Kenmore 11026702693 washer Parts

To hard reset your Kenmore washer model 11026702693, we recommend a simple power reset first: unplug the washer (or switch off the breaker) for 1 minute, then restore power and try a normal cycle. This clears minor control glitches without changing your wash settings.

Quick hard reset steps (safe first)

• Turn the cycle selector knob to Off.
• Unplug the washer from the outlet (or turn off the circuit breaker).
• Wait 60 seconds.
• Plug back in (or turn the breaker on).
• Close the lid and select a regular wash cycle.
• Pull the timer knob out to start (this matches how this timer-style washer starts and stops). See the 11026702693 owner's manual.

If it still will not start or spin

On this style of Kenmore top-load washer, a “reset” often reveals an underlying issue such as a lid switch not closing, a drain problem, or a drive system fault.

Common checks we use:

• Confirm the lid closes firmly; a failed lid switch can stop spin.
• Listen for the drain pump during drain; a jammed pump can stall the cycle.
• If it agitates but will not spin, inspect the drive coupling and clutch.
• If it fills incorrectly (hot or cold issues), check the mixing valve.

Parts that commonly relate to “won’t run” symptoms

Symptom after reset	Common cause	Example part for this model
Won’t spin, acts “dead” with lid open	Lid safety circuit	Washer lid switch WP3949238
Hums, won’t drain	Pump jam or failure	Washer drain pump WP3363394
Motor runs, no agitation/spin	Broken drive coupling	Coupling 285753A

Why it matters

A hard reset clears temporary timer or control interruptions, but it does not fix mechanical failures. If the washer repeatedly stalls at the same point (fill, agitate, drain, spin), the pattern points to the exact system to troubleshoot and the right replacement part.

Last updated: February 2026

For Kenmore washer model 11026702693, the model number is the key to getting the right parts and repair info. The first three digits (the prefix) identify the manufacturer family, and the remaining digits narrow down the exact design and production variation; always use the full model number from the model and serial number plate.

Where to find the model number on this washer

Our Kenmore washer model and serial number are listed on the model and serial number plate. The owner’s manual specifically notes you will need the complete model and serial numbers when requesting information.

• Check the model and serial number plate on the washer cabinet (commonly under the lid opening area)
• Write down the full model number and serial number exactly as shown
• Keep the information with your purchase date for future parts lookup
• Use the full number (not just the first few digits) when ordering parts

Reference: 11026702693 owner's manual

How Kenmore model numbers are structured (what the digits mean)

Kenmore model numbers are typically read in two main chunks:

Model number section	Example from 11026702693	What it tells you
Prefix (first 3 digits)	110	Manufacturer family used for parts matching
Remainder (next digits)	26702693	Exact washer design and variation

Why the prefix matters

The prefix helps match your washer to the correct parts system and diagrams. For example, many Kenmore washers with a 110 prefix share common Whirlpool-built design families, which is why parts like a lid switch or motor coupling often cross-reference to Whirlpool-style components.

Why it matters when ordering parts

Using the full model number prevents wrong-part issues, especially for common repairs like no-spin, no-drain, or agitation problems.

• Electrical parts can vary by revision (switches, harnesses)
• Drive system parts can differ (coupling, clutch, gear case)
• Tub and basket parts must match the exact configuration

Common parts that depend on the exact model

If you are troubleshooting a symptom, these are examples of parts that must match 11026702693:

• Washer lid switch WP3949238 (safety switch that detects lid closed)
• Coupling 285753A (connects motor to transmission/drive)
• Washer drain pump WP3363394 (pumps water out during drain)

Quick tip for faster parts lookup

When searching, enter the full model number 11026702693 exactly; then confirm the part fits your symptom and location in the diagrams before ordering.

Last updated: February 2026

Yes; repairing a Kenmore washer is usually worth it when the fix restores reliable wash and spin performance for less than replacing the machine. For Kenmore model 11026702693, many common failures involve serviceable parts like the lid switch, drain pump, or motor coupling, which are often straightforward repairs.

Quick way to decide (repair vs. replace)

Use these practical checkpoints before spending money:

• Age and condition: If the cabinet, tub, and controls are in good shape, repairs tend to pay off.
• Symptom type: No-drain, no-spin, or won’t-start issues are often part-related and repairable.
• Cost rule: If the total repair (parts + labor) is under about 50% of a comparable new washer, repair is the better value.
• Repeat failures: Multiple recent breakdowns point toward replacement.
• Leak severity: Small hose or gasket leaks are repairable; major tub or gear case leaks can be costly.

Common repairs that are typically “worth it” on this style of Kenmore washer

These are frequent, high-impact fixes on direct-drive top-load designs:

Problem you see	Likely area	Typical outcome
Won’t spin or starts then stops	Lid safety circuit	Often a single-part fix
Won’t drain or drains slowly	Pump or blockage	Usually restores normal cycles
Agitator doesn’t move properly	Agitator drive parts	Improves cleaning action
Loud grinding or oil leak underneath	Gear case / drive train	Higher cost; evaluate carefully

Helpful parts to consider for model 11026702693:

• Washer lid switch WP3949238
• Washer drain pump WP3363394
• Coupling 285753A

Why it matters

A washer that won’t drain, spin, or agitate can look “dead,” but many failures are isolated to a single wear part. Fixing the right component can restore safe operation and prevent secondary damage (for example, a failing pump causing overflow risk, or a bad lid switch preventing spin).

What we recommend before ordering parts

1. Confirm the symptom and when it happens (fill, agitate, drain, spin).
2. Check installation basics (leveling and vibration can mimic bigger problems).
3. Use the troubleshooting and operating guidance in the 11026702693 owner's manual to match symptoms to likely causes.

Last updated: February 2026

A Kenmore washer typically lasts 10 to 15 years with normal household use. For Kenmore model 11026702693, good loading habits, correct detergent amounts, and routine care from the 11026702693 owner's manual help you reach the upper end of that range.

Typical lifespan and what affects it

Most top-load, agitator-style washers like the 11026702693 land in the 10 to 15 year window. Lifespan usually changes based on:

• Load size and frequency (overloading shortens life)
• Water quality (hard water speeds up valve and seal wear)
• Drain performance (slow draining strains the pump)
• Vibration and balance (out-of-balance loads stress suspension and drive parts)
• Small wear parts being replaced early (before they damage bigger assemblies)

Parts that commonly limit washer life

When a washer starts to slip, leak, or stop spinning, these are frequent wear points on this style of Kenmore washer:

Symptom	Common wear area	Example part for this model
Won’t spin or stops mid-cycle	Lid safety circuit	Washer lid switch WP3949238
Won’t drain or drains slowly	Drain pump or blockage	Washer drain pump WP3363394
Agitates poorly or “ratcheting” sound	Agitator drive dogs/cam	Agitator dog 80040
No agitation/spin, motor runs	Motor coupling	Coupling 285753A

Maintenance habits that extend life

We recommend these simple habits to keep performance strong over time:

• Keep loads evenly distributed to reduce vibration
• Use the right water temperature and cycle for the fabric
• Measure detergent and additives; avoid overuse
• Check pockets to prevent coins and debris from damaging the pump
• If you notice leaking, address it quickly to prevent rust and bearing damage

Why it matters

A washer that is maintained and repaired early usually avoids expensive secondary damage (for example, a draining issue that overheats the pump, or repeated out-of-balance spinning that wears suspension and drive components).

Last updated: February 2026
