reset your Kenmore dryer model 79691373210, we recommend doing a simple power reset: turn the dryer off, disconnect power for a few minutes, then restore power and try a cycle again. This clears many control glitches without replacing parts.

Reset steps (power reset)

• Press Power/Cancel to turn the dryer off.
• Unplug the dryer, or switch OFF the dryer circuit breaker.
• Wait 1 to 5 minutes.
• Restore power (plug back in, or switch the breaker ON).
• Press Power, select a cycle, and press Start.

If the dryer still will not run

A reset helps when the control is “stuck”, but it will not fix a failed door switch, belt issue, or overheating safety trip.

• Confirm the door fully closes and the latch clicks; a bad switch can stop the motor from running.
• If the motor hums but the drum will not turn, check the belt and idler system.
• If the dryer shuts off mid-cycle or overheats, check airflow and safety thermostats.
• If you see an error code, use the model-family error code guide to narrow the failure.

Common parts related to “won’t start” or “stops” symptoms

Symptom	What to check first	Example part for this model
Won’t start (no tumble)	Door switch, power supply	Dryer door switch EBF61496102
Tumbles poorly or not at all	Belt, idler pulley	Dryer drum belt 4400EL2001F
Overheats or shuts down	Venting, high-limit thermostat	Dryer high-limit thermostat AGM30045804

Why it matters

A proper reset is the fastest way to rule out a temporary electronic control issue before spending time on deeper troubleshooting or ordering Kenmore dryer parts.

For control panel functions and cycle behavior specific to model 79691373210, follow the steps and safety notes in the 79691373210 owner’s manual.

Last updated: February 2026

For Kenmore dryer model 79691373210, replacing a dryer sensor typically costs $20 to $150 for the part, plus labor if you hire service. On this model, a common sensor-related replacement is the moisture sensor (often a lower-cost DIY part).

Typical cost breakdown

• Part only (DIY): $20 to $150 (most moisture sensors are on the lower end)
• Service call and labor: commonly $100 to $250+ depending on your area and access
• Total installed: often $150 to $400+

Which “sensor” are we talking about?

Dryers use a few different sensors and thermostats, and the price changes a lot depending on which one failed.

What you’re replacing	What it affects	Typical part cost range
Moisture sensor	Auto-dry shuts off too soon or runs too long	$20 to $60
High-limit thermostat	Overheating protection, no-heat symptoms	$30 to $120
Blower thermostat	Temperature control and safety	$30 to $120

For this Kenmore 79691373210, examples of sensor-related parts we carry include the dryer moisture sensor 6500EL3001A and safety thermostats like the dryer high-limit thermostat AGM30045804.

What to check before you buy a sensor

These quick checks often prevent replacing the wrong part:

• Clean the lint screen and housing; airflow problems can mimic sensor failures.
• Make sure the exhaust vent is not crushed, kinked, or clogged.
• If auto cycles end early, clean moisture sensor bars inside the drum (soap residue insulates them).
• If the dryer overheats or shuts down, check venting first, then thermostats.
• Confirm the correct procedure and access steps in the 79691373210 manual.

Why it matters

A “bad sensor” symptom is often caused by restricted airflow. Fixing venting and lint buildup first can restore normal drying, prevent overheating, and keep you from paying for an unnecessary part.

Last updated: February 2026

PF on a Kenmore dryer (including model 79691373210) stands for power failure. It means the dryer’s control detected an interruption in electrical power; once power is stable again, you can usually clear PF and restart the cycle.

How to clear PF and get the dryer running

• Press Power to turn the dryer off, then back on.
• Press Start/Pause to resume, or reselect the cycle and press Start.
• If PF returns, unplug the dryer (or switch the breaker off) for 1 minute, then restore power.
• Check that the dryer plug is fully seated and the outlet is not loose.
• If the dryer is on a shared circuit, reduce other loads (space heater, iron, vacuum) while drying.

What usually causes a PF code

PF is almost always caused by a brief loss of voltage to the dryer, such as:

• A tripped breaker or weak breaker connection
• A loose power cord connection at the terminal block
• A loose wall outlet or damaged receptacle
• A momentary outage or power dip in the home
• Extension cords or power strips (not recommended for dryers)

Quick checks (safe, no disassembly)

Check	What you’re looking for	What to do
Breaker	Partially tripped or warm breaker	Reset fully OFF then ON
Outlet	Plug feels loose, discoloration	Stop using and have outlet repaired
Cord	Kinked, damaged jacket	Replace the cord if damaged
Repeat PF	Happens mid-cycle often	Have power supply and connections inspected

Why it matters

A PF message is a helpful warning that the dryer may not be getting steady power. Fixing the underlying power issue prevents interrupted cycles and helps protect the electronic control from repeated power drops.

For model-specific control behavior and reset steps, follow the 79691373210 owner’s manual.

Last updated: February 2026

On your Kenmore dryer model 79691373210, the model number is printed on the rating label. Most often, we find it on the door opening (inside the door on the cabinet frame) or on the back of the dryer near the top.

Common places to check first

• Inside the dryer door opening on the cabinet frame (most common)
• On the back panel near the top edge
• Along the door opening lip or side panel just inside the door
• On the lower front area behind the toe panel or access panel (some designs)

What the label looks like

The label typically includes:

• Model number (for example, 79691373210)
• Serial number
• Electrical or gas information (voltage, amps, or BTU rating)
• Brand and certification markings

Quick tips so you record the right number

• Copy the full model number exactly as shown (all digits, no spaces).
• If the label is worn, use a flashlight and take a close-up photo.
• Use the model number (not the serial number) when ordering parts like a belt or thermostat.

Model vs. serial number (what to use)

You see on the label	What it’s for	Use it to order parts?
Model number	Identifies the exact dryer design	Yes
Serial number	Identifies your specific unit	No

Why it matters

Kenmore dryers can look similar across multiple series; the model number ensures we match the correct parts, diagrams, and repair procedures for your exact dryer.

For label location diagrams and model identification details, use the 79691373210 manual.

Last updated: February 2026
