What are the advantages of bottom mount refrigerators?
Bottom-mount refrigerators like the Kenmore 79577306600 keep fresh-food shelves at eye and waist level, so we reach everyday items with less bending. The freezer stays below, and features like multi-airflow circulation help keep temperatures more even across compartments (details in the 79577306600 owner's manual).
Key advantages you’ll notice day to day
- Easier access to fresh food: produce, drinks, and leftovers sit higher up.
- Less bending: the freezer is lower, so we bend less for items used most often.
- Better organization for fresh foods: adjustable shelves help fit tall items and group foods.
- More consistent cooling: multi-flow style circulation helps move cold air through both sections.
- Door-open savings: faster access to fresh food can reduce how long doors stay open.
How bottom-mount compares to other common layouts
| Layout | Fresh-food access | Freezer access | Best for |
|---|---|---|---|
| Bottom-mount (bottom freezer) | Highest | Lowest | Households that use fresh food most |
| Top freezer | Medium | Highest | Budget-focused, simple storage |
| Side-by-side | Medium | Medium | Narrow door swing, frequent freezer use |
Why it matters
Most households open the refrigerator section far more than the freezer. A bottom-mount design puts the most-used space where we naturally reach, which can improve convenience and help limit warm air entering during quick grabs.
Tips to get the most from a bottom-mount design
- Keep frequently used items on the middle shelves.
- Avoid blocking top vents so air can circulate properly.
- Close doors firmly; some models use a door alarm if left open.
- Clean door gaskets regularly to prevent cool-air leaks.
Last updated: January 2026
What is the bottom part of a refrigerator called?
On the Kenmore 79577306600 bottom-mount refrigerator, the bottom area is commonly called the base grille (the front cover) and the machine compartment behind it, where major cooling parts like the compressor and condenser components are located. For model-specific diagrams and access steps, use the 79577306600 owner's manual.
Common names you may hear
- Base grille: the removable front grille at the bottom of the cabinet
- Machine compartment: the space behind the base grille that houses cooling components
- Compressor compartment: another common name for the machine compartment
- Drain pan area: the space underneath where defrost water can evaporate
What’s typically located in the bottom area
Most bottom-mount refrigerators place key cooling and service components down low, including:
- Compressor (pumps refrigerant through the sealed system)
- Condenser coils (release heat)
- Condenser fan (moves air across coils on many designs)
- Drain pan (collects defrost water)
- Wiring and control components (varies by model)
If you are removing the front cover for cleaning or inspection, follow the removal steps in the 79577306600 owner's manual.
Quick reference: “bottom part” terms
| What you see/mean | Common name | What it does |
|---|---|---|
| Front cover at the very bottom | Base grille | Protects components; allows airflow |
| Space behind that cover | Machine compartment | Houses cooling system parts |
| Under the cabinet | Drain pan area | Handles defrost water evaporation |
Why it matters
Using the right term helps you find the correct Kenmore parts and instructions faster, especially for tasks like cleaning condenser coils, checking airflow, or accessing service components safely.
Last updated: January 2026
How to tell cubic feet of Kenmore refrigerator by model number?
You typically can’t calculate cubic feet from the Kenmore model number alone. For Kenmore model 795.77306600, the most reliable way is to look up the capacity in the 79577306600 owner's manual specifications section; if you need a quick estimate, measure the interior and convert cubic inches to cubic feet.
Best ways to find the cubic feet (capacity)
- Check the specs in the manual: Look for “capacity” or “total volume” in the specifications pages of the 79577306600 owner's manual.
- Use the model label to confirm the exact model: The manual notes the identification label is on the right-hand side of the refrigerator compartment; match that model number exactly before comparing specs.
- Estimate by measuring the interior (good for a ballpark): measure usable interior width, depth, and height (in inches), then convert.
How to estimate cubic feet by measuring
- Empty the compartment enough to measure the usable space.
- Measure width x depth x height (in inches).
- Multiply to get cubic inches.
- Divide by 1,728 to convert to cubic feet.
Quick conversion table
| What you have | What to do | Result |
|---|---|---|
| Inches (W x D x H) | Multiply | Cubic inches |
| Cubic inches | Divide by 1,728 | Cubic feet (approx.) |
Why the model number isn’t a dependable “capacity code”
Kenmore model numbers (including the 795 prefix used on many bottom-mount units) identify a design family and configuration, but they don’t consistently encode the exact interior volume. Capacity can also vary by features and revisions within a series.
Helpful tip while you’re checking specs
If you’re measuring because the refrigerator isn’t holding temperature, confirm airflow and control settings in the 79577306600 owner's manual. For troubleshooting display or error indicators on Kenmore 795 bottom-freezer models, use Kenmore 795 model bottom freezer refrigerator error codes.
Last updated: January 2026
Why is my Kenmore refrigerator leaking underneath?
Water leaking underneath a Kenmore bottom-mount refrigerator like model 79577306600 is usually caused by defrost water not draining correctly (a clogged or frozen defrost drain) or by water supply issues if the ice maker or dispenser is connected. Use the 79577306600 owner's manual to locate cleaning and troubleshooting guidance.
Most common causes (and what to check first)
- Clogged or frozen defrost drain: Meltwater backs up and can spill into the cabinet and down to the floor.
- Drain pan overflow or misalignment: During defrost, water should run into the pan; if it is out of place, it can drip underneath.
- Water line or fitting leak: Especially if the unit has an ice maker or water dispenser.
- Door not sealing well: Excess frost can increase defrost water volume and contribute to drain problems.
- Cracked or loose drain tube: The drain path can leak before water reaches the pan (a common fix is replacing the refrigerator drain tube 5251JA3003D).
Step-by-step: quick leak diagnosis
- Confirm the liquid: Water (clear) vs. sticky spill vs. oily residue (service needed).
- Look for ice buildup in the freezer floor: This strongly points to a defrost drain issue.
- Check the drain pan area: Make sure the pan is seated and not overflowing.
- Inspect the water supply line (if connected): Look for drips at the shutoff valve, fittings, and tubing.
- Check door sealing: Clean the gasket surfaces; dirty or sticky gaskets can prevent a good seal.
What you’ll typically see by symptom
| Symptom | Most likely cause | Best next step |
|---|---|---|
| Puddle appears after defrost cycles | Drain pan issue or defrost drain backup | Inspect pan seating; clear drain path |
| Ice sheet on freezer bottom | Frozen/clogged defrost drain | Thaw and clear drain; verify drain tube |
| Leak only when ice maker runs | Water line/fitting leak | Tighten fittings; inspect tubing |
Why it matters
Leaks underneath can lead to floor damage and can also signal airflow and defrost problems that reduce cooling performance. The manual notes that water normally runs into the drain pan during defrost; when that path is disrupted, water ends up on the floor.
Last updated: January 2026
