Kenmore 1069532582 refrigerator Parts

On a Kenmore side-by-side refrigerator like model 1069532582, the model number is printed on the appliance identification label (model and serial tag). You will typically find that label inside the fresh food compartment along the side wall, near the top, or around the door frame area.

Look in these spots first (in order):

• Inside the refrigerator section on the left or right side wall
• On the ceiling of the fresh food compartment (near the light housing)
• Around the door opening or door frame (fresh food side)
• Behind the crisper drawers (on the liner wall)
• On the freezer side wall (less common, but possible)

The tag usually includes both a model number and a serial number. For parts lookup and troubleshooting, we recommend recording:

• Full model number (for example, 1069532582)
• Serial number
• Any revision or additional digits/letters shown after the model

Kenmore model families can share similar door styles and shelves, but use different components (thermostat, evaporator fan parts, door gaskets). Using the exact model number helps ensure the replacement part fits and functions correctly.

Once you confirm the model number, you can match common repairs to the right component, such as a temperature control issue that may involve the refrigerator thermostat WP2198202.

Last updated: February 2026

To clean the condenser coils on your Kenmore 1069532582 side-by-side refrigerator, unplug the refrigerator, access the coils (usually behind the front toe grille or at the back), then vacuum and brush off all dust and pet hair so airflow stays strong and cooling stays efficient.

• Unplug the refrigerator (or switch off power at the breaker).
• Pull the refrigerator out carefully if the coils are on the back; protect the floor.
• Remove the toe grille at the bottom front if your coils are underneath.
• Use a coil brush and a vacuum with a crevice tool to loosen and remove dust.
• Clean the area around the condenser fan and nearby vents.
• Reinstall the grille, move the unit back, then restore power.

• Every 6 months in most homes
• Every 3 months if you have pets, heavy dust, or the refrigerator is in a tight enclosure

Dirty coils make the compressor run longer to remove heat. That can cause warmer temperatures, higher energy use, and more wear on cooling parts.

Coil cleaning helps airflow, but if temperatures are still off, common next checks include:

• Evaporator fan operation (air movement in the freezer); the refrigerator evaporator motor 4389144 is a common airflow-related part.
• Frost buildup on the evaporator (defrost system issue); the refrigerator defrost bi-metal WPW10225581 is often involved.
• Temperature control accuracy; the refrigerator thermostat WP2198202 can affect cycling and temperatures.

Last updated: February 2026

Your Kenmore refrigerator model 1069532582 has a specific cubic-foot capacity, but the most reliable way to get the exact number is to read it from the refrigerator’s rating plate (model and serial tag) inside the fresh food section or freezer. That tag lists the official capacity for your exact build.

Check these common locations on Kenmore side-by-side models:

• Inside the fresh food compartment on a side wall (often upper right)
• On the ceiling of the fresh food compartment near the light housing
• Inside the freezer compartment on a side wall
• Behind the toe grille or near the lower hinge area (less common)

If you find the tag, look for wording like “Capacity”, “Total volume”, or “cu. ft.”.

Use a model-based lookup approach and confirm with measurements if needed:

• Search your model number 1069532582 in your saved purchase paperwork or product listing
• Compare the refrigerator’s exterior size to typical side-by-side capacity ranges
• If you are troubleshooting cooling performance, focus on airflow and temperature control parts first (capacity does not change how the sealed system cools)

Most Kenmore side-by-side refrigerators are commonly in this range:

Knowing the cubic feet helps when you are matching the right replacement shelves and bins, estimating food storage space, and comparing energy use. For performance issues (warm fridge, frost buildup), capacity is less important than components like the thermostat, evaporator fan, and defrost system.

If you are checking cooling problems while you look up capacity, these model-compatible parts are common suspects:

• Refrigerator thermostat WP2198202 (temperature control)
• Refrigerator evaporator motor 4389144 (circulates cold air)
• Refrigerator defrost bi-metal WPW10225581 (prevents heavy frost)

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 1069532582 are cooling issues, ice maker or water dispenser failures, leaks, unusual noises, and frost buildup. Many of these trace back to airflow, defrost, or temperature-control parts that can be tested and replaced.

• Not cooling or warm fridge section: restricted airflow, evaporator fan issue, or a temperature control problem
• Frost buildup on the back wall or in the freezer: defrost system problem (defrost thermostat, heater, or control)
• Ice maker not working or slow ice production: freezer temperature too warm, dispenser/ice path issues, or water supply problems
• Water leaking or puddles: clogged/iced drain, cracked reservoir, or loose fittings
• Noisy operation: evaporator fan blade rubbing, worn fan motor, or vibration from panels/fasteners

The parts below are frequently involved when troubleshooting the issues above on Kenmore 1069532582:

• Confirm controls are set correctly (freezer typically around 0°F, fridge around 37°F).
• Make sure vents are not blocked by food packages.
• Listen for the evaporator fan running when the freezer door is closed (door switch engaged).
• Look for heavy frost on the freezer back panel (strong defrost clue).
• Inspect for water under crispers or under the unit (drain or reservoir clue).

A side-by-side refrigerator depends on steady airflow from the freezer to the fresh food section. When the evaporator fan, defrost system, or thermostat is off, temperatures swing, frost builds, and the ice maker and dispenser performance drops.

For model-specific troubleshooting patterns, we use the same approach as in the Kenmore 106 model refrigerator error codes guide to narrow symptoms to the most likely circuit or component.

Last updated: February 2026

On Kenmore model 1069532582, a sudden loss of cooling is usually caused by an airflow problem (blocked vents or a failed evaporator fan), a defrost failure that lets frost choke the evaporator, or a temperature control issue. Less commonly, it is a sealed-system problem such as a compressor issue.

• Confirm the refrigerator has power and the interior lights come on.
• Set controls to a normal mid-range setting and wait 12 to 24 hours for stabilization.
• Make sure food packages are not blocking return vents in the freezer or fresh-food section.
• Listen for the evaporator fan running when the doors are closed (you may hear it ramp up).
• Check for heavy frost on the freezer back wall (a strong sign of a defrost problem).
• Clean condenser coils and verify the condenser fan (if equipped) is running.

1. Unplug the refrigerator and inspect vents for ice or packaging blockage.
2. If you see heavy frost, do a manual defrost (unplug and leave doors open) until ice is fully melted; then restart and monitor.
3. If airflow is weak, inspect the evaporator fan area for ice obstruction or a loose blade.
4. If the refrigerator side is warm but freezer is closer to normal, check whether the air baffle is opening and closing.

Side-by-side refrigerators depend on steady airflow from the freezer evaporator to cool both compartments. When airflow stops or frost blocks the evaporator, temperatures rise quickly even though the lights work and the unit may still sound like it is running.

Last updated: February 2026
