Whirlpool ED5LHAXWQ00 side-by-side refrigerator Parts

The Whirlpool ED5LHAXWQ00 side-by-side refrigerator has a total capacity of about 25.3 cubic feet, with the freezer at about 9.9 cubic feet and the fresh food section making up the remainder. For the exact capacity listing for your unit, confirm in the ED5LHAXWQ00 owner's manual.

Capacity breakdown (what the numbers mean)

Refrigerator capacity is usually listed as total cubic feet, then split between the freezer and fresh food compartments.

• Total capacity: about 25.3 cu. ft.
• Freezer capacity: about 9.9 cu. ft.
• Fresh food capacity: total minus freezer (typically the larger section)
• Capacity is a volume measurement, not shelf space
• Usable space can vary with shelves, bins, and the ice maker setup

Quick reference table

Compartment	Capacity (cu. ft.)	What it represents
Total	25.3	Combined fresh food + freezer volume
Freezer	9.9	Freezer compartment volume
Fresh food	About 15.4	Remaining volume (total minus freezer)

Why it matters

Knowing the cubic feet helps when comparing replacement refrigerators, planning food storage, and understanding why airflow and organization (shelves, bins, and ice storage) can make the refrigerator feel more or less spacious than the raw capacity number.

Related maintenance that helps performance

Good airflow and clean water flow help this Whirlpool refrigerator run efficiently and keep food at safe temperatures.

• Replace the water filter on schedule to maintain dispenser flow and ice quality (see refrigerator water filter EDR3RXD1)
• Avoid overpacking; leave space near vents for proper circulation
• Keep door gaskets sealing to prevent warm air leaks
• Clean condenser area periodically to support cooling efficiency

Last updated: January 2026

The biggest problem we see in Whirlpool refrigerators like model ED5LHAXWQ00 is cooling trouble (warm fridge or freezer, temperature swings, or running nonstop). The most common root causes are restricted airflow from dirty condenser coils, a failing fan, or a defrost system issue that lets frost block airflow.

Most common “big problems” and what they look like

• Not cooling well: food softening, freezer warming, compressor running a lot
• Frost buildup on the back freezer wall: points to a defrost problem
• Ice maker or dispenser not working: no ice, small cubes, slow water flow
• Water leaks or puddles: often a clogged defrost drain or water supply issue
• Doors not sealing: moisture, frost, or warm spots near the door edge

Quick checks we recommend first (no parts needed)

• Set temps to typical targets: 0°F freezer and 37°F fresh food.
• Clean condenser coils and confirm the condenser area has good airflow.
• Listen for the evaporator fan in the freezer; it should run when cooling.
• Check door closing and sealing; a poor seal can mimic a cooling failure.
• If water flow is weak, replace the filter and purge air from the dispenser.

When a part is usually the fix

Symptom	Likely system	Common fix for ED5LHAXWQ00
Warm temps, runs constantly	Airflow or heat rejection	Clean coils; check fans and airflow paths
Heavy frost, weak airflow	Defrost system	Test defrost heater/thermostat; inspect defrost control
No ice or slow fill	Water supply	Replace filter; diagnose inlet valve

If you are chasing water quality or slow dispensing, the correct replacement is the refrigerator water filter EDR3RXD1. For no-water or no-ice fill issues, the refrigerator water inlet valve W10408179 is a common failure point.

Why it matters

Cooling problems can spoil food quickly and also overwork the compressor. Catching airflow, defrost, or water-supply issues early usually prevents bigger repairs and keeps ice maker and dispenser performance consistent.

For model-specific operating details (controls, temperature settings, and care steps), use the ED5LHAXWQ00 owner's manual.

Last updated: January 2026

Your Whirlpool side-by-side refrigerator’s model number (and serial number) is on the rating label located on the inside wall of the refrigerator compartment. Open the fresh food door and look along the interior side wall for a sticker or metal tag; confirm the full model number before ordering parts.

Where to look on model ED5LHAXWQ00

Check these common label locations inside the fresh food section:

• Left or right interior side wall (most common)
• Near the top front edge of the compartment liner
• Behind or beside the crisper drawers (still on the inside wall)
• Near the ceiling light housing area

For the exact location callout and label examples, use the owner's manual.

Tips to read the label correctly

We recommend copying the model number exactly as printed so you get the right diagrams and Whirlpool replacement parts.

• Write down the full model number and the serial number
• Use uppercase letters and include all digits (for example, ED5LHAXWQ00)
• Avoid using numbers from the dispenser, control panel, or ice maker; those are not the model number
• If the label is hard to read, take a clear photo with the door open and the light on

Why it matters

The model number identifies the exact production design for your refrigerator. That affects which parts fit, such as the water filter, ice maker, door gasket, and control components.

What you’re looking for	Why you need it
Model number	Matches the correct parts diagrams and compatible parts
Serial number	Helps identify the production run when parts changed over time
