What size is Kenmore refrigerator model 79551737810?
Kenmore refrigerator model 79551737810 is a side-by-side refrigerator; the exact exterior dimensions (width, depth, height) vary by the specific 795.5173* / 795.5183# version and are listed in the specifications section of the 79551737810 owner's manual.
How to find the exact dimensions for your unit
We recommend using the model’s specification details in the manual because they match your exact configuration (handles, doors, and trim can change overall depth).
- Check the specifications or installation section for W x H x D
- Measure width at the widest point (often the doors)
- Measure height from floor to top of hinge cover
- Measure depth two ways: cabinet only and with handles
- Allow extra clearance for door swing and airflow behind the unit
Typical size range for Kenmore side-by-side refrigerators like this
If you are planning a cabinet opening and need a quick planning range, most Kenmore side-by-side refrigerators in this class fall into these common ranges.
| Measurement | Typical range (planning) | What changes it most |
|---|---|---|
| Width | 32 to 36 in. | Door design, trim |
| Height | 66 to 71 in. | Hinge cover, leveling |
| Depth | 30 to 35 in. | Handles, door thickness |
Why it matters
Using the correct dimensions helps prevent installation problems like doors that cannot open fully, poor condenser airflow (which hurts cooling), and water line kinks behind the refrigerator.
Last updated: February 2026
Where is the water filter on my Kenmore side by side refrigerator?
On Kenmore side-by-side refrigerator model 79551737810, the water filter is located behind a small filter cover inside the fresh food compartment. You open the cover using the push button, then pull the filter down and out of the manifold.
How to find and access the filter
Use these steps (they match the procedure shown in the owner's manual):
- Locate the water filter cover inside the refrigerator section.
- Press the push button to open the filter cover.
- Pull the water filter downward, then pull it straight out.
- Keep the old filter upright as you remove it; a small amount of water can drain.
- Install the new filter with the tabs horizontal, push it in until it stops, then rotate it up and close the cover until it clicks.
After you replace the filter
After installing a new filter, we recommend flushing the system to clear trapped air and loose carbon.
- Dispense about 2.5 gallons of water total.
- Use cycles of 30 seconds ON and 60 seconds OFF (do not run it continuously).
- Expect sputtering at first; that is normal while air purges from the line.
| What you notice | What it usually means | What to do |
|---|---|---|
| Low water flow | Filter is clogged or not fully seated | Reinstall filter, then flush; replace if overdue |
| Small ice cubes | Restricted water supply to ice maker | Replace filter and confirm water supply is on |
| Cover will not close | Filter not rotated up into position | Push filter in fully, rotate up, close until it clicks |
Which replacement filter fits
For this model, a matching replacement is the Kenmore refrigerator water filter 9490 ADQ73613402.
Why it matters
A properly seated, regularly replaced water filter helps maintain normal dispenser flow and ice production. In the manual, Kenmore recommends replacing the filter about every 6 months, or sooner if flow drops or cubes get smaller.
Last updated: February 2026
Why is the water dispenser not working on my Kenmore refrigerator?
On Kenmore refrigerator model 79551737810, the water dispenser usually stops working because the control panel is locked, the refrigerator door is open, air is trapped after a filter or water-line change, or the water supply is restricted (kinked line, closed shutoff valve, or a clogged filter). See the dispenser and water system steps in the owner's manual.
Quick checks that fix most “no water” problems
- Unlock the dispenser: press and hold Lock for 3 seconds.
- Confirm Water mode: press the Water button (not ice).
- Close all doors fully: water will not dispense if a door is open.
- Purge trapped air (new install or after filter change): dispense 2.5 gallons total using 30 seconds ON, 60 seconds OFF cycles.
- Check the house shutoff valve: make sure it is fully open.
- Inspect the water line behind the fridge: straighten any kinks from moving/cleaning.
If flow is weak or stops after a few seconds
A restricted filter is one of the most common causes of low dispenser flow and small ice cubes.
- Replace the filter if it has been in use about 6 months, the indicator is on, or output has dropped.
- After replacing, flush 2.5 gallons using the 30/60 cycle method to clear air.
Model-matched part: Kenmore refrigerator water filter 9490 ADQ73613402
Parts that can cause “no dispense” when the supply is OK
If the water supply is on and the line is not kinked, a failed dispenser electrical or water-delivery part is likely.
| Symptom | Most likely area | Example part for this model |
|---|---|---|
| No response when pressing the lever | Dispenser switch or lever mechanism | Lg refrigerator dispenser switch 6600JB3001C |
| Ice works but water does not | Water inlet valve or frozen/restricted water path | Refrigerator water inlet valve AJU34125558 |
| Leaks or loose tubing at connections | Water tube fitting | Refrigerator water tube fitting 4932JA3002C |
Why it matters
A dispenser that is locked, air-bound, or restricted can look like a major failure, but these checks prevent unnecessary part replacement and help protect the ice maker and water system from low-flow issues.
Last updated: February 2026
