Kenmore Elite 79681072310 dryer Parts

If your Kenmore Elite dryer model 79681072310 won’t start or runs but won’t heat, a blown thermal fuse is a top suspect. The sure way to know is a continuity test with a multimeter after unplugging the dryer; a good fuse shows continuity, and a blown fuse shows no continuity.

• Dryer will not start at all (no motor run)
• Dryer runs but produces no heat
• Cycle stops early and clothes stay damp
• Burning smell or unusually hot cabinet (often tied to restricted airflow)
• Repeated overheating issues after long dry times

1. Unplug the dryer (or switch off the breaker) and let it cool.
2. Access the thermal fuse location shown in the 79681072310 owner’s manual.
3. Remove at least one wire from the fuse terminal.
4. Set a multimeter to continuity (or lowest ohms).
5. Touch probes to the fuse terminals.

A thermal fuse usually opens because the dryer overheats. On model 79681072310, overheating is most often caused by poor airflow.

• Clean the lint screen before every load (replace a damaged screen such as the lg dryer lint screen ADQ73373201)
• Clear lint from the lint duct and blower housing area
• Inspect the vent hose for kinks, crushing, or long runs
• Clean the entire vent to the outside hood; confirm strong airflow outside
• Avoid running the dryer with the vent disconnected (it can overheat and fill the cabinet with lint)

The thermal fuse is a one-time safety device. If you replace it without fixing the airflow restriction, the dryer can overheat again and the new fuse can blow quickly.

Last updated: February 2026

For Kenmore Elite dryer model 79681072310, the heating-element part cost is typically $50 to $300, depending on whether you replace just the element or a full heater assembly; professional replacement is typically $200 to $500 total once labor and a service call are included. Use the 79681072310 owner's manual to confirm access steps and safety notes before pricing the repair.

Here is what we see most often for electric dryers like the Kenmore 796 series:

• Heating element part only: $50 to $300
• Related safety parts (if needed): $15 to $80 (thermal cut-off, thermostats)
• Labor: $120 to $250
• Service call/diagnostic: $80 to $150

If your dryer overheated or stopped heating, techs often check these at the same time because a failed safety device can mimic a bad element:

• Dryer heating element 5301EL1001J (the heater itself)
• High-limit thermostat (opens if the heater area overheats)
• Blower thermostat (helps regulate operating temperature)
• Thermistor (temperature sensor used by the control)

• Electric vs. gas: electric models use a heating element; gas models use an igniter and gas valve system.
• Airflow restrictions: a clogged vent or lint buildup can overheat the heater area and take out thermostats.
• Access time: some dryers require more disassembly to reach the heater housing.
• Multiple failed parts: repeated overheating can damage the element and a thermostat together.

A “no heat” symptom is not always a bad heating element. Pricing the job correctly means confirming airflow and testing heater circuit components so you do not replace the wrong part and still have long dry times.

Last updated: February 2026

Common problems we see on Kenmore dryers like model 79681072310 include no heat, long dry times, the drum not turning, and loud squealing or thumping. Most of these issues trace back to airflow restrictions (lint buildup) or normal wear on drive and temperature-sensing parts; check the 79681072310 owner's manual for model-specific operating and care guidance.

• Dryer runs but won’t heat: failed heating circuit parts such as the dryer heating element 5301EL1001J, a thermostat, or a temperature sensor
• Long drying times: clogged lint screen, restricted venting, or a weak blower wheel
• Drum won’t turn: worn belt, idler pulley, or drum support rollers
• Loud noise (squeal, rumble, thump): worn drum rollers, idler pulley, or blower wheel issues
• Stops mid-cycle or overheats: airflow restriction or a high-limit thermostat opening

1. Clean the lint screen and confirm it is seated correctly (a damaged screen can leak lint into the duct).
2. Inspect and clear the vent path from the dryer outlet to the exterior hood.
3. Run a timed dry cycle and confirm strong airflow at the outside vent.
4. Listen for noise location: front (idler), rear (rollers), or blower housing area.
5. If the dryer is electric, confirm the outlet is supplying full power (a partial power issue can cause “runs but no heat”).

Airflow and temperature control protect your clothes and the dryer. A restricted vent can cause long dry times and overheating, which can repeatedly trip thermostats and shorten the life of the heating element, motor, belt, and rollers.

If your display shows an error code, use the Kenmore elite dryer error codes guide to match the code to the most likely failed component and the right next test.

Last updated: February 2026

Kenmore Elite is a premium Kenmore product line that began appearing in the late 1990s; the exact “year” for your Kenmore Elite dryer model 79681072310 is the unit’s manufacture date, which is determined from the serial number on the rating label. For the most accurate location and label details, use the 79681072310 owner's manual.

Kenmore Elite is a line name used across many appliance types (dryers, washers, refrigerators), produced over many years by different manufacturers. Because of that, the launch of the line and the build date of a specific dryer are two different things.

In practice, the year you care about is the manufacture year of model 79681072310, which comes from the serial number format used on that dryer.

Start by locating the model and serial tag (usually inside the door opening, on the door frame, or on the cabinet opening).

• Unplug the dryer before reaching around sharp metal edges.
• Open the door and look along the door opening for a sticker or metal tag.
• Confirm the model reads 79681072310.
• Write down the full serial number exactly as shown.
• Use the serial number to decode the manufacture date (the coding pattern varies by manufacturer).

The manufacture year helps us match the correct version of parts and service information for your dryer, especially for items that can change during a production run (controls, thermostats, and drum support components).

If you are troubleshooting a performance issue while you are checking the label, common wear items for this model include the dryer drum support roller 4581EL2002H and the dryer drum belt 4400EL2001D.

Last updated: February 2026

On the Kenmore Elite dryer model 79681072310, the model number is printed on the rating label. You will typically find that label on the door opening (cabinet frame) when you open the dryer door, or on the back of the dryer near the top.

• Open the dryer door and check the cabinet frame around the door opening
• Look along the inside edge of the door opening near the lint screen area
• Check the back panel near the top (upper-left or upper-right area)
• If your dryer is stacked, you may need to pull it forward to see the rear label

The rating label is usually a white or silver sticker/plate that includes the model number, serial number, and electrical or gas information.

We use the exact model number to match the correct Kenmore parts diagrams and ensure you get the right replacement parts (for example, a belt, thermostat, or control board) for your specific dryer.

• Copy the full model number exactly as printed (all digits)
• Record the serial number too; it helps confirm production version
• Use the model number when checking diagrams in the 79681072310 owner’s manual
• If you are troubleshooting a display code, compare it to the Kenmore elite dryer error codes list before replacing parts

Last updated: February 2026
